Bently Nevada 330904-00-25-10-02-00 Proximity Probe

330904-00-25-10-02-00 In Stock — Every Hour of Downtime Costs You Money. We Ship Today.

Your turbine tripped. The DCS is screaming. Maintenance is standing by and the only thing between you and restart is a proximity probe that failed at 3 AM. You’ve traced the fault to the Bently Nevada 330904-00-25-10-02-00 — a 25 mm eddy-current proximity probe in the 3300 NSv system. We have it. It ships from Xiamen within hours of order confirmation via DHL Express or FedEx International Priority. No waiting for factory lead times. No distributor runaround. Direct to your site.

This is not a grey-market substitute. Every unit we supply is 100% original Bently Nevada, sourced through verified channels with full traceability documentation. Calibration certificates ship with the unit. If your procurement team needs an export compliance declaration, we handle that too — same day.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Fault Scenario 1 — Monitor shows GAP voltage out of range (typically below −2V or above −18V): Before condemning the probe, check the extension cable first. The 330130/330140 extension cables are the most common failure point in high-vibration installations. Disconnect at the Proximitor junction, measure probe output directly. If GAP voltage normalises, replace the extension cable, not the probe. If it stays out of range with a known-good cable, the probe tip is damaged or the coil is open — replace the 330904-00-25-10-02-00.

Fault Scenario 2 — Intermittent 1X vibration spike, no process change: This is almost always a loose probe tip or a cracked probe body from thermal cycling. Torque spec on the probe locknut is 5.6 N·m (50 in-lb). Check it before pulling the probe. If the body shows any crack at the tip-to-cable transition, replace immediately — a failed probe in a turbine bearing housing is a machinery protection failure, not just an instrumentation fault.

Replacement Procedure (field-expedient):

• De-energise the Proximitor sensor (330180 NSv) before disconnecting the probe. Hot-swapping can damage the Proximitor input stage.
• Record the existing GAP voltage before removal — this is your baseline for the new probe setup. Target GAP: −10.0 VDC ±0.5 V for most 3300 NSv installations.
• Install the replacement 330904-00-25-10-02-00. Set probe-to-target gap to 1.0 mm (40 mil) using a feeler gauge at the shaft. This puts you in the centre of the linear range.
• Re-energise the Proximitor and verify GAP voltage. Adjust gap in 0.1 mm increments until GAP reads within spec. Do not rely on the monitor’s OK relay alone — verify with a calibrated voltmeter at the Proximitor output.
• Run the machine at low speed and confirm 1X amplitude and phase are consistent with historical baseline. A new probe with identical gap should reproduce baseline within ±5%.
• No firmware update or address configuration is required for the 330904 series — the probe is passive. All signal conditioning is in the Proximitor (330180). If the Proximitor was also replaced, verify the system sensitivity setting matches: 200 mV/mil for the 25 mm probe.

Common Mistake: Engineers sometimes install a 330903 (8 mm tip) as a temporary replacement. The 8 mm probe has a different linear range and sensitivity — the 3300 NSv monitor will not alarm correctly and you risk a missed trip. Only use the 330904-00-25-10-02-00 or a verified 25 mm NSv-compatible probe.

Reliability in Harsh Conditions

The 330904-00-25-10-02-00 was engineered for the environments where most sensors fail. The probe body is constructed from 316 stainless steel with a PEEK tip housing — chemically resistant to the lube oil, seal gas, and process condensate found in compressor and turbine bearing housings. The integral cable uses a fluoropolymer jacket rated to 200 °C continuous, with a stainless armour braid that handles the flex fatigue from machine vibration without cracking the insulation over time.

Vibration immunity is not a marketing claim here — the probe is designed to measure vibration, so it must be immune to the mechanical noise of its own mounting. The tip assembly is potted and hermetically sealed; there is no internal mechanical joint that can loosen under cyclic loading. Units are tested to IEC 60068-2-6 (sinusoidal vibration) and IEC 60068-2-64 (random vibration) as part of the 3300 NSv system qualification.

Humidity and condensation are handled by the fully sealed construction — IP67 at the probe body. In offshore and coastal installations where salt fog is a concern, the stainless housing provides adequate corrosion resistance. The cable connector (type 02) uses gold-plated contacts and a moisture-excluding boot; inspect and replace the boot if it shows cracking during any scheduled maintenance window.

High-temperature installations: the standard 330904-00-25-10-02-00 is rated to 177 °C at the probe tip. For steam turbine applications where bearing housing temperatures exceed this, specify the 330905 high-temperature variant. Do not attempt to use the standard probe above its rated temperature — the PEEK tip will deform and calibration will shift permanently.

Global Express Logistics

Our warehouse is in Xiamen, Fujian Province — one of China’s primary export hubs with direct access to DHL, FedEx, and UPS international gateways. For urgent orders, here is what the timeline looks like from the moment you confirm:

• Order confirmed before 14:00 CST: Same-day dispatch. DHL Express or FedEx International Priority label generated within 2 hours of payment confirmation.
• Transit to Southeast Asia: 1–2 business days door-to-door.
• Transit to Middle East / India: 2–3 business days.
• Transit to Europe: 2–4 business days.
• Transit to North America: 3–5 business days.
• Transit to South America / Africa: 4–7 business days depending on customs clearance.

Every shipment includes: commercial invoice with correct HS code (8543.70), packing list, calibration certificate, and where required, a Certificate of Origin. For ATEX-certified installations, we provide the original EU Declaration of Conformity documentation. Customs clearance support is available for shipments to markets with complex import procedures — contact us before ordering if your site is in a restricted or high-duty jurisdiction.

We do not use consolidation freight for urgent orders. Your probe ships in its own dedicated express consignment. The unit is packed in anti-static foam inside a rigid outer carton, with the probe tip protected by a machined plastic cap. Arrives ready to install.
