GE IC695LRE001B PLC Module – PACSystems RX3i

GE IC695LRE001B — Serial Bus Transmitter for PACSystems RX3i Distributed I/O Architecture

The GE IC695LRE001B is a single-slot Serial Bus Transmitter module engineered for the PACSystems RX3i control platform. Its primary function is to extend the RX3i backplane communication fabric beyond the local chassis, establishing a dedicated serial expansion bus segment that connects the CPU rack to one or more remote I/O expansion racks. In distributed control topologies where physical separation between the controller and field I/O is a structural requirement — such as large-footprint process plants, multi-zone manufacturing cells, or geographically dispersed substations — the IC695LRE001B provides the deterministic, low-latency data path that sustains scan-cycle integrity across the entire I/O domain.

Unlike PROFINET-based remote I/O solutions that rely on Ethernet infrastructure and introduce variable network latency, the RX3i Serial Expansion Bus operated by the IC695LRE001B is a point-to-point, synchronous serial link. The transmitter module on the CPU rack pairs with a corresponding receiver module (IC695LRE001B on the remote rack side) to form a closed, electrically isolated communication channel. This architecture eliminates the need for managed switches, IP address management, or network topology planning, reducing commissioning complexity in environments where network infrastructure is constrained or where determinism requirements preclude shared-medium communication.

The module occupies a single universal backplane slot and draws power directly from the RX3i backplane bus. It is compatible with all standard RX3i universal backplanes — IC695CHS007 (7-slot), IC695CHS012 (12-slot), and IC695CHS016 (16-slot) — and operates transparently with all RX3i CPU variants including the IC695CPE302, IC695CPE305, IC695CPE310, IC695CPE400, and IC695CPE410. No additional configuration is required beyond slot insertion and firmware version verification; the CPU automatically detects the transmitter module during rack initialization and incorporates the remote I/O data into the standard I/O scan cycle.

The IC695LRE001B supports a maximum cable run of 100 meters between the transmitter and receiver using the specified GE serial bus cable assembly. This distance envelope covers the majority of industrial facility layouts without requiring signal repeaters or intermediate amplification stages. For applications exceeding this distance, the system architecture must transition to PROFINET-based remote I/O, which introduces the network management overhead described above. Within the 100-meter constraint, the serial bus delivers consistent, cycle-synchronous data transfer that is unaffected by network congestion or switch forwarding delays.

Field firmware upgrades are supported via Proficy Machine Edition 8.x and above, allowing maintenance teams to apply GE-issued firmware patches without module replacement. This capability is particularly valuable in long-lifecycle industrial installations where hardware replacement carries significant downtime cost and where firmware updates may address diagnostic enhancements or protocol timing refinements introduced in later revisions.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The IC695LRE001B implements galvanic isolation between the RX3i backplane bus and the external serial cable interface. This isolation barrier — typically realized through optocoupler arrays or transformer-coupled transceivers at the physical layer — prevents ground loop currents and common-mode voltage differentials present on long cable runs from propagating into the backplane power domain. In industrial environments where the CPU rack and remote I/O rack are grounded at different structural steel reference points, ground potential differences of several volts are common. Without isolation, these differentials would corrupt serial data frames and introduce systematic bit errors that manifest as intermittent I/O faults. The IC695LRE001B’s isolation architecture eliminates this failure mode entirely.

The module’s EMC design follows IEC 61131-2 requirements for conducted and radiated immunity. The serial bus cable interface incorporates common-mode chokes and transient voltage suppression (TVS) diodes at the connector entry point, providing protection against fast transients (IEC 61000-4-4, Burst Level 3) and surge events (IEC 61000-4-5, Level 2) that are characteristic of motor drive switching, contactor operation, and lightning-induced surges on cable shields. The module housing provides shielded enclosure continuity when installed in a properly grounded RX3i backplane, contributing to the system-level radiated emission performance required for CE marking.

The serial bus protocol implemented by the IC695LRE001B uses a master-slave arbitration model where the CPU rack transmitter initiates each communication cycle. The remote receiver acknowledges each frame within a defined timeout window; failure to receive acknowledgment within this window triggers a configurable fault response in the CPU — either a controlled shutdown, a hold-last-value strategy, or a fault-output activation, depending on the application program’s I/O fault handling configuration. This deterministic fault detection mechanism ensures that cable disconnection or receiver power loss is detected within one scan cycle, preventing the CPU from operating on stale I/O data.

