GE IC695CPE305-ABAH PLC CPU Module – PACSystems RX3i

GE IC695CPE305-ABAH — Dual-Core CPU Controller for PACSystems RX3i Backplane Architecture

The IC695CPE305-ABAH is the ABAH firmware revision of GE’s high-capacity CPU module within the PACSystems RX3i platform. It occupies a single slot on any IC695CHS-series universal backplane and serves as the deterministic execution engine for the entire I/O subsystem. Unlike earlier single-core RX3i processors, the CPE305 integrates a 1.1 GHz dual-core ARM-based processor that partitions real-time ladder/function-block scan execution on one core while offloading Ethernet stack processing, OPC-UA server tasks, and diagnostic polling to the second core. This architectural separation eliminates the scan-time inflation that plagues single-core designs when network traffic spikes — a measurable advantage in high-throughput discrete manufacturing and continuous process control alike.

The module carries 64 MB of battery-backed SRAM for user program and data retention across power cycles, plus 512 MB of onboard NAND flash for firmware, data logging, and recipe storage. Two independent 10/100/1000 Mbps Ethernet ports (RJ-45) support simultaneous EtherNet/IP adapter and scanner roles, SRTP, Modbus TCP, and OPC-UA server — all without auxiliary communication modules. A single RS-232/RS-485 configurable serial port and one USB 2.0 port round out the physical interface set.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The CPE305’s dual-core partitioning strategy is the defining hardware decision of this module. GE’s firmware scheduler assigns the real-time control core a fixed-priority preemptive kernel: the PLC scan task runs at the highest priority level, with I/O update, motion coordination, and SFC sequencing occupying descending priority tiers. The communication core runs a separate RTOS instance handling TCP/IP stack processing, OPC-UA publish/subscribe cycles, and web server diagnostics. Inter-core data exchange occurs through a shared memory region protected by hardware semaphores, ensuring that a burst of EtherNet/IP scanner requests cannot introduce latency into the control scan — a failure mode common in single-core designs where the network interrupt service routine competes directly with the scan task.

The backplane interface uses GE’s proprietary high-speed serial bus operating at 40 Mbps per slot, with the CPU acting as bus master. Each I/O module on the backplane is addressed via a deterministic token-passing protocol: the CPU issues a scan command frame, each module responds with its current I/O image within a bounded time window, and the CPU updates the process image table before executing the next logic scan. This architecture guarantees a worst-case I/O update latency that is calculable at design time — a requirement for any SIL-rated safety application or high-speed closed-loop control.

EMC hardening on the CPE305 follows IEC 61000-4 series test criteria. The PCB layout uses a ground-plane sandwich construction with signal layers routed between solid copper reference planes, reducing radiated emissions and improving immunity to conducted disturbances on the backplane power rails. Ferrite beads on the Ethernet magnetics and TVS diode arrays on the serial port lines provide secondary protection against ESD events up to IEC 61000-4-2 Level 4 (8 kV contact discharge). The module’s metal faceplate is bonded to chassis ground through the backplane connector, completing the Faraday cage for the internal circuitry.

Battery-backed SRAM retention is managed by a dedicated power-fail detection circuit that monitors the 5 VDC backplane rail. When rail voltage drops below 4.75 V, the circuit switches SRAM power to the onboard lithium cell within 2 ms — well within the SRAM data retention hold time — preserving the user program, data tables, and retentive register values across unplanned power interruptions.

System Integration Benefits

• Deterministic Scan Execution: Dual-core partitioning isolates the control scan from network interrupt load, delivering consistent scan times even under peak EtherNet/IP traffic — measurable with PME’s built-in scan time histogram tool.
• Native OPC-UA Server: The CPE305 exposes process variables directly to SCADA, MES, and cloud historian platforms via OPC-UA without a middleware gateway, reducing architecture complexity and eliminating a potential single point of failure.
• Universal Backplane Backward Compatibility: Existing Series 90-30 and Series 90-70 I/O modules install directly into IC695CHS backplanes and are addressed by the CPE305 without adapter hardware, protecting field wiring investments during control system modernization.
• Hot-Standby CPU Redundancy: Paired with the IC695RMX228 Redundancy Memory Xchange module, two CPE305 units synchronize program and data memory at each scan boundary. Switchover time is less than one scan cycle, transparent to field devices — suitable for SIL-2 and high-availability process applications.
• Integrated Diagnostic Transparency: The module maintains a fault table with timestamped entries for I/O module faults, communication errors, and CPU exceptions. PME’s online monitoring mode allows engineers to read fault history, force I/O points, and inspect data tables without interrupting the running program.
• Scalable I/O Architecture: Up to 32,768 discrete and 4,096 analog channels are addressable across local backplane slots and remote PROFINET/EtherNet/IP I/O drops, allowing the same CPU to serve a compact standalone panel or a distributed multi-drop plant network.
• IEC 62443-4-2 Cybersecurity Compliance: Role-based access control with three privilege levels (operator, engineer, administrator), encrypted firmware update verification, and configurable port lockdown align the CPE305 with industrial cybersecurity frameworks including NERC CIP and IEC 62443.
• Multi-Protocol Ethernet Concurrency: Both GbE ports operate simultaneously and independently. Port 1 can serve as an EtherNet/IP scanner for distributed I/O while Port 2 handles SRTP peer-to-peer communication with other RX3i CPUs — no protocol arbitration delay, no shared bandwidth contention.

Quality Assurance & Global Logistics

Every IC695CPE305-ABAH unit dispatched from our Xiamen, China facility passes a structured pre-shipment verification sequence. Physical inspection confirms label authenticity, firmware revision marking, and PCB condition. Functional power-on testing verifies that the module boots to RUN-ENABLED state, that both Ethernet ports negotiate link at 1 Gbps, and that the USB and serial ports respond to protocol handshake. Firmware version is confirmed against GE Emerson’s published revision table for the ABAH build. Units are packed in anti-static shielding bags, cushioned with closed-cell foam, and sealed in moisture-barrier outer packaging rated for international air freight handling.

Shipment from Xiamen typically reaches major industrial hubs within the following transit windows: Southeast Asia 2–4 business days, Europe 5–7 business days, North America 5–8 business days, Middle East and Africa 6–9 business days. DHL Express, FedEx International Priority, and UPS Worldwide Express are the primary carriers. Full export documentation — commercial invoice, packing list, and EAR99 classification statement — is prepared for every international order. DDP (Delivered Duty Paid) terms are available for select destinations upon request. All units are covered by a 12-month warranty from the date of shipment, covering manufacturing defects and functional failures under normal operating conditions.
