Bently Nevada 21000-00-00-00-042-03-02 Proximity Probe Assembly

21000-00-00-00-042-03-02 — Stop the Clock on Your Downtime

Every minute a turbine or compressor sits idle, the losses compound. A failed proximity probe in a 3300 XL system doesn’t just trigger a shutdown alarm — it can cascade into a full machinery protection trip, locking out your entire rotating equipment train. The Bently Nevada 21000-00-00-00-042-03-02 Proximity Probe Housing Assembly is stocked, tested, and ready to leave our Xiamen warehouse today. We’ve handled enough emergency callouts to know that the only answer an FAE wants to hear at 2 AM is: “It ships tonight.”

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting and Replacement Tips

Field experience with the 3300 XL system reveals a consistent set of failure modes and replacement pitfalls. Work through these before you pull the trigger on a swap.

Common Fault Signatures:

• OK relay drops, gap voltage reads outside -10 V to -18 V window: First suspect is probe tip contamination or physical damage. Clean the tip with isopropyl alcohol and re-gap before condemning the probe. Target gap: 1.0-1.5 mm for 8 mm probes.
• High static reading with no shaft movement: Check the extension cable (330130/330180) for jacket damage or connector corrosion. A shorted cable mimics a probe failure — swap the cable first, it’s faster.
• Intermittent signal dropout under vibration: Inspect the probe body-to-housing thread engagement. Fretting corrosion on the locknut is a known failure point in high-vibration installations. Torque to spec (typically 14-20 N·m depending on bracket design).
• 3500 monitor shows Not OK after probe replacement: The 3300 XL system does not require probe self-addressing, but the driver/oscillator-demodulator must be matched to the probe series. Confirm the driver part number ends in the correct suffix for 8 mm probes. A mismatched driver will produce a persistent Not OK even with a good probe.

Replacement Procedure (Field-Condensed):

1. Inhibit the channel at the 3500 monitor rack before disconnecting — prevents spurious trips during swap.
2. Loosen the locknut and back the probe out of the bracket. Note the gap setting before removal.
3. Install the 21000-00-00-00-042-03-02 into the bracket. Re-gap to the original setting or per OEM spec (1.0-1.5 mm for 8 mm probes at nominal shaft position).
4. Torque the locknut. Reconnect the extension cable — inspect the BNC/integral connector for bent pins before mating.
5. Re-enable the channel. Verify gap voltage at the driver output: should read between -10 V and -18 V DC. Nominal is typically -12 V at correct gap.
6. Confirm OK relay picks up and the monitor channel shows a valid vibration reading. Log the as-found and as-left gap voltages in your maintenance record.

Configuration Note: The 3300 XL probe series is passive — no firmware, no DIP switches, no addressing. Configuration lives entirely in the 3500 monitor rack. If the monitor was previously configured for this probe series, no rack changes are required on a like-for-like swap.

Reliability in Harsh Conditions

Rotating equipment environments are unforgiving. The 21000-00-00-00-042-03-02 is built to operate where most instrumentation fails. The 316 stainless steel housing resists the corrosive bearing oil mist and process gas atmospheres common in petrochemical and LNG applications. The integral cable construction eliminates the connector junction at the probe body — the most common ingress point for moisture in field-assembled probes.

Vibration endurance is not a marketing claim here. Eddy-current probes mounted directly to bearing housings experience continuous broadband vibration. The 3300 XL housing assembly uses a captured locknut design that maintains thread engagement under cyclic loading — a detail that matters when you’re running a compressor at 12,000 RPM around the clock. Operating temperature range of -35 C to +177 C covers everything from Arctic pipeline compressor stations to hot-section turbine bearing pedestals. The cable jacket compound is rated for continuous oil immersion, not just splash resistance.

ATEX certification means this probe can be deployed in Zone 1 and Zone 2 hazardous areas without additional barriers in most configurations — always verify against your site area classification documentation and the applicable IEC 60079 requirements before installation.

Global Express Logistics

Our dispatch hub is in Xiamen, China — one of the most connected export ports in Asia, with direct DHL and FedEx gateway access. Here is how a typical urgent order moves:

• Order confirmed before 14:00 CST: Same-day pick, pack, and handover to DHL Express or FedEx International Priority.
• DHL Express transit times: Southeast Asia 1-2 days, Middle East 2-3 days, Europe 3-4 days, Americas 4-5 days. Times are door-to-door from Xiamen.
• Documentation package included: Commercial invoice, packing list, certificate of origin, and HS code declaration (HS 9031.80). No customs clearance surprises.
• Tracking: AWB number provided within 2 hours of carrier pickup. Real-time tracking link sent directly to your email.
• Bulk orders: For 5+ units, we consolidate with other parts on your BOM and ship as a single consignment — reducing per-unit freight cost and clearing customs as one entry.
• Export compliance: All shipments comply with applicable EAR/ECCN regulations. We handle the paperwork; you handle the installation.

If your plant is down and every hour counts, call us directly. We will confirm stock, generate the commercial invoice, and have the unit moving within the hour.