Revision B of the IC695LRE001B incorporates diagnostic register enhancements relative to earlier revisions, exposing communication error counters and link status flags that are accessible via the CPU’s I/O diagnostic tables in Proficy Machine Edition. These registers allow maintenance personnel to trend communication quality over time, identifying cable degradation or connector corrosion before they progress to hard faults — a capability that is absent in third-party serial bus alternatives and that directly supports predictive maintenance programs.

System Integration Benefits

• Scan-Cycle Synchronous Data Transfer: The serial bus operates in lockstep with the CPU scan cycle, ensuring that all remote I/O data is refreshed once per scan with no additional latency accumulation from network scheduling or switch forwarding queues.
• Zero Network Infrastructure Dependency: The point-to-point serial link requires no Ethernet switches, IP addressing, or VLAN configuration, eliminating a class of infrastructure failure modes and reducing the skill set required for commissioning and maintenance.
• Deterministic Fault Detection: Communication loss between transmitter and receiver is detected within one CPU scan cycle, enabling the application program to execute fault-response logic before the process state becomes undefined.
• Galvanic Isolation: The isolation barrier between the backplane bus and the serial cable interface prevents ground loop interference and common-mode voltage damage, extending hardware service life in electrically noisy industrial environments.
• Transparent CPU Integration: The CPU automatically enumerates the IC695LRE001B during rack initialization; no additional hardware configuration or I/O map reservation is required beyond the standard Proficy Machine Edition hardware configuration tree.
• Field Firmware Upgradability: Firmware updates are applied in-situ via the programming software connection, eliminating module removal and reducing the maintenance window duration for firmware-level corrections.
• Diagnostic Register Transparency: Revision B exposes communication error counters and link health flags accessible from the CPU diagnostic tables, providing quantitative data for predictive maintenance and root-cause analysis of intermittent faults.
• EMC-Hardened Physical Interface: Integrated TVS diode arrays and common-mode chokes at the cable connector protect the module against fast transient bursts and surge events per IEC 61000-4-4 and IEC 61000-4-5, reducing the risk of hardware damage from switching transients on long cable runs.
• Scalable Distributed Architecture: Multiple IC695LRE001B modules can be installed in the CPU rack (subject to backplane slot availability and CPU configuration limits), each supporting an independent serial bus segment and remote rack, enabling incremental I/O expansion without architectural redesign.
• Reduced Commissioning Risk: Using the OEM-specified transmitter module eliminates protocol compatibility unknowns and ensures that GE’s published timing specifications and fault behavior are fully realized, reducing the validation effort required for safety-related or high-availability applications.

Quality Assurance & Global Logistics

Every IC695LRE001B unit supplied by siemensplc.com undergoes functional verification prior to dispatch. Units are sourced through traceable supply channels — authorized distributors, factory-surplus inventory, and certified refurbishers — with full documentation available including Certificate of Conformance (CoC) and test records upon request. Original GE/Emerson packaging is supplied where available; units without original packaging are shipped in anti-static ESD-safe bags with foam cushioning conforming to JEDEC JESD625 handling standards.

All orders are fulfilled from our warehouse in Xiamen, China. Xiamen’s port infrastructure and direct access to major international express carriers — DHL Express, FedEx International Priority, and UPS Worldwide Express — enable next-business-day dispatch for in-stock units, with typical transit times of 3–5 business days to Europe and North America, and 2–4 business days to Southeast Asia. Sea freight consolidation is available for bulk orders where air freight cost is prohibitive. Export documentation including commercial invoice, packing list, and certificate of origin is prepared for all international shipments to facilitate customs clearance. HS Code 8537.10 applies to this product category for import duty classification purposes.

A 12-month warranty covers all units from the date of shipment. Warranty claims are processed with a target response time of 48 hours; defective units are replaced or credited at the supplier’s discretion following return merchandise authorization (RMA) issuance. Technical pre-sale support — including compatibility verification, firmware version guidance, and system configuration review — is provided at no charge by our engineering team.
