PKG 6M-2/CS10922 Industrial Cordset – Single Ended Series

PKG 6M-2/CS10922: 6-Meter Single Ended Cordset for Deterministic Field Signal Transmission

In distributed control architectures, the physical layer between a field device and the I/O subsystem is not a passive element — it is a precision signal conduit. The PKG 6M-2/CS10922 is a 6-meter single ended cordset engineered to maintain signal integrity across the full span of an industrial sensor loop. Its role in the control circuit is to deliver a low-impedance, shielded transmission path from proximity sensors, photoelectric detectors, or actuator feedback devices directly to PLC digital input terminals, without introducing ground loops, capacitive crosstalk, or connector-induced voltage drop that would degrade switching threshold accuracy.

The single ended configuration — one factory-terminated connector mated to a stripped or ferrule-terminated open end — is the standard topology for field-side wiring in panel-to-device runs. This design eliminates the need for junction boxes in short-to-medium distance installations and reduces the total connector count in the signal chain, which directly lowers the probability of intermittent contact faults over the service life of the installation. At 6 meters, the 6M-2/CS10922 covers the majority of machine-cell wiring scenarios without requiring cable extensions or intermediate splices.

The cordset is designed for integration with PKG-series sensors using M12 circular connector interfaces, and is compatible with standard A-coded pinouts used across Siemens, Mitsubishi, Omron, and Allen-Bradley PLC I/O modules when terminated via appropriate field-side wiring practices. The cable jacket compound is selected for resistance to cutting oils, hydraulic fluid mist, and the thermal cycling typical of enclosed machine enclosures operating between -25 °C and +80 °C.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The CS10922 series cordset employs a foil-and-braid composite shield architecture. The foil layer provides continuous 360° coverage against high-frequency radiated interference — a critical requirement in environments where variable-frequency drives (VFDs), servo amplifiers, and inductive welding equipment generate broadband EMI in the 150 kHz–30 MHz range. The outer braid layer adds mechanical robustness to the shield termination at the connector backshell, preventing shield discontinuity under repeated flexing cycles, which is the primary failure mode in cordsets installed on moving machine axes or robot end-effectors.

The M12 connector body is constructed from nickel-plated zinc alloy, providing a low-resistance ground path from the cable shield to the sensor housing ground stud. This direct metallic continuity — rather than a pigtail ground wire — eliminates the inductive impedance that would otherwise allow high-frequency noise to bypass the shield at the connector interface. In installations where the PLC I/O module uses a separate functional earth (FE) terminal, the shield drain wire at the open end should be terminated to FE, not PE, to avoid circulating ground currents that appear as common-mode noise on the signal conductors.

The PUR jacket compound exhibits a Shore A hardness of approximately 85–90, balancing flexibility at low temperatures with resistance to abrasion from cable tray edges and conduit entry points. PUR outperforms standard PVC in environments with continuous exposure to cutting emulsions and hydraulic oil mist, where PVC plasticizers leach out over time, causing jacket embrittlement and cracking at bend radii below the rated minimum. The stranded conductor construction supports a minimum bend radius of 5× cable OD for static installations and 10× OD for dynamic flex applications, making the 6M-2/CS10922 suitable for energy chain (cable carrier) deployment on linear and rotary axes.

System Integration Benefits

• Deterministic signal latency: Low-capacitance conductor geometry limits cable-induced signal rise-time degradation to under 1 µs for 24 VDC switching signals at 6 meters, preserving timing accuracy for high-speed counting and position-capture on Siemens S7-1200/1500 HSC modules.
• Reduced commissioning error rate: Factory-terminated connectors eliminate field-side pin crimping errors. The keyed M12 body prevents mis-mating with incompatible connector types, reducing wiring faults in multi-sensor panel builds.
• IP67 ingress protection: The mated connector assembly maintains IP67 per IEC 60529, enabling direct installation in wash-down zones, coolant splash areas, and outdoor enclosures without additional conduit protection.
• EMC-compliant shield termination: The 360° backshell shield connection meets IEC 61000-4-3 (radiated immunity) and IEC 61000-4-6 (conducted immunity) requirements, supporting CE marking of the end-system without supplementary filtering components.
• Predictive maintenance baseline: Consistent factory electrical characteristics — known conductor resistance, capacitance, and insulation resistance — allow commissioning baseline measurements to be recorded and compared during scheduled maintenance to detect insulation degradation before failure.
• Dynamic flex compatibility: Stranded conductors and PUR jacket support 10× OD minimum bend radius in continuous flex, compatible with cable carrier installations on linear axes and robot wrist assemblies.
• Simplified spare parts inventory: A single cordset part number covers multiple sensor types sharing the same M12 connector interface, reducing MRO line items and simplifying procurement for multi-vendor machine installations.
• Thermal cycle stability: Connector contact plating and cable jacket compound maintain dimensional and electrical stability across the full -25 °C to +80 °C operating range, preventing contact resistance drift in applications with large ambient temperature swings between production and shutdown periods.

Quality Assurance & Global Logistics

Every PKG 6M-2/CS10922 unit supplied through siemensplc.com is sourced from verified distribution channels with documented supply chain traceability. Incoming stock undergoes a structured inspection protocol: label and date code verification, connector body and locking ring inspection, cable jacket continuity check, and pin-out verification against the PKG CS10922 reference specification. Lot numbers and supplier documentation are retained for each batch, and certificates of conformance are available upon request for regulated industry procurement.

Dispatch is handled from our logistics hub in Xiamen, China, with access to DHL Express, FedEx International Priority, and EMS for time-critical shipments. Standard in-stock orders are processed within 1–3 business days. For bulk procurement (10+ units), consolidated air freight and sea freight options are available with competitive lead times. Export documentation — commercial invoice, packing list, and certificate of origin — is prepared for all international shipments. The 12-month warranty covers manufacturing defects and connector integrity from the date of dispatch.
