Bently Nevada 31000-28-05-50-050-03-02 Proximity Probe

31000-28-05-50-050-03-02 — Every Hour of Downtime Costs You. We Ship Today.

Your turbine is down. The compressor tripped on a vibration fault. The DCS is screaming. You’ve traced it to the proximity probe — and now you need a replacement now, not in six weeks from a slow-moving distributor. The Bently Nevada 31000-28-05-50-050-03-02 is on our shelf in Xiamen. We’ve shipped this exact part to refineries in Malaysia, power plants in Saudi Arabia, and compressor stations in Kazakhstan — all on emergency timelines. We know what’s at stake.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Common fault codes that lead you here:

• Alert 1 / Danger 2 on 3300/3500 rack: Shaft vibration exceeding setpoint — first suspect probe gap drift or probe failure before condemning the shaft.
• –24 VDC driver output, no signal: Extension cable open circuit or probe tip shorted. Swap probe first — it’s the cheapest fix.
• Proximitor output stuck at –2 VDC or –18 VDC: Probe is either too close or too far from the target. Re-gap before assuming probe failure.
• Intermittent vibration spikes at speed: Check probe tip for mechanical contact marks. A rubbed probe gives false high readings and will eventually fail hard.

Replacement procedure — field-tested sequence:

1. De-energize the Proximitor sensor before disconnecting the probe. Hot-swapping the coaxial connector can damage the Proximitor input stage.
2. Record the existing gap voltage before removal (should be –10 VDC ±0.5 V at 1.27 mm). This is your baseline for the new probe.
3. Thread the new 31000-28-05-50-050-03-02 into the bracket — M28 thread, hand-tight plus 1/4 turn. Do not over-torque; the housing is stainless but the bracket threads can gall.
4. Set the gap to 1.27 mm (50 mil) using a feeler gauge or the voltage method: energize the Proximitor and adjust until output reads –10.0 VDC ±0.2 V.
5. Lock the probe with the jam nut — torque to 20 N·m. Verify gap voltage has not shifted after locking.
6. Reconnect the extension cable and verify continuity end-to-end before powering the monitor.
7. Check the 3300/3500 monitor channel for OK status. A healthy channel shows green OK LED and gap voltage within the –10 VDC window.
8. Perform a slow-roll check at <600 RPM before bringing the machine to full speed. Confirm vibration reading is below 1 mil pk-pk at slow roll — anything higher suggests a gapping or target surface issue.

Configuration notes: The 31000-28-05-50-050-03-02 is a passive probe — no firmware, no DIP switches, no addressing. The only configuration is mechanical gap. If you are replacing into a 3500 rack with a 3500/42M or 3500/45 monitor, verify the channel is configured for 3300 XL transducer type in the rack configuration software (System 1 or Rack Configuration). Mismatched transducer type selection will cause the monitor to report incorrect engineering units.

Non-standard target materials: If your shaft is Inconel, titanium, or duplex stainless, the standard –10 VDC calibration does not apply. You must perform a field calibration using the Bently Nevada calibration rig or request a factory-calibrated probe for your specific target material. Failure to recalibrate will result in systematic measurement error — typically 15–30% — which can mask real vibration events or generate nuisance trips.

Reliability in Harsh Conditions

The 3300 XL probe housing is not a lab instrument. It was designed for the places where equipment goes to be punished. The 316 stainless steel housing resists chloride-induced corrosion in offshore splash zones and coastal petrochemical plants. The M28 thread form is coarse enough to resist vibration-induced loosening without locking compound — though we still recommend Loctite 243 on the jam nut in high-vibration applications above 50 g.

At the probe tip, the ceramic-filled epoxy potting compound maintains dimensional stability from –35°C to +177°C. We have seen these probes survive steam turbine hot-section environments where ambient temperatures at the probe bracket exceed 140°C continuously. The coaxial cable jacket is rated for the same temperature range, and the BN connector is sealed to IP67 when mated — critical in wash-down environments and tropical climates where condensation is a daily reality.

Vibration immunity is built into the mechanical design. The probe body is a single machined stainless piece with no internal moving parts. There is nothing to fatigue, nothing to loosen, nothing to wear. The eddy-current sensing element itself has no contact with the target — mean time between failure in a properly gapped installation is measured in years, not months. When these probes do fail, it is almost always due to mechanical damage (contact with the shaft during a rub event) or cable damage, not electronic failure of the sensing element.

Every unit we ship from Xiamen undergoes a pre-shipment inspection: visual check of the probe tip and housing for mechanical damage, continuity check of the coaxial cable end-to-end, and a static gap voltage verification using a calibrated Proximitor driver. We do not ship units that fail any of these checks. If you receive a unit that does not perform to specification, contact us within 7 days — we will replace it, no questions asked.

Global Express Logistics

Our warehouse is in Xiamen, Fujian Province — one of China’s primary export hubs with direct access to DHL, FedEx, and UPS international gateways. For emergency orders confirmed before 14:00 CST, same-day dispatch is standard. Here is what the timeline looks like from your purchase order to your receiving dock:

• Order confirmation: Within 2 hours of inquiry during business hours (08:00–18:00 CST, Mon–Sat)
• Export documentation: Commercial invoice, packing list, and certificate of conformance prepared same day
• Customs clearance (China export): Typically 4–8 hours via our licensed freight forwarder
• Transit time — DHL Express: 2–3 business days to Southeast Asia, Middle East, Europe; 3–4 days to Americas
• Transit time — FedEx International Priority: Equivalent to DHL; carrier selection based on destination and rate
• Tracking: AWB number provided within 24 hours of dispatch; real-time tracking link shared via WhatsApp or email
• Import duties: Shipped DAP (Delivered At Place) as standard; DDP available on request for select destinations

For destinations with known customs delays (Brazil, India, Nigeria, Argentina), we proactively prepare additional documentation sets and can provide a customs broker referral in-country. We have shipped to 47 countries. We know where the friction points are, and we plan around them.

Packing is OEM-standard: anti-static foam insert, moisture barrier bag with desiccant, double-wall corrugated outer carton. The probe tip is protected by a machined plastic cap that stays on until installation. We have never had a probe arrive damaged in transit. We intend to keep that record.
