YOKOGAWA EJA110A Differential Pressure Transmitter

YOKOGAWA EJA110A: Stop the Bleed — Every Minute of Downtime Costs You Money

Your process loop is down. The EJA110A on loop 4 is dead — no output, alarm active, production halted. You’ve already pulled the failed unit. Now you need a replacement in your hands, not a lead time quote. We stock the YOKOGAWA EJA110A in Xiamen and ship same-day via DHL Express or FedEx International Priority. Most destinations in Asia receive within 24–48 hours. Europe and the Americas within 3–5 business days. No excuses. No delays.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Ten years on the floor teaches you that most EJA110A failures fall into three buckets. Here’s how to diagnose fast and swap clean:

Fault 1 — No Output / 3.6 mA Burnout Signal
The transmitter has gone into hardware fault mode. Check the LCD for error code E01 (CPU error) or E08 (sensor failure). If the capsule is cracked from overpressure, you’ll see a frozen reading before the burnout kicks in. Confirm with a HART communicator — if PV is reading max-scale and you can’t write to the device, the sensor cell is gone. Replace the unit; capsule-only swap is not field-practical on the EJA110A.

Fault 2 — Erratic / Noisy Output
Ninety percent of the time this is condensate in the impulse lines, not the transmitter. Blow down both legs, equalize the manifold, and re-zero. If noise persists after that, connect a HART communicator and check Damping Value — factory default is 0.5 s. Bump it to 2.0 s as a temporary stabilizer while you investigate. If the noise is still there with damping at 4.0 s, the DPharp sensor cell has micro-cracking — replace the unit.

Fault 3 — Zero Drift After Maintenance
You’ve reinstalled the transmitter and the zero is off by 2–5%. Classic cause: the manifold was not fully equalized before you closed the block valves, leaving a static head error baked in. Re-equalize, vent both legs, and perform a zero trim via HART. On the BT200 communicator: Basic Setup → Zero Trim → Confirm. Document the trim value — if it exceeds ±5% of span, the capsule is suspect.

Replacement Configuration Checklist (do this before you power up the new unit):

• Verify the capsule range code on the nameplate matches your process span — EJA110A capsules are not interchangeable across range codes without recalibration.
• Check the output direction setting (direct/reverse) via HART before loop connection. A reversed output on a flow loop will drive your control valve fully open on startup.
• Confirm damping value matches the original unit’s setting — retrieve from your instrument database or the old unit’s HART memory if it’s still partially functional.
• Set the engineering unit (kPa, inH₂O, mmH₂O) to match the DCS tag configuration before loop commissioning.
• Perform a loop test at 4 mA and 20 mA from the HART communicator before closing the manifold block valves — confirm the DCS reads correctly at both endpoints.
• If the unit has an integral indicator (LCD), verify the display unit matches the control room display to avoid operator confusion during startup.

Reliability in Harsh Conditions

The EJA110A was not designed for a clean instrument room. It was built for the places where instruments go to die — and survive anyway. The DPharp single-crystal silicon resonant sensor at its core has no moving parts, no oil fill, and no diaphragm fatigue in the traditional sense. Vibration that kills conventional capacitance-cell transmitters — compressor skids, pump headers, reciprocating machinery — barely registers on the DPharp cell. YOKOGAWA’s own vibration testing covers 10–2000 Hz at 9.8 m/s² in all three axes simultaneously.

Thermal cycling is where most transmitters accumulate drift. The EJA110A’s temperature effect is specified at ±0.1% per 28°C change across the full –40 to 85°C ambient range. In practice, on a steam header that cycles from ambient to 80°C every shift, you’ll see less than 0.05% drift over a 12-month calibration interval — verified by our own field data from petrochemical customers in Southeast Asia.

The IP67 dual-compartment housing keeps moisture out of the electronics even in direct water jet washdown environments. The terminal compartment and electronics compartment are physically separated — a wiring fault or moisture ingress in the field wiring side cannot propagate to the sensor electronics. In coastal and offshore installations where salt fog is a daily reality, the epoxy-coated aluminum housing has demonstrated 5+ year service life without corrosion-related failures.

Global Express Logistics

Our Xiamen warehouse is 40 minutes from Xiamen Gaoqi International Airport (XMN), a major DHL and FedEx hub for South China exports. Orders confirmed before 14:00 CST ship same day. Here’s what the timeline looks like from your purchase order to your instrument rack:

• Order Confirmation → Warehouse Pick: Within 2 hours of payment confirmation. Each unit is re-inspected against the order model code before packing.
• Export Documentation: Commercial invoice, packing list, certificate of origin (Form E for ASEAN preferential tariff where applicable), and HS Code 9026.20 declaration prepared in parallel with packing.
• Carrier Handoff: DHL Express or FedEx International Priority. Tracking number issued within 4 hours of pickup scan.
• Transit Times (typical): Southeast Asia 1–2 days | Northeast Asia 1–2 days | Middle East 2–3 days | Europe 3–4 days | North America 3–5 days | South America 5–7 days.
• Customs Clearance Support: We provide pre-shipment HS code confirmation and can issue a detailed technical description letter for customs brokers in markets with strict import controls (India, Brazil, Saudi Arabia).
• Packaging Standard: Anti-static foam insert inside a double-wall export carton. Transmitter is secured against 1.2 m drop test equivalent. Original YOKOGAWA packaging used where available.

For critical shutdowns where air freight is not fast enough, contact us directly — we have relationships with freight forwarders who can arrange next-flight-out courier from Xiamen for genuine emergency situations.
