ABB SNAT 602 TAC Relay Output Module

ABB SNAT 602 TAC — Every Hour of Downtime Costs You. We Ship Today.

Your ACS 600 or ACS 800 drive just tripped on a relay output fault. The line is cold. Maintenance is standing by. You’ve already pulled the SNAT 602 TAC and confirmed it’s the culprit — burned relay coil, welded contacts, or a silent failure that’s taken out your run-permissive signal. You don’t need a lecture on what this module does. You need a replacement on a plane tonight.

We stock the ABB SNAT 602 TAC at our Xiamen warehouse. Verified, inspected, ready to ship via DHL Express or FedEx Priority. Most international orders clear customs and land on your bench within 3–5 business days. Domestic CN delivery is next-day in major cities.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Common failure signatures that point to a dead SNAT 602 TAC:

• ACS 800 fault code F-0022 (Output Phase Loss) or A-0006 (Relay Output Fault) appearing without a wiring change — the relay contact has failed open under load.
• Run-permissive signal to your PLC drops intermittently. Drive shows running, PLC sees no feedback. Classic welded-contact symptom: the relay closes but the contact surface has fused and won’t open on command.
• Auxiliary contactor for motor brake or cooling fan fails to energize. Scope the relay output terminal — if you see the coil energizing (LED on board illuminates) but no continuity across the output contacts, the contact block is gone.
• Drive trips immediately on power-up with no load connected. Check if the SNAT 602 TAC is pulling the fault line low due to an internal short on the relay driver IC.

Step-by-step replacement procedure:

1. Isolate and lock out. Open the main breaker, apply LOTO. Verify zero energy with a CAT III meter at the drive input terminals. Wait the full DC bus discharge time — minimum 5 minutes for ACS 800, check the drive nameplate for exact discharge time.
2. Document wiring before you touch anything. Photograph the terminal block connections to the relay output terminals (typically X2 or X3 on the control board). Label every wire. A mislabeled run-permissive wire will cost you another hour of troubleshooting after the swap.
3. Remove the control board assembly. On ACS 800, the RMIO board and SNAT 602 TAC are mounted on the same carrier. Release the two M4 screws on the carrier bracket, disconnect the SNAT bus ribbon cable, and slide the assembly out. Do not flex the ribbon cable — the ZIF connector is fragile on aged units.
4. Swap the SNAT 602 TAC. The module clips onto the SNAT bus carrier via a 64-pin edge connector. Press firmly and evenly — a partial seating will cause intermittent faults that are nearly impossible to diagnose under load.
5. No DIP switch or address configuration required. The SNAT 602 TAC is not node-addressed. It is a passive relay output board; the drive’s main CPU (NAMC or RMIO) controls it directly via the SNAT bus. No firmware download, no parameter reset needed for the module itself.
6. Verify relay output parameter mapping. After power-up, check ACS 800 parameters 14.01–14.06 (Relay Output 1–6 function assignments). These are stored in the drive’s FLASH memory and survive a board swap — but confirm they match your application’s logic before releasing the line.
7. Functional test under no-load first. Command a run signal from your PLC or HMI. Verify each relay output closes and opens correctly with a continuity tester across the output terminals before reconnecting field devices.

Pro tip: If the replacement module shows the same fault within minutes of power-up, the problem is upstream — check the SNAT bus ribbon cable for cracked conductors at the fold points, and verify the RMIO/NAMC board’s relay driver output voltage. A failed driver IC on the main control board will destroy a new SNAT 602 TAC in the same way it killed the original.

Reliability in Harsh Conditions

The SNAT 602 TAC was engineered for the environments where ABB drives actually live — not climate-controlled server rooms, but steel mill motor control centers, paper machine drive cabinets, and offshore platform MCC panels. ABB’s design validation for the SNAT series includes:

• Vibration resistance: Tested to IEC 60068-2-6, sinusoidal vibration 10–150 Hz, 1 g acceleration. The PCB uses through-hole relay bodies with reinforced solder joints specifically to survive the resonance frequencies common in pump and compressor drive enclosures.
• Thermal cycling: Qualified across the full −40 °C to +70 °C storage range with operational performance guaranteed from 0 °C to +55 °C. The relay coil resistance is compensated for temperature drift — contact pull-in voltage remains stable across the operating range.
• Humidity and condensation: Conformal coating on the PCB provides protection against humidity up to 95% RH non-condensing. In coastal or tropical installations, this coating is the difference between a 10-year service life and a corrosion failure in 18 months.
• EMC immunity: The galvanic isolation between relay contacts and the SNAT logic bus provides inherent protection against common-mode transients from inductive loads. Tested to EN 61000-4-4 (EFT/Burst) and EN 61000-4-5 (Surge) per CE marking requirements.
• Contact endurance: ABB-specified relay contacts rated for a minimum of 100,000 mechanical operations and 30,000 electrical operations at rated load — sufficient for the duty cycles of most industrial run/stop and fault-signaling applications.

Units in our stock are stored in anti-static bags inside foam-lined cartons with humidity indicator cards. Any unit showing a compromised humidity card is quarantined and not shipped. We do not ship modules that have been stored in uncontrolled environments.

Global Express Logistics

Our dispatch hub is in Xiamen, Fujian Province — one of China’s primary export ports with direct DHL, FedEx, and UPS gateway access. Here’s how your order moves:

• Order confirmed before 14:00 CST: Same-day dispatch. The module is packed, labeled, and handed to the carrier the same afternoon.
• DHL Express Worldwide: Transit time 2–4 business days to Europe, 3–5 days to North America, 2–3 days to Southeast Asia. Real-time tracking from pickup to delivery.
• FedEx International Priority: Available for time-critical shipments. Typically 1–3 business days to major hubs in the US, EU, and AU.
• Export documentation: Commercial invoice, packing list, and HS code declaration (HS 8538.90) prepared for every international shipment. DDP (Delivered Duty Paid) terms available for customers who need a single landed cost with no customs surprises.
• Dangerous goods: Not applicable — the SNAT 602 TAC contains no lithium cells or hazardous materials. No special handling surcharges.
• Emergency freight: For genuine production-down situations, contact us directly on WhatsApp for same-day courier booking and priority handling. We have shipped to offshore platforms, remote mining sites, and island facilities where standard logistics routes don’t apply.

We provide the AWB (Air Waybill) number within 2 hours of dispatch so your team can track the shipment in real time and coordinate with your receiving dock or customs broker.
