Bently Nevada 330901-00-90-05-02-05 Proximity Probe

330901-00-90-05-02-05 — Stop the Clock on Your Downtime. Ship Today.

Your turbine is down. The 3300 XL proximity channel is dead. Every hour that shaft sits idle costs you — in lost throughput, in penalty clauses, in the kind of pressure that makes plant managers age fast. You don’t need a brochure. You need the part, verified, boxed, and moving toward your site before end of business. That’s exactly what this listing is.

The Bently Nevada 330901-00-90-05-02-05 is a 5 mm eddy-current proximity probe from the 3300 XL Proximity Transducer System — the API 670 standard for rotating machinery protection. This configuration ships with a 5-metre extension cable, standard connector, and factory-matched calibration. It is a direct, zero-reconfiguration replacement for any existing 330901-00-90-05-02-05 installation. Plug it in, verify gap voltage, confirm sensitivity, and restart. No monitor reconfiguration. No DCS input remapping. No surprises.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Symptom: Monitor shows Not OK or gap voltage out of range on channel startup.
First check: measure DC gap voltage at the driver output with a calibrated DMM. For a 5 mm probe at nominal 1.0 mm gap, you should read approximately -10.5 VDC plus or minus 0.5 V. If you are reading rail voltage (-24 V) or near zero, the probe tip is either shorted to the shaft or the cable is open. Swap the probe first — it is the fastest field test.

Symptom: High 1X vibration reading immediately after probe swap, machine otherwise normal.
This is almost always a gap setting error. The 3300 XL 5 mm probe has a linear range of 0.25 to 2.25 mm. Set your initial gap to 1.0 to 1.5 mm (center of linear range). Use the driver DC output to confirm: -10 to -12 VDC at rest. If the reading is correct but 1X is still elevated, check for mechanical runout on the shaft at the probe location — the new probe is doing its job and revealing a pre-existing condition.

Symptom: Intermittent Not OK trips, probe reads correctly when checked statically.
Suspect the extension cable, not the probe. The 330901 series uses a matched probe-cable assembly. If the extension cable has been field-spliced or replaced with a non-matched cable, the system sensitivity will drift. The 330901-00-90-05-02-05 ships as a complete matched assembly — do not mix cables between probe serial numbers.

Replacement procedure (field-verified steps):

1. De-energize the driver. Confirm -24 VDC supply is isolated at the rack terminal.
2. Disconnect the extension cable from the driver input. Label the channel before disconnecting if multiple probes share the same housing.
3. Remove the probe from the bracket. Note the existing gap dimension with a feeler gauge and record it before removal.
4. Install the new 330901-00-90-05-02-05. Thread the probe to the same gap dimension as a starting point.
5. Re-energize the driver. Measure DC gap voltage. Adjust probe position until output is within -10 to -12 VDC (1.0 to 1.5 mm gap).
6. Lock the probe locknut. Verify gap voltage has not shifted after locking — probe tip can move slightly during locknut torque.
7. Confirm the 3500 monitor channel returns to OK status. Check that the vibration reading is within baseline for that machine at slow-roll.
8. Document the final gap voltage and probe serial number in the machine history file.

Driver compatibility note: The 330901 5 mm probe requires the 3300 XL 5 mm Driver (330180-series). Do not connect a 5 mm probe to an 8 mm or 11 mm driver — the sensitivity curves are incompatible and the monitor will report false readings without triggering a fault.

Target material caution: If your shaft is not AISI 4140 or equivalent carbon steel, the factory calibration does not apply. Stainless steel, titanium, or Inconel targets require field recalibration using the Bently Nevada calibration fixture. Skipping this step produces systematic measurement error — typically 10 to 25 percent sensitivity deviation — that will not be caught by the monitor self-diagnostics.

Reliability in Harsh Conditions

The 3300 XL Series was not designed for a clean lab. It was designed for the inside of a turbine bearing housing — where temperatures swing from ambient to 150 degrees C during startup, where the cable runs alongside high-current motor leads, and where the probe tip sits millimeters from a shaft spinning at 3,000 to 15,000 RPM. The 330901-00-90-05-02-05 reflects that design intent at every level.

The probe body is machined from stainless steel with a hermetically sealed tip assembly. The cable jacket is rated for continuous exposure to lubricating oils, hydraulic fluids, and the cleaning solvents used in turbine maintenance. The connector is a positive-locking design that resists vibration-induced loosening — a failure mode that has caused more spurious trips than actual probe failures in field experience.

EMI immunity is built into the cable shield construction. In installations adjacent to VFD-driven auxiliaries or high-current bus bars, the 3300 XL cable rejects induced noise that would corrupt a standard instrumentation cable. A noisy proximity signal produces false high-vibration alarms that operators learn to ignore — and then the real event gets ignored too. The shielding is a measurable specification verified during factory calibration, not a marketing claim.

Vibration resistance of the probe mounting hardware is consistent with API 670 requirements. The probe bracket and locknut assembly, when properly torqued, will not shift gap position under the vibration levels that would trigger a machine shutdown — meaning the probe will not introduce measurement drift as machine condition changes.

Global Express Logistics

Stock is held in Xiamen, China — a major international freight hub with daily DHL Express and FedEx International Priority departures. From the moment your order is confirmed and payment cleared, our warehouse team targets same-day or next-morning dispatch for in-stock items.

Typical transit times from Xiamen:

• Southeast Asia (Singapore, Thailand, Malaysia, Indonesia): 2 to 3 business days via DHL Express
• Middle East (UAE, Saudi Arabia, Qatar): 3 to 4 business days via FedEx International Priority
• Europe (Germany, Netherlands, UK, France): 4 to 5 business days via DHL Express Worldwide
• North America (USA, Canada): 4 to 6 business days via FedEx International Priority
• Australia and New Zealand: 3 to 5 business days via DHL Express

Every shipment includes full commercial invoice, packing list, and certificate of conformance. For destinations requiring import permits or specific HS code documentation, contact us before ordering — we handle export compliance daily and can advise on documentation requirements for your country customs authority.

For genuine plant emergencies, contact us directly via WhatsApp before placing the order. We can confirm real-time stock, arrange priority pick-and-pack, and coordinate with the freight carrier for the earliest available flight. We have shipped parts to active shutdown sites within 24 hours of first contact — it is not a standard service, but it is something we can do when the situation demands it.

Packaging is ESD-safe bag, foam-lined rigid box, moisture barrier sealed. The probe tip and connector are individually protected. We photograph every shipment before sealing — photos available on request for insurance or receiving inspection purposes.
