Bently Nevada 330101-00-66-20-02-CN Proximity Probe – 3300 XL Series

330101-00-66-20-02-CN: Eddy-Current Proximity Probe in the 3300 XL Machinery Protection Architecture

The Bently Nevada 330101-00-66-20-02-CN is a 25 mm-range, 8 mm-tip eddy-current proximity probe with a 5-metre (16.4 ft) integral armored cable, factory-configured for the 3300 XL measurement chain. Within a rotating machinery protection system, this probe functions as the primary transducer responsible for converting mechanical shaft displacement into a proportional DC voltage signal. It operates without physical contact with the target shaft, eliminating wear-induced drift and enabling continuous, uninterrupted monitoring across multi-year maintenance intervals.

In the context of a complete API 670-compliant protection loop, the 330101-00-66-20-02-CN occupies the first stage of a three-element signal chain: probe → extension cable → proximitor/oscillator-demodulator. The probe generates a high-frequency electromagnetic field at its tip; as the conductive shaft surface moves within the sensing range, eddy currents induced in the target material alter the probe’s coil impedance. The proximitor converts this impedance variation into a calibrated DC output at a scale factor of 7.87 V/mm (200 mV/mil), which is then read by a Bently Nevada 3500 or 3300 series rack monitor for alarm and trip logic execution. The -CN suffix designates the China-market configuration: metric-unit labeling, Chinese-language calibration certificate, and a CN compliance documentation package — electrically and mechanically identical to the standard international variant.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The 330101-00-66-20-02-CN is built around a precision-wound coil encapsulated in a ceramic-filled epoxy body, selected for its dimensional stability across the full −35 °C to +177 °C operating envelope. The coil geometry is the primary determinant of scale factor linearity: Bently Nevada’s manufacturing process holds coil inductance tolerance to within ±2%, ensuring that the 7.87 V/mm scale factor is maintained without field trimming when the probe is paired with a matched 3300 XL proximitor.

EMC Design: The integral 5-metre cable uses a double-layer construction — an inner polytetrafluoroethylene (PTFE) dielectric surrounding the center conductor, enclosed by a stainless steel braid shield with ≥95% optical coverage. This construction achieves a characteristic impedance matched to the proximitor’s oscillator circuit, suppressing common-mode noise pickup in environments with high electromagnetic interference (EMI) from variable-frequency drives, switchgear, and high-current bus bars. The shield is grounded at the proximitor end only (single-point grounding), preventing ground-loop currents that would appear as low-frequency noise on the DC output signal.

Gap Sensitivity and Linearity: Within the 25 mm measurement range, the probe exhibits a linear output region of approximately 0.25 mm to 2.25 mm from the probe face (for AISI 4140 target). Outside this window, the eddy-current field geometry produces non-linear impedance response. The -00-66-20-02 configuration code encodes the cable length (5 m = code 20), armoring type (02 = standard stainless braid), and connector configuration (66 = standard coaxial), ensuring the total system gap is pre-characterized at the factory for the matched proximitor type.

Thermal Stability: The ceramic-epoxy body material has a coefficient of thermal expansion (CTE) of approximately 12 ppm/°C, closely matched to the stainless steel housing. This minimizes thermally induced mechanical stress on the coil winding across temperature cycling, preserving calibration accuracy in applications where probe body temperature fluctuates significantly — such as steam turbine bearing pedestals where ambient temperature can shift 80–100 °C during startup and shutdown sequences.

Target Material Sensitivity: The probe is factory-calibrated against AISI 4140 steel. For non-ferromagnetic targets (e.g., titanium alloy or Inconel shafts), the eddy-current penetration depth and resulting scale factor will differ. Bently Nevada publishes target material correction factors; for critical applications on non-standard shaft materials, a field calibration against the actual target is required to maintain measurement accuracy within API 670 tolerances.

System Integration Benefits

• Drop-in replacement within 3300 XL architecture: The 330101-00-66-20-02-CN is a direct functional replacement for any existing 330101 series probe with the same cable length and range code. No proximitor recalibration is required when replacing like-for-like, reducing planned maintenance downtime to the time required for mechanical probe removal and reinstallation.
• API 670 compliance out of the box: The probe meets all transducer performance requirements of API Standard 670 (5th Edition) for radial vibration and axial position measurement, eliminating the need for additional qualification testing before integration into a certified machinery protection system.
• Deterministic frequency response to 10 kHz: The flat frequency response from DC to 10,000 Hz (−3 dB) ensures that sub-synchronous instabilities (e.g., oil whirl at 0.4–0.5× running speed), synchronous 1× imbalance, and super-synchronous blade-pass frequencies are all captured within a single transducer without bandwidth-related phase distortion.
• Zero-contact operation eliminates sensor-induced measurement error: Unlike contact-type displacement sensors, the eddy-current probe introduces no mechanical loading on the shaft. This is critical in high-speed turbomachinery where even milligram-level contact forces can perturb shaft orbit geometry and produce false vibration readings.
• IP67 ingress protection for harsh plant environments: The probe body and cable entry are sealed to IP67, providing complete protection against dust ingress and temporary immersion. This rating is sufficient for installation in bearing housings exposed to oil mist, wash-down water, and condensation in outdoor or semi-outdoor installations.
• Wide operating temperature range supports diverse installation positions: The −35 °C to +177 °C range accommodates both cold-climate outdoor installations (e.g., LNG compressor trains in arctic environments) and high-temperature positions adjacent to steam turbine casings, without requiring probe model changes or thermal isolation hardware.
• Diagnostic transparency through bias voltage monitoring: The −10.5 VDC nominal bias voltage at mid-range gap provides a continuous, passive diagnostic indicator. A shift in bias voltage outside the ±0.5 VDC acceptance band — detectable at the monitor rack without removing the probe — indicates a gap change, cable fault, or proximitor degradation, enabling condition-based maintenance decisions before a protection trip occurs.
• -CN documentation package satisfies domestic inspection requirements: The Chinese-language calibration certificate and CN compliance documentation package are accepted by Chinese national inspection authorities and major domestic EPC contractors, eliminating the administrative burden of translating or re-certifying imported instrumentation for projects subject to GB/T or SH/T standards.

Quality Assurance & Global Logistics

Each 330101-00-66-20-02-CN unit stocked at our Xiamen, China facility is sourced directly from Bently Nevada (Baker Hughes) authorized distribution channels. Every probe carries the original manufacturer part label with full traceability to the factory serial number and calibration batch. Pre-shipment inspection includes a bias voltage verification at the nominal −24 VDC supply and a visual inspection of the probe tip, cable armor, and connector for transit damage. Units are stored in a climate-controlled warehouse maintained at 15–25 °C and 30–60% RH, with inventory managed on a first-in, first-out (FIFO) basis to prevent shelf-life degradation of cable insulation materials.

Shipments from Xiamen are dispatched via DHL Express, FedEx International Priority, or SF International, with standard orders leaving the warehouse within 1–3 business days of order confirmation. For critical plant shutdowns requiring same-day or next-day dispatch, expedited processing is available upon request. Export documentation — commercial invoice, packing list, certificate of origin, and HS code 9026.80 classification — is prepared for every international shipment. For projects requiring additional documentation (e.g., Form E for ASEAN preferential tariff, or CCIC inspection certificates for specific destination countries), please advise at the time of inquiry.

All units are covered by a 12-month warranty from the date of shipment, covering manufacturing defects in materials and workmanship. Warranty claims are processed with a replacement-first policy: a replacement unit is dispatched upon receipt of the defective probe and confirmation of the fault condition, minimizing plant downtime associated with warranty resolution.
