ABB 3BSE018137R1 CI858-1 Communication Module

ABB 3BSE018137R1 CI858-1 DriveBus Module: Stop the Clock on Your Downtime — Ship Today

Every minute your line is down, you’re bleeding money. A failed CI858-1 on an AC800M rack doesn’t just kill one drive — it can cascade into a full process shutdown across every PROFIBUS DP slave on that segment. We’ve seen it happen in petrochemical plants, paper mills, and water treatment facilities. The fix is straightforward: swap the module, re-establish the DP master, and get your drives spinning again. The only variable is how fast you can get the part.

We stock the ABB 3BSE018137R1 CI858-1 in Xiamen, China. Orders confirmed before 15:00 CST ship same day via DHL Express or FedEx International Priority. Most destinations in Southeast Asia receive within 24–48 hours. Europe and North America: 48–72 hours door-to-door. No waiting on factory lead times. No broker delays. Just a verified, original ABB module in your hands when you need it most.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Common failure signatures for CI858-1:

• ERR LED solid red: Loss of PROFIBUS DP communication. Check cable termination first — a missing or double termination at segment ends is the #1 field cause. Verify the integrated termination switch on the CI858-1 itself matches your topology.
• System 800xA alarm — “CI858-1 communication error” / Object status OFFLINE: The module has lost its heartbeat with the AC800M CPU. Power-cycle the controller unit. If the alarm persists after restart, the module’s internal ASIC has likely failed — replacement is the only fix.
• Intermittent slave dropouts at high baud rates: Reduce baud rate to 1.5 Mbit/s temporarily to isolate whether the issue is cable impedance or the module. If dropouts stop, inspect cable shielding and grounding. If dropouts continue, suspect the CI858-1 DP transceiver.
• Module not recognized after hot-swap: AC800M firmware below 4.1 does not support true hot-swap on communication modules. Perform a controlled controller restart after seating the new CI858-1. Confirm the module slot address in Control Builder M matches the physical slot.

Step-by-step replacement procedure:

1. Document the current PROFIBUS DP network configuration: slave addresses, baud rate, GSD file versions. Export the CBM project as a backup before touching hardware.
2. Notify downstream operators — all drives on this DP segment will lose communication during the swap. Coordinate a safe process hold or manual override.
3. In System 800xA, set the CI858-1 object to “Offline” to suppress alarm flooding during the swap.
4. Disconnect the PROFIBUS DP cable from the 9-pin D-Sub connector. Label the cable if multiple segments are present.
5. Release the module locking lever and slide the CI858-1 out of the AC800M rack. Handle by the frame — avoid touching the backplane connector pins.
6. Seat the replacement 3BSE018137R1 CI858-1 firmly until the locking lever clicks. Verify the module slot number matches your CBM configuration.
7. Reconnect the PROFIBUS DP cable. Confirm termination switch position matches the original module (ON if this is a segment endpoint, OFF if mid-segment).
8. In System 800xA, set the CI858-1 object back to “Online”. Monitor the ERR LED — it should extinguish within 5–10 seconds as the DP master re-establishes cyclic communication with all slaves.
9. Verify drive status on each ACS/ACS800/ACS880 drive: check the fieldbus status word for “Data Valid” indication. Confirm process values are updating in the faceplate.
10. Release the process hold and monitor for 15 minutes before declaring the repair complete.

Configuration notes: The CI858-1 does not use DIP switches for address assignment — slot position in the AC800M rack determines the module’s logical address in CBM. No firmware flashing is required on the module itself; firmware is managed by the AC800M CPU. If replacing a CI858-1 with a later CI858 revision, verify the hardware revision compatibility table in ABB document 3BSE018137R1/en before installation.
