Bently Nevada 330101-15-40-10-02-00 Proximity Probe – 3300 XL Series

Bently Nevada 330101-15-40-10-02-00 — Eddy-Current Proximity Probe for Turbomachinery Shaft Monitoring

The 330101-15-40-10-02-00 is a non-contact eddy-current proximity probe from Bently Nevada’s 3300 XL 8mm Proximity Transducer System. This configuration encodes a precise mechanical and electrical specification: 15-inch (381 mm) probe body, 40-inch (1016 mm) armored integral extension cable, 10-32 UNF mounting thread, connector type 02, and option code 00 for standard output. Within the 3300 XL platform, this probe functions as the primary sensing element in a three-component measurement chain — probe, extension cable, and Proximitor® driver — that together deliver a calibrated DC voltage output proportional to the gap between the probe tip and the target shaft surface.

In a rotating machinery protection system, the proximity probe occupies the most critical position in the signal chain. It is the only component in direct proximity to the rotating element, operating continuously in environments characterized by elevated temperature, mechanical vibration, process fluid contamination, and electromagnetic interference. The 3300 XL 8mm probe is engineered to maintain measurement integrity under these conditions without mechanical contact, without wear, and without periodic recalibration under stable thermal conditions.

This part number is one of the most widely specified configurations in API 670-compliant machinery protection installations globally. It is deployed in radial vibration measurement channels on steam turbines, gas turbines, centrifugal compressors, and large rotating machinery in power generation, oil and gas, petrochemical refining, and industrial processing facilities. The 15-inch probe length accommodates standard bearing housing geometries, while the 40-inch armored extension cable provides the necessary routing distance from the bearing housing to the Proximitor® sensor mounted in a junction box or instrument enclosure.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The operating principle of the 330101-15-40-10-02-00 is based on the eddy-current effect: the Proximitor® driver energizes the probe coil at a fixed oscillation frequency (nominally 1.0 MHz for the 3300 XL 8mm system). When the probe tip is positioned within the linear range of a conductive target, the alternating magnetic field induces eddy currents in the target surface. These eddy currents create a counter-magnetic field that loads the probe coil, reducing its effective inductance and oscillation amplitude. The Proximitor® demodulates this amplitude change and outputs a DC voltage that is linearly proportional to the probe-to-target gap — decreasing voltage as the gap decreases.

The 8mm tip diameter is a deliberate design parameter. Smaller tip diameters reduce the effective sensing field diameter, which improves spatial resolution and reduces sensitivity to shaft surface irregularities such as runout caused by residual magnetism or surface finish variations. The 3300 XL 8mm probe achieves a balance between spatial resolution and signal-to-noise ratio that makes it suitable for both radial vibration (dynamic displacement) and static position (DC gap) measurement on shafts ranging from 50 mm to several hundred millimeters in diameter.

The armored integral extension cable is a coaxial assembly with a defined characteristic impedance matched to the Proximitor® driver input. The armor — typically stainless steel braid over a PTFE-insulated center conductor — serves two functions: mechanical protection against abrasion and crush loads in bearing housing environments, and electromagnetic shielding that maintains signal integrity against the high-frequency interference generated by variable-frequency drives, switchgear, and adjacent instrumentation cables. The cable termination at the Proximitor® end uses a precision connector that maintains the coaxial geometry to preserve the calibrated scale factor. Any substitution of non-OEM extension cables will alter the total cable capacitance and inductance, shifting the scale factor outside the ±1% tolerance required by API 670.

The probe body housing is constructed from 316 stainless steel, providing resistance to process fluid ingress and corrosion in wet gas, hydrocarbon, and steam environments. The epoxy-encapsulated coil assembly within the probe tip is hermetically sealed, preventing moisture absorption that would alter coil inductance and introduce measurement drift. The 10-32 UNF thread allows precise gap adjustment during installation using a standard probe holder and locknut assembly, with the thread pitch providing approximately 0.794 mm of axial travel per revolution — sufficient resolution for setting the nominal 1.0 mm (40 mil) installation gap specified in most OEM turbomachinery manuals.

