B&R APCI5096 PCI Data Acquisition Card – APCI Series

B&R APCI5096 PCI Data Acquisition Card: Precision Analog Input Architecture for Industrial Control Loops

The B&R APCI5096 is a 32-bit PCI-bus data acquisition card designed for high-resolution analog signal conditioning in process automation, machine control, and laboratory instrumentation environments. Operating within the B&R APCI series framework, this module occupies a single PCI slot and presents a deterministic, interrupt-driven acquisition pipeline to the host industrial PC. Its role in a control loop is unambiguous: it serves as the analog front-end boundary between field-level transducers—thermocouples, pressure transmitters, load cells—and the software execution layer running on a PCI-based IPC or embedded controller.

Unlike generic PC-based DAQ cards, the APCI5096 is engineered to B&R’s industrial-grade electrical specifications, meaning it is rated for continuous operation in environments with elevated ambient temperatures, conducted EMI, and vibration profiles consistent with panel-mount industrial enclosures. The card’s analog input channels are individually buffered, and the multiplexer switching sequence is managed by an onboard FPGA-class sequencer that eliminates inter-channel crosstalk artifacts common in lower-grade acquisition hardware. This architecture ensures that each sampled value reflects the actual field signal at the moment of conversion, not a blended artifact of adjacent channel settling transients.

In closed-loop control applications, the APCI5096 functions as the primary feedback acquisition node. A PID controller executing on the host CPU reads digitized process variable data from the card’s FIFO buffer via the PCI bus, computes the error term, and issues corrective output commands—typically through a paired analog output card or digital I/O module. The card’s interrupt latency characteristics and DMA transfer capability directly influence the achievable loop update rate. B&R’s driver architecture for the APCI series supports both polled and interrupt-driven acquisition modes, allowing system architects to select the transfer method that best matches the determinism requirements of their specific control application.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The APCI5096’s analog front-end employs a precision instrumentation amplifier stage ahead of the multiplexer, providing a common-mode rejection ratio (CMRR) exceeding 80 dB at 50/60 Hz. This is a deliberate design choice for industrial environments where ground loops between field instruments and the host IPC are unavoidable. The differential input configuration allows the card to reject noise voltages induced on cable shields without requiring galvanic isolation at the card level—a cost-effective architecture when the field wiring distances are under 10 meters and the noise environment is moderate.

The onboard SAR ADC operates with an internal reference voltage derived from a buried-zener reference circuit, which exhibits a temperature coefficient of approximately ±5 ppm/°C. Over the card’s rated 0–60 °C operating range, this translates to a worst-case reference drift of ±300 ppm—equivalent to ±19.7 mV on a ±10 V input range. For applications requiring tighter absolute accuracy, the card supports user-calibration routines accessible through the B&R driver API, allowing offset and gain correction coefficients to be stored in onboard non-volatile memory.

The PCI bus master DMA engine is implemented in the card’s onboard FPGA logic. When DMA mode is active, the APCI5096 autonomously transfers completed sample blocks from its 4096-sample FIFO to a host-memory ring buffer without CPU intervention. This architecture decouples the acquisition process from the host CPU’s interrupt service routine latency, which is particularly significant in Windows-based IPC environments where interrupt latency can vary by several milliseconds under load. The DMA block-transfer mechanism ensures that no samples are lost even when the host OS is temporarily preempted by higher-priority tasks.

EMC hardening on the APCI5096 includes a multi-layer PCB stackup with dedicated analog and digital ground planes separated by a split-plane boundary at the ADC’s analog-digital interface. Bypass capacitors are placed within 2 mm of each IC power pin, and the PCI edge connector is filtered with common-mode chokes to suppress high-frequency noise conducted from the backplane. The card’s metal bracket provides a low-impedance chassis ground connection, completing the EMC shielding loop when installed in a properly grounded IPC chassis.

System Integration Benefits

• Deterministic acquisition timing: The onboard timer-based trigger mode generates acquisition start pulses with a jitter of less than 100 ns, enabling precise time-stamping of sampled data relative to external process events—critical for correlation analysis in multi-variable control systems.
• Reduced CPU overhead via DMA: Bus master DMA transfers eliminate the per-sample interrupt overhead that would otherwise consume 15–30 % of CPU cycles at 100 kS/s, freeing the host processor for PID computation, HMI rendering, and communication stack processing.
• Software-configurable input ranges: Per-channel range selection (±10 V, ±5 V, 0–10 V) eliminates the need for external signal conditioning attenuators in mixed-signal installations where different transducer types share the same acquisition card.
• Onboard FIFO buffering: The 4096-sample FIFO absorbs burst acquisition data during periods when the PCI bus is occupied by other masters, preventing sample loss without requiring real-time OS guarantees from the host platform.
• Integrated digital I/O lines: Eight TTL-compatible bidirectional lines on the same card allow synchronization signals, relay control outputs, or limit-switch inputs to be handled without a separate digital I/O card, reducing slot count and wiring complexity.
• External trigger input: A TTL-level external trigger input allows the APCI5096 to synchronize acquisition starts with external events—machine cycle signals, encoder index pulses, or PLC output triggers—enabling event-driven data capture without software polling latency.
• Diagnostic transparency via driver API: The B&R APCI driver exposes FIFO overflow flags, DMA transfer error counters, and calibration status registers through a documented API, allowing application software to implement self-diagnostic routines and log acquisition integrity events without hardware oscilloscope access.
• Drop-in compatibility with existing APCI installations: The APCI5096 is mechanically and electrically compatible with the APCI-series connector pinout standard, allowing direct replacement of aging DAQ cards in existing B&R IPC-based systems without PCB or wiring modifications.
• Broad OS support: Validated driver packages for Windows XP through Windows 10 and Linux kernel 2.6+ ensure the card can be integrated into both legacy and current-generation IPC platforms without custom driver development effort.
• 12-month warranty coverage: Every unit shipped from our Xiamen facility carries a 12-month functional warranty, with documented RMA procedures and technical support available via email and WhatsApp for rapid fault resolution.

Quality Assurance & Global Logistics

Every B&R APCI5096 unit dispatched from our Xiamen, China operations center is sourced through verified B&R distribution channels and subjected to a structured pre-shipment inspection protocol. Physical inspection covers PCB label integrity, firmware revision marking, connector pin condition, and ESD packaging seal verification. Functional bench testing confirms PCI bus enumeration, driver handshake, and basic analog input response prior to final packaging.

Shipments are packed in anti-static ESD bags within foam-lined cartons rated for international air freight handling. Standard export documentation—commercial invoice, packing list, and Certificate of Origin—is prepared for every international order to facilitate customs clearance in major import markets including the EU, North America, Southeast Asia, and the Middle East. DHL Express and FedEx International are the primary carriers for time-sensitive orders, with transit times of 3–5 business days to most destinations. Sea freight consolidation is available for bulk orders exceeding 20 units. All shipments comply with applicable export control regulations, and HS code documentation is provided upon request.
