Bently Nevada 330881-BR-04-034-06-02 Proximity Transducer Assembly – PROXPAC XL

Bently Nevada 330881-BR-04-034-06-02 PROXPAC XL – Precision Shaft Displacement Measurement in Critical Rotating Machinery

The 330881-BR-04-034-06-02 is a factory-matched PROXPAC XL proximity transducer assembly manufactured by Bently Nevada (a Baker Hughes company). It integrates an eddy-current probe, a calibrated extension cable, and a Proximitor signal conditioning driver into a single pre-characterized system. This matched-set architecture eliminates the inter-component calibration variance that arises when probe, cable, and driver are sourced and assembled independently — a critical requirement in API 670-governed machinery protection installations where measurement uncertainty must remain within ±1% of full-scale range.

The assembly is designed for continuous, non-contact measurement of radial shaft vibration and static axial position in high-speed rotating machinery. Its eddy-current sensing principle operates without physical contact with the target shaft, producing a DC-coupled output voltage linearly proportional to the gap between probe tip and target surface. This allows simultaneous acquisition of both dynamic vibration waveforms (AC component) and static shaft centerline position (DC component) from a single transducer channel — a dual-function capability that reduces sensor count and simplifies rack wiring in 3500 Series monitoring systems.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The 330881-BR-04-034-06-02 operates on a resonant LC oscillator circuit embedded within the Proximitor driver. The oscillator drives a high-frequency electromagnetic field (typically 1–2 MHz carrier) through the probe coil. When a conductive target enters the field, eddy currents are induced on the target surface, loading the oscillator and attenuating its amplitude. The Proximitor demodulates this amplitude variation and converts it to a DC-coupled output voltage with a slope of 200 mV/mil — a transfer function that remains stable across the full operating temperature range due to the factory-matched calibration between probe inductance, cable capacitance, and driver gain coefficients.

EMC Design: The coaxial extension cable in the PROXPAC XL assembly uses a double-shielded construction with a drain wire bonded at the Proximitor end only (single-point grounding). This topology prevents ground-loop currents from injecting common-mode noise into the signal path — a frequent failure mode in installations where cable shields are grounded at both ends. The Proximitor housing incorporates a ferrite bead filter on the power supply input line, attenuating conducted interference in the 150 kHz–30 MHz band per IEC 61000-4-6 requirements.

Thermal Stability: The XL designation in the PROXPAC XL series indicates an extended-temperature probe coil winding using a high-temperature polyimide-insulated wire rated to 200°C continuous. The coil former is machined from PEEK (polyether ether ketone), which maintains dimensional stability to within ±0.01 mm across the full −35°C to +177°C range, preserving the probe’s inductance-gap characteristic and preventing sensitivity drift in hot bearing housings adjacent to steam turbine casings.

Cable Impedance Matching: The extension cable is manufactured to a controlled characteristic impedance matched to the probe coil’s resonant frequency. Substituting a non-matched cable — even of identical physical length — shifts the resonant frequency of the LC circuit, altering the sensitivity slope and introducing a non-linearity error that cannot be corrected by field calibration. The factory-matched PROXPAC XL assembly eliminates this risk by guaranteeing that probe, cable, and driver are characterized together on a calibration bench before shipment.

System Integration Benefits

• Direct 3500 Series Rack Compatibility: The 330881-BR-04-034-06-02 connects directly to the Bently Nevada 3500/40M Proximitor I/O module without signal conditioning adapters. The rack’s internal power supply delivers the −24 VDC bias, and the module’s A/D converter samples the output at up to 20 kHz per channel, supporting full-spectrum vibration analysis up to 10 kHz.
• Deterministic Real-Time Response: The Proximitor’s analog output has a group delay of less than 50 µs across the DC–10 kHz band, ensuring that transient shaft events — such as rub-impact impulses or blade-loss events — are captured without phase distortion that would corrupt orbit plot reconstruction in System 1 software.
• Dual-Variable Measurement from a Single Channel: The DC component of the output encodes static shaft position (gap), while the AC component encodes dynamic vibration amplitude and frequency. A single 3500/40M channel can simultaneously monitor both variables, reducing rack slot consumption by up to 50% compared to installations using separate position and vibration transducers.
• API 670 Alarm Setpoint Traceability: Because the assembly’s sensitivity is factory-certified at 200 mV/mil ±1%, alarm setpoints configured in the 3500 rack (e.g., 2.5 mil pp alert, 5.0 mil pp danger) directly correspond to physical shaft displacement without requiring field verification of the transducer gain — a mandatory audit requirement under API 670 Section 8.3.
• Diagnostic Transparency via Gap Voltage Monitoring: The Proximitor’s DC output at nominal gap (−10 VDC at 50 mil) provides a continuous health indicator for the probe-target gap. Gradual drift in this DC level — visible in System 1 trend plots — indicates bearing wear, shaft thermal growth, or probe fouling before vibration amplitude thresholds are reached, enabling condition-based maintenance scheduling.
• Reduced Commissioning Time: Factory-matched calibration data is supplied with each PROXPAC XL assembly on a calibration certificate traceable to NIST standards. This eliminates the field calibration step required when probe and driver are sourced separately, reducing commissioning time per measurement point by approximately 45–60 minutes.
• Interchangeability Without Recalibration: Replacement of a failed PROXPAC XL assembly with an identical part number restores the measurement channel to its original calibrated state without requiring rack reconfiguration or setpoint adjustment — a significant advantage during unplanned outages where minimizing downtime is the primary constraint.
• SIL-Capable Installation Support: When integrated into a 3500 Series rack configured for SIL 2 machinery protection per IEC 61511, the 330881-BR-04-034-06-02 contributes a probability of failure on demand (PFD) consistent with the overall safety instrumented function (SIF) target. Bently Nevada’s functional safety documentation package (available on request) provides the failure mode and effects analysis (FMEA) data required for SIL verification calculations.

Quality Assurance & Global Logistics

Every 330881-BR-04-034-06-02 unit dispatched from our Xiamen, China facility is sourced exclusively from Bently Nevada’s authorized distribution network. Each assembly arrives with its original factory calibration certificate, OEM packaging, and a traceable lot number. Prior to dispatch, our technical team performs the following verification protocol:

• Visual inspection against Bently Nevada OEM cosmetic and labeling standards — label font, part number format, and housing finish are cross-referenced against authenticated reference units
• Electrical continuity check on probe coil, extension cable shield, and center conductor
• Insulation resistance measurement: ≥ 100 MΩ at 500 VDC between shield and center conductor
• Bias voltage verification: Proximitor output at nominal gap confirmed within −24 VDC ±5%
• Sensitivity spot-check at two gap distances to confirm 200 mV/mil slope within ±2%
• Anti-static packaging with desiccant and humidity indicator card; outer carton rated for air freight vibration per ISTA 2A

Shipments from Xiamen reach major industrial hubs in Southeast Asia within 3–5 business days via DHL Express or FedEx International Priority. European and North American destinations are typically served within 5–7 business days. Export documentation — including commercial invoice, packing list, and EAR99 classification confirmation — is prepared in-house to prevent customs clearance delays. Emergency same-day dispatch is available for in-stock units when orders are confirmed before 14:00 CST.
