Siemens 6GT2002-0AA00 RFID Basic Module

Siemens 6GT2002-0AA00 MOBY-I Basic Module: Stop the Clock on Your Downtime

Every minute your line is down, you’re bleeding money. A failed MOBY-I Basic Module 6GT2002-0AA00 can halt an entire automotive body shop, a conveyor sorting system, or a precision machining cell — and waiting two weeks for a standard distributor order is simply not an option. We stock the Siemens 6GT2002-0AA00 specifically for emergency callouts. Order before cutoff and your replacement module ships same day from Xiamen via DHL Express or FedEx International Priority. That’s the difference between a four-hour fix and a four-day nightmare.

The 6GT2002-0AA00 is the central processing unit of the MOBY-I RFID identification system. It bridges your SIMATIC S7 PLC environment to the SLG read/write heads via RS-232 or RS-422, managing all data transactions with MOBY-I MDS transponders. When this module fails, the entire RFID loop goes dark — no pallet tracking, no tool identification, no WIP traceability. Getting the right part fast is the only fix.

⚡ URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Most common failure signatures for the 6GT2002-0AA00:

• No communication with SLG head: The BM powers up (24 V LED on) but the SLG status LED stays red or off. Nine times out of ten this is a dead RS-422 driver IC inside the BM — not the cable, not the SLG. Swap the BM first.
• Intermittent read errors / CRC faults: Caused by degraded internal oscillator or corrupted firmware flash. STEP 7 diagnostic buffer will log “BM not responding” or “Timeout SLG.” A firmware re-flash rarely fixes this — replace the module.
• 24 V present but all LEDs dark: Internal DC/DC converter failure. Check incoming voltage at terminal block first (must be 20.4–28.8 V DC). If voltage is good, the BM is dead.
• Sporadic MDS read failures at high conveyor speed: Before blaming the BM, check SLG mounting angle and gap distance. If geometry is correct and the issue persists after SLG swap, the BM’s timing registers may have drifted — replace it.

Step-by-step hot-swap procedure:

1. Document current DIP switch settings on the failed BM (photograph before removal — settings control RS-232 vs RS-422 mode, baud rate, and parity).
2. Power down the 24 V supply rail feeding the BM. Do not hot-swap — the RS-422 interface is not hot-plug tolerant.
3. Disconnect the SLG cable (M12 or terminal block depending on revision) and the 24 V supply terminals.
4. Unclip from DIN rail. Clip in the replacement 6GT2002-0AA00.
5. Set DIP switches on the new BM to match your documented settings before applying power.
6. Reconnect SLG cable and 24 V supply. Power up.
7. In STEP 7 or TIA Portal, run the MOBY-I function block (FC) with command “RESET” (CMD = 1) to initialize the BM-SLG link. Wait for “Ready” status bit.
8. Perform a test read/write cycle with a known-good MDS transponder before releasing the line.

Configuration notes: The 6GT2002-0AA00 does not support automatic address assignment — the BM address is fixed by hardware DIP switches. If you are replacing a unit in a multi-drop RS-422 network, ensure the new BM is set to the same node address as the failed unit. Mismatched addresses will cause the entire network segment to drop communication.

Reliability in Harsh Conditions

The MOBY-I Basic Module was engineered for the factory floor, not the server room. Siemens designed the 6GT2002-0AA00 to operate continuously in environments that would kill consumer-grade electronics within weeks.

Vibration resistance: The BM’s internal PCB uses conformal coating and through-hole component anchoring on critical ICs, making it resistant to the constant low-frequency vibration typical of press shops and conveyor frames. Connector retention force on the terminal blocks exceeds IEC 60068-2-6 test levels.

Thermal cycling: Industrial cabinets in foundry and paint shop environments routinely swing from cold startup at 5 °C to sustained 50 °C operation during peak production. The 6GT2002-0AA00’s operating range of 0–55 °C covers this envelope, and the internal components are rated for extended thermal cycling without solder joint fatigue.

EMC immunity: Automotive and heavy manufacturing environments are electrically hostile — VFD switching noise, welding transients, and inductive load switching are constant. The BM meets EN 61000-4-4 (EFT/Burst) and EN 61000-4-5 (Surge) immunity requirements. Proper cabinet grounding and shielded SLG cables are still required — but the module itself will not misfire from typical industrial EMC events.

Humidity and condensation: While the IP20 rating means the BM must be installed inside a sealed cabinet, the internal components tolerate relative humidity up to 95% non-condensing. If your cabinet breathes (no positive pressure purge), ensure a cabinet heater is active during cold startups to prevent condensation on the PCB.

Global Express Logistics

Our warehouse is located in Xiamen, Fujian Province — one of China’s primary export hubs with direct access to DHL, FedEx, and UPS international gateways. When your line is down, logistics speed is everything.

Standard express timeline (DHL Express / FedEx International Priority):

• Southeast Asia (Singapore, Thailand, Malaysia, Vietnam): 1–2 business days
• Europe (Germany, Poland, Czech Republic, UK): 2–3 business days
• North America (USA, Canada, Mexico): 2–4 business days
• Middle East (UAE, Saudi Arabia, Turkey): 2–3 business days
• South America (Brazil, Argentina): 3–5 business days

Our dispatch process: Orders confirmed before 14:00 CST are packed and handed to the carrier the same day. Each shipment includes a commercial invoice, packing list, and country-of-origin certificate. For shipments requiring an export license or customs pre-clearance documentation, our logistics team handles the paperwork — you just need to receive the package.

Tracking numbers are sent via email within 2 hours of carrier pickup. For urgent shipments, we can also arrange airport-to-airport cargo if your local freight forwarder needs to collect at the destination airport for same-day customs clearance.

We have shipped Siemens automation components to over 60 countries. Customs classification for the 6GT2002-0AA00 falls under HS code 8537.10 (programmable controllers / industrial control panels) in most jurisdictions — our team will confirm the correct code for your destination country before shipment.