EMC performance is achieved through the combination of the armored cable shield, the Proximitor® driver’s differential input architecture, and the inherently narrow-band nature of the eddy-current oscillator circuit. The system rejects common-mode interference on the cable shield while the oscillator’s high-Q resonant circuit attenuates out-of-band noise. This design allows the 3300 XL system to maintain measurement accuracy in environments with radiated field strengths up to 10 V/m across the 80 MHz to 1 GHz band, consistent with IEC 61000-4-3 Class III industrial immunity requirements.

System Integration Benefits

• Direct API 670 Compliance: The 330101-15-40-10-02-00 meets all transducer system requirements of API 670 5th Edition, including scale factor tolerance, frequency response, and temperature range — eliminating the need for third-party compliance verification during machinery protection system commissioning.
• Calibrated System Traceability: Bently Nevada calibrates the probe, extension cable, and Proximitor® driver as a matched system. The scale factor printed on the Proximitor® label is valid only for the specified cable length and probe model — this 40-inch cable configuration maintains the factory-calibrated 7.87 V/mm scale factor without field adjustment.
• Deterministic Frequency Response: The flat frequency response from DC to 10,000 Hz ensures that all vibration components within the measurement bandwidth — including sub-synchronous instabilities (oil whirl at 0.43–0.48×), synchronous (1×), and higher harmonics — are captured with equal amplitude fidelity, supporting accurate orbit plot generation in the 3500 monitoring system.
• Static and Dynamic Measurement in a Single Channel: The DC component of the probe output provides continuous shaft centerline position data, while the AC component carries dynamic vibration information. This dual-function capability allows a single probe channel to simultaneously monitor bearing clearance consumption and vibration amplitude — reducing channel count and wiring complexity.
• Plug-Compatible Replacement: The 330101-15-40-10-02-00 is a direct replacement for any existing 3300 XL 8mm probe with the same cable length configuration. No Proximitor® recalibration, no monitoring system reconfiguration, and no setpoint adjustment is required — reducing planned maintenance downtime to the time required for physical probe replacement and gap verification.
• Diagnostic Transparency via OK Circuit: The 3300 XL system includes an OK output on the Proximitor® driver that monitors probe and cable continuity. An open circuit or short in the probe or extension cable drives the OK output to a fault state, triggering a diagnostic alarm in the 3500 monitoring rack before the measurement channel is declared invalid — providing advance warning of sensor degradation rather than silent measurement loss.
• Thermal Stability Across Operating Range: The probe’s scale factor temperature coefficient is specified and compensated within the Proximitor® driver. Over the operating temperature range of the probe tip (–30°C to +177°C), scale factor variation is maintained within ±1% of nominal — ensuring that thermal transients during turbine startup and shutdown do not introduce false vibration readings that could trigger spurious trips.
• Compatibility with Bently Nevada System 1 Software: When connected to a 3500 Series rack, data from this probe channel is accessible in Bently Nevada System 1 condition monitoring software, enabling trend analysis, alarm management, and machinery diagnostics with full historical data retention — supporting predictive maintenance programs without additional hardware investment.

Quality Assurance & Global Logistics

Every unit of the 330101-15-40-10-02-00 supplied through siemensplc.com is sourced as genuine Bently Nevada (Baker Hughes) original equipment. We do not supply remanufactured, refurbished-as-new, or counterfeit instrumentation. Each unit is inspected upon receipt for packaging integrity, label authenticity, and physical condition. Original manufacturer documentation — including the calibration data sheet specifying the as-manufactured scale factor for the specific probe and cable combination — is retained and available upon request for critical instrumentation applications.

Our logistics operation is based in Xiamen, China, a major international port city with direct air freight connections to Singapore, Dubai, Frankfurt, Los Angeles, and Tokyo. Standard export documentation — commercial invoice, packing list, and certificate of origin — is prepared for every international shipment. For regulated industries requiring additional documentation (material certificates, test reports, or third-party inspection), these can be arranged prior to shipment. Typical dispatch time for in-stock units is 1–3 business days from order confirmation. Air freight transit times to major industrial hubs are 3–7 business days depending on destination and carrier selection. All shipments are tracked end-to-end with proactive status updates provided to the buyer.

A 12-month warranty is provided from the date of shipment, covering manufacturing defects under normal operating conditions. Warranty claims are processed with direct technical support from our engineering team, with replacement units dispatched upon fault confirmation to minimize machinery downtime.
