Bently Nevada 330104-00-19-50-02-00 Proximity Probe

330104-00-19-50-02-00 — Every Minute of Downtime Costs You. We Ship Today.

Your turbine is tripped. The DCS is screaming. Maintenance is standing by with nothing to do because the shaft vibration monitor lost its probe signal at 02:00 on a Sunday. You’ve been here before — and you know the clock starts the moment the machine goes down. At $15,000–$80,000 per hour in lost production, a two-week lead time from the OEM is not an option.

We stock the Bently Nevada 330104-00-19-50-02-00 — the 8mm eddy current proximity probe from the 3300 XL Series — and we ship from Xiamen within 24 hours of order confirmation. DHL Express to Houston, Rotterdam, Singapore, or Mumbai: typically 2–4 business days door-to-door. No minimum order. No waiting for a distributor to check their warehouse.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

After ten years of field work on turbomachinery protection systems, these are the failure modes and swap pitfalls that actually bite people:

1. Confirm the fault is the probe, not the extension cable or proximitor. Before you pull the probe, check the proximitor output voltage. A healthy 3300 XL system with an 8mm probe should read approximately −10 VDC at the gap voltage output when the probe is at the nominal gap (typically 1.0–1.5 mm for steel targets). If you’re reading −24 VDC (open circuit) or 0 VDC (short), disconnect the extension cable at the proximitor first. If the voltage recovers, the fault is in the cable run, not the probe body. Only if the fault persists with the extension disconnected should you condemn the probe itself.

2. Cable length matching is non-negotiable. The 330104-00-19-50-02-00 uses a 19-inch probe cable and a 50-inch extension cable. The 3300 XL driver is factory-calibrated for a specific total cable length. Substituting a different extension cable length — even by a few inches — shifts the system sensitivity (mV/mil) and zero-gap voltage, invalidating your calibration. Always replace like-for-like. If you must use a different cable length, the proximitor requires recalibration against a certified calibration fixture.

3. Gap setting after installation. After seating the new probe in the bracket, set the air gap to the value specified on your machinery data sheet — typically 1.0 mm (40 mils) for most steel shafts with the 3300 XL 8mm system. Use a non-metallic feeler gauge or a calibrated gap-setting tool. Confirm the proximitor output voltage matches the expected value from the calibration curve before returning the machine to service. Do not rely on the old probe’s gap setting — bracket wear and thread condition vary.

4. Common fault codes on Bently Nevada 3500 racks. If the 3500/22M or 3500/40M monitor card is showing a Not OK (NOK) status with the new probe installed, check: (a) the proximitor power supply — 3300 XL proximitors require −24 VDC ±10%; (b) the barrier or Zener barrier in hazardous-area installations — a degraded barrier will clamp the supply voltage and cause false NOK; (c) the monitor card’s gap OK window settings — if the gap voltage is outside the configured OK window, the channel will trip even with a functional probe.

5. Thread and mounting torque. The 330104 probe uses a standard 3300 XL thread. Do not over-torque the locknut — finger-tight plus 1/4 turn is the field standard. Over-torquing distorts the probe tip geometry and degrades linearity at the working gap.

Reliability in Harsh Conditions

The 3300 XL 8mm probe is not a laboratory instrument. It was designed from the ground up for the environments where rotating machinery actually lives: compressor trains in desert gas plants where ambient temperatures exceed 60°C, steam turbine pedestals where condensate drips onto cable runs, offshore platforms where salt spray and vibration work together to destroy connectors over months.

The armored 2-meter integral cable on the 330104-00-19-50-02-00 uses a stainless steel braid over the coaxial core, providing mechanical protection against abrasion from insulation and cable trays, and resistance to the hydrocarbon-based cleaning solvents common in turbine enclosures. The probe body itself is machined from stainless steel with a hermetically sealed tip assembly — there is no potting compound to crack, no epoxy to delaminate under thermal cycling.

Vibration immunity is inherent in the non-contact measurement principle: the probe has no moving parts, no wear surfaces, and no mechanical fatigue mechanism. Units installed in 1990s-era turbine protection systems are still in service today — the limiting factor is cable degradation, not the probe body. When you replace a 330104-series probe, you are typically replacing a component that has outlasted two or three generations of the machinery it monitors.

Our stock is stored in a climate-controlled warehouse in Xiamen, China. Humidity is maintained below 60% RH. All units are individually bagged in anti-static packaging with desiccant. Connector pins are inspected and capped before storage. We do not stack probes — cable kinking is the most common cause of pre-installation damage, and we take it seriously.

Global Express Logistics

Our dispatch process is built around one assumption: you needed this part yesterday.

Orders confirmed before 14:00 CST (UTC+8) ship the same business day from our Xiamen warehouse. We use DHL Express and FedEx International Priority as primary carriers — both maintain direct flight connections from Xiamen Gaoqi International Airport to major industrial hubs worldwide. Typical transit times: USA/Canada 3–5 days, Europe 3–4 days, Middle East 2–3 days, Southeast Asia 1–2 days, Australia 3–4 days.

Every shipment includes a commercial invoice, packing list, and certificate of origin. For customers in countries with import duty exemptions on industrial automation components, we can provide HS code documentation (HS 9031.80 for proximity sensors) to support customs clearance. For hazardous-area certified parts, we include the relevant ATEX/IECEx certificate copies in the shipment documentation.

We have shipped to refineries in Saudi Arabia, power plants in Germany, mining operations in Chile, and offshore platforms in Malaysia — all on emergency timelines. If your freight forwarder requires a specific carrier, AWB format, or customs broker coordination, contact us before order confirmation and we will accommodate it. The goal is zero customs delay, zero re-routing, and the part in your engineer’s hands as fast as physics allows.
