YASKAWA CIMR-M5N2011 AC Servo Drive

YASKAWA CIMR-M5N2011 — Every Hour of Downtime Costs You Money. We Ship Today.

Your line is down. The CIMR-M5N2011 has faulted, and the clock is running. Whether it’s an OC (overcurrent) trip, a UV (undervoltage) alarm, or a blown gate driver, you don’t have time for a 6-week lead time from the OEM. We stock the YASKAWA CIMR-M5N2011 in Xiamen and can have it on a DHL Express flight within hours of your order confirmation. One call, one part, line back up.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

After 10 years of field work on YASKAWA M5-series drives, these are the failure modes I see most often on the CIMR-M5N2011 — and what to watch for when you drop in a replacement unit.

Top Fault Codes & Root Causes:

• OC (Overcurrent) at startup: Almost always a shorted IGBT module or a failed gate driver board. Before condemning the drive, check motor insulation resistance to ground — a degraded motor winding will blow a new drive just as fast. Megger the motor at 500 V DC; anything below 1 MΩ, fix the motor first.
• UV1 / UV2 (Undervoltage): Check the 24 V DC control power supply on the main PCB. Capacitor aging on the M5 series is a known issue after 8–10 years of service. If the bus voltage is normal but UV persists, the fault is on the control board, not the power section.
• OL1 (Motor Overload): Verify that E2-01 (motor rated current) is set correctly. A common commissioning error is leaving this at factory default, which causes nuisance trips under normal load. Set it to the motor nameplate FLA.
• GF (Ground Fault): Isolate the motor cable and motor separately. If GF clears with motor disconnected, the cable is the culprit — check for insulation damage at conduit entry points.

Replacement Configuration Checklist:

• Parameter backup first: If the old drive still powers up, connect a laptop via RS-485 and use YASKAWA DriveWizard to dump all parameters before pulling the unit. This saves hours of re-commissioning.
• DIP switch S1 (termination resistor): On the M5N, the RS-485 termination resistor is set via DIP switch S1 on the control board. If this drive is the last node on the Modbus chain, switch S1-1 to ON (120 Ω termination). Leaving it OFF on a terminated node causes intermittent communication faults that are extremely difficult to diagnose.
• Frequency reference source: Confirm b1-01 (reference source) and b1-02 (run command source) match your system — analog (0–10 V or 4–20 mA), digital operator, or Modbus. A mismatch here means the drive powers up but won’t respond to commands.
• Carrier frequency (C6-01): Default is 10 kHz. If your motor cable run exceeds 50 m, reduce to 5 kHz to prevent capacitive leakage current from triggering GF faults on the new unit.
• Auto-tuning: Run rotational auto-tune (T1-01 = 0) after installation if the motor is uncoupled from the load. This recalculates motor constants and dramatically improves torque linearity. Skip this step and you’ll leave 15–20% of the drive’s performance on the table.

Reliability in Harsh Conditions

The CIMR-M5N2011 was engineered for the factory floor, not a climate-controlled server room. YASKAWA’s M5 platform was validated against the conditions that actually kill drives in the field.

Vibration: The M5 series meets IEC 60068-2-6 sinusoidal vibration testing at 9.8 m/s² across 10–55 Hz. Bus bar connections and PCB mounting points are reinforced to prevent the micro-fractures that cause intermittent faults in lesser drives after years of machine vibration. In CNC spindle applications — where the drive sits inside a cabinet bolted directly to the machine frame — this matters enormously.

Thermal cycling: Rated for continuous operation at ambient temperatures up to 40°C (50°C with derating). The forced-air cooling system uses a dual-bearing fan with a rated MTBF exceeding 30,000 hours. In practice, the most common thermal failure mode on aged M5 units is fan bearing seizure — the drive overtemps and shuts down on OH (overheat) fault. On a replacement unit, verify the fan spins freely and the heatsink fins are clear of debris before commissioning.

Humidity & contamination: The IP20 enclosure keeps fingers and large debris out, but the M5N is not sealed against fine particulate or condensation. In foundry, woodworking, or food-processing environments, install the drive in a sealed NEMA 12 cabinet with a filtered air heat exchanger. Conformal coating on the control PCB is available on some production runs — check the board revision label if your environment is corrosive.

EMI immunity: The M5 series control board is designed to IEC 61800-3 Category C2 EMI immunity. In environments with heavy welding equipment or large contactors switching nearby, add a line reactor (3–5% impedance) on the input to protect the drive’s rectifier bridge from voltage spikes. This single $50 component prevents the majority of unexplained drive failures in electrically noisy plants.

Global Express Logistics

Our warehouse is located in Xiamen, Fujian Province — one of China’s primary industrial export hubs with direct access to Xiamen Gaoqi International Airport (XMN), a major DHL and FedEx gateway.

Standard shipping timeline from order confirmation:

• Order confirmed before 14:00 CST: Same-day dispatch to DHL/FedEx sort facility
• DHL Express Worldwide: 2–4 business days to most of Europe, Southeast Asia, Middle East, and Australia
• FedEx International Priority: 1–3 business days to North America
• DHL Express to Japan/Korea: Next business day in most cases

Export documentation included with every shipment:

• Commercial invoice with accurate HS code (8504.40) for customs clearance
• Packing list with net/gross weight and dimensions
• Certificate of Origin (Form E for ASEAN, available on request for other regions)
• Test report / inspection certificate available on request

We have shipped YASKAWA drives to over 40 countries. Our logistics team handles export licensing, dangerous goods declarations (where applicable for lithium backup batteries), and customs pre-clearance documentation. You receive a DHL/FedEx tracking number within 2 hours of dispatch — no chasing, no guessing.

For time-critical shipments where every hour counts, contact us directly on WhatsApp for real-time coordination with our warehouse team.
