Bently Nevada 330905-00-21-10-02-CN Proximity Probe

330905-00-21-10-02-CN — Stop the Clock on Your Downtime

Every minute a turbine or compressor sits idle, the losses compound. A failed proximity probe shouldn’t be the reason your plant bleeds money. The Bently Nevada 330905-00-21-10-02-CN — 3300 NSv 8 mm eddy-current proximity probe, 21 cm body, 10 m extension, CN connector — is on our shelf in Xiamen right now. We’ve shipped this exact part to petrochemical plants, power stations, and LNG terminals across Asia, the Middle East, and Europe. Same-day dispatch is not a marketing line; it’s how we operate.

If your vibration monitor is throwing a Not OK or your DCS is logging erratic gap voltage, the probe or its cable is the first suspect. Don’t wait three weeks for an OEM lead time. Call us.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Fault symptom: Gap voltage out of range / NOT OK light on 3300/16 monitor
Before condemning the probe, measure DC gap voltage at the Proximitor output with a calibrated DMM. Nominal gap for this probe at 1.0 mm air gap is approximately −10.5 VDC. If you read −24 V (rail) or 0 V, the probe coil is open or shorted — replace the probe. If voltage is present but drifting, suspect the extension cable connector or the Proximitor itself.

Step-by-step replacement procedure:

1. Isolate the channel. Bypass or inhibit the trip logic on the 3300/16 or 3300/20 monitor before pulling the probe. Failure to do this will trigger a spurious machinery trip.
2. Record the existing gap. Note the installed gap (typically 1.0–1.5 mm for radial vibration probes). Use a feeler gauge or the gap voltage reading as reference. You will re-gap the new probe to the same value.
3. Disconnect the extension cable at the Proximitor. Label the cable before removal — CN connectors on multi-channel systems look identical.
4. Remove the probe from the bracket. Most 3300 NSv probes use a 3/8-24 UNF thread. Count the turns as you remove it so you can pre-set the new probe to approximately the same depth before fine adjustment.
5. Install the new 330905-00-21-10-02-CN. Thread in by hand, then adjust gap while monitoring Proximitor output voltage. Target: −10.5 VDC ±0.5 V at nominal gap. Lock the locknut to 20–25 N·m.
6. Verify total cable length. The 330180 NSv Proximitor is calibrated for a specific probe + extension cable total length. This unit ships with a 10 m extension. If your existing extension is a different length, the Proximitor calibration will be off — sensitivity error will result. Match total length or recalibrate the Proximitor.
7. Reconnect and verify. Power up the Proximitor, confirm gap voltage, check the monitor for OK status, and verify vibration reading against a known baseline (zero-speed runout or a reference reading from the other channel).
8. Remove the bypass/inhibit. Restore trip logic only after confirming stable readings.

Common fault codes on 3300/16 and 3300/20 monitors:

• NOT OK (red LED): Gap voltage outside −2 V to −18 V window. Check probe gap, cable continuity, and Proximitor power supply.
• Danger setpoint trip with no process change: Probe tip contamination (conductive debris, oil film on non-conductive buildup) or loose locknut causing probe migration. Clean tip or re-gap.
• High 1× vibration at startup only: Probe bracket resonance or thermal growth shifting the gap. Verify bracket rigidity and re-check gap at operating temperature.
• Erratic gap voltage after cable replacement: CN connector not fully seated or pin corrosion. Inspect and re-terminate if necessary.

Reliability in Harsh Conditions

The 3300 NSv probe series was not designed for a climate-controlled instrument room — it was built for the bearing housing of a 60 MW steam turbine running at 3,000 RPM in a coastal petrochemical plant. The 330905-00-21-10-02-CN reflects that design intent at every level.

The probe body is machined from stainless steel with a hermetically sealed coil assembly. The coil potting compound maintains dielectric integrity at continuous temperatures up to 120 °C, with short-term excursions to 150 °C tolerated without calibration shift. In high-vibration environments — compressor bearing housings where broadband vibration exceeds 50 g — the probe body and locknut assembly holds position without fretting, provided the locknut is torqued correctly.

Humidity and condensation are handled by the sealed construction. The CN connector, when mated and secured, provides IP67-equivalent ingress protection at the junction point. In offshore or coastal installations where salt-laden air accelerates corrosion, the stainless housing outperforms carbon steel alternatives by a significant margin. We have seen units pulled from service after eight years in a South China Sea platform application that still calibrated within factory tolerance.

The extension cable jacket is rated for continuous immersion in lubricating oil — a common condition in bearing housing installations where oil mist or splash is unavoidable. The cable’s flexibility at low temperatures (rated to −35 °C) prevents jacket cracking during cold-start maintenance in northern climates.

Global Express Logistics

Our warehouse is located in Xiamen, Fujian Province — one of China’s primary export hubs with direct access to DHL, FedEx, and UPS international gateways. For urgent plant shutdowns, we operate a same-day cut-off: orders confirmed and paid before 15:00 CST ship the same afternoon.

Typical transit times from Xiamen:

• Southeast Asia (Singapore, Thailand, Malaysia, Indonesia): 2–3 business days via DHL Express
• Middle East (UAE, Saudi Arabia, Qatar, Kuwait): 3–4 business days via FedEx International Priority
• Europe (Germany, Netherlands, UK, France): 4–5 business days via DHL Express Worldwide
• North America (USA, Canada): 4–6 business days via FedEx International Priority
• Australia / New Zealand: 3–5 business days via DHL Express
• South Asia (India, Pakistan, Bangladesh): 3–5 business days via DHL or FedEx

All shipments include a commercial invoice, packing list, and certificate of origin. For customers requiring customs clearance support, we provide HS code documentation and can prepare a detailed technical description for customs authorities. Dangerous goods classification does not apply to this product — no special handling surcharges.

For plant shutdowns where every hour counts, contact us directly on WhatsApp for real-time stock confirmation and an immediate proforma invoice. We do not put urgent orders in a queue.
