Emerson PR6424/000-100 CON021 Proximity Sensor – Bently Nevada 3300 XL

Emerson PR6424/000-100 CON021 – Eddy Current Proximity Transducer for Rotating Machinery Protection

The PR6424/000-100 CON021 is an 8 mm eddy current proximity transducer manufactured by Emerson under the Bently Nevada product line. It is engineered for continuous, non-contact measurement of radial shaft vibration and axial position displacement in critical rotating machinery. The transducer operates as part of the Bently Nevada 3300 XL 8 mm Proximity Transducer System, delivering a DC voltage output linearly proportional to the gap between the probe tip and the observed conductive target surface.

In a typical machinery protection architecture, this sensor occupies the front-end position of a three-component measurement chain: probe, extension cable (PR6422 series), and driver/conditioner (330180-51-00). The output feeds directly into Bently Nevada 3300 XL or 3500-series monitor racks, where the signal is processed against alarm and danger setpoints defined per API 670 machinery protection standards. The CON021 connector designation specifies the standard Bently Nevada bayonet-style termination used on this cable length variant (1.0 m integral cable).

This transducer is deployed across power generation, oil and gas upstream and downstream, petrochemical processing, and marine propulsion applications where shaft displacement data must be available continuously with sub-millisecond latency and without mechanical contact that would introduce wear or loading effects on the shaft.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

Eddy Current Excitation Circuit: The PR6424 probe tip houses a precision-wound coil driven by a high-frequency oscillator within the 330180 driver/conditioner, typically operating at 1.0 MHz carrier frequency. When the probe tip is positioned near a conductive target, the oscillating magnetic field induces eddy currents in the target surface. These eddy currents create a counter-magnetic field that loads the probe coil, reducing oscillator amplitude in a manner that is monotonically and linearly related to the probe-to-target gap across the calibrated measurement range. The driver demodulates this amplitude-modulated carrier to produce the final DC output voltage.

Scale Factor Stability: The 7.87 V/mm (200 mV/mil) scale factor is maintained within ±1% across the full operating temperature range through a thermally compensated oscillator design. This is critical in turbomachinery environments where bearing housing temperatures can vary from ambient startup conditions to sustained operating temperatures exceeding 80 °C.

EMC Design: The coaxial cable construction of the integral 1.0 m cable provides inherent shielding against capacitively coupled interference. The shield is grounded at the driver end only (single-point grounding) to prevent ground loop currents that would appear as low-frequency noise on the output signal. The driver’s differential input stage further rejects common-mode interference present on long cable runs in electrically noisy plant environments.

Target Material Correction: The eddy current depth of penetration (skin depth) is a function of target material conductivity and permeability. The PR6424 is factory-calibrated against AISI 4140 steel. For non-ferrous targets (aluminum, titanium, Inconel), the effective scale factor shifts due to differing conductivity values. Bently Nevada provides documented correction factors for common shaft materials, allowing the system to maintain measurement accuracy without hardware changes.

Mechanical Integration: The M10 × 1.0 thread and 316 stainless steel housing allow direct installation into standard proximity probe holders and armored conduit fittings. The probe tip geometry is optimized to minimize sensitivity to target surface finish variations within the Ra 0.4–1.6 µm range typical of machined shaft journals.

System Integration Benefits

• Direct rack compatibility: Plug-and-play termination into Bently Nevada 3300 XL, 3500/40M, 3500/42M, and TDXnet monitor racks without signal conditioning adapters, preserving measurement chain integrity and eliminating additional failure points.
• API 670 compliance path: The PR6424/000-100 CON021 is a qualified component within Bently Nevada’s API 670-compliant machinery protection systems, simplifying documentation and third-party audit processes for critical service applications.
• Deterministic frequency response: The flat frequency response from DC to 10,000 Hz ensures that both low-frequency rotor bow events and high-frequency blade-pass or gear-mesh vibration components are captured without phase distortion, supporting accurate orbit plot generation and spectral analysis.
• Non-contact measurement eliminates mechanical loading: Unlike contact-type displacement transducers, the eddy current principle imposes zero mechanical force on the shaft, making it suitable for lightweight or flexible rotors where contact loading would distort the measurement.
• Simultaneous vibration and position measurement: The DC-coupled output carries both the AC vibration component (dynamic displacement) and the DC gap component (static position), allowing a single transducer to provide both radial vibration amplitude and shaft centerline position data to the monitor rack.
• Diagnostic transparency: The 3300 XL system’s OK relay output, driven by the driver/conditioner, provides a hardware-level signal indicating transducer system health. Loss of probe continuity, cable open-circuit, or driver power failure all drive the OK relay to the de-energized (fault) state, enabling the DCS or safety system to distinguish a genuine process alarm from an instrumentation fault.
• DCS and safety system integration: The ±10 V or 4–20 mA buffered outputs available from the 3500-series monitor racks allow direct integration with Siemens PCS 7, ABB System 800xA, Honeywell Experion, and Rockwell PlantPAx DCS platforms, as well as SIL-rated safety instrumented systems.
• Scalable system architecture: The PR6424 probe is interchangeable across the full PR6424 cable-length family (0.3 m, 0.6 m, 1.0 m, 5.0 m variants), allowing field replacement without driver recalibration when the same cable length is maintained, reducing planned maintenance downtime.

Quality Assurance & Global Logistics

Every PR6424/000-100 CON021 unit supplied through siemensplc.com is sourced from verified channels carrying full Emerson/Bently Nevada OEM traceability. Each unit undergoes incoming inspection covering connector integrity, cable continuity, coil impedance verification, and visual examination of the probe tip and housing for mechanical damage. Units are stored in ESD-controlled, humidity-monitored warehouse conditions in Xiamen, China.

Shipment is executed from Xiamen via DHL Express, FedEx International Priority, or UPS Worldwide Expedited, with typical transit times of 3–5 business days to Europe, 4–6 business days to North America, and 2–4 business days to Southeast Asia. All shipments include commercial invoice, packing list, and certificate of conformance. Calibration certificates and original Emerson documentation are available upon request at time of order.

Export classification and customs documentation are prepared in compliance with Chinese export regulations and destination country import requirements. HS Code 9031.80 applies to this product category in most jurisdictions. The 12-month warranty covers manufacturing defects and verified performance deviations from published specifications under normal operating conditions.
