Bently Nevada 991-06-50-02-01 Proximity Probe

991-06-50-02-01 Shaft Monitor Down — Every Hour of Blind Running Costs More Than This Probe

The alarm is latched. Gap voltage is railed. Your rotating equipment is running blind or tripped offline, and the maintenance window you didn’t plan for is already eating into production. The Bently Nevada 991-06-50-02-01 is an 8 mm eddy current proximity probe assembly from the 3300 XL series — the industry standard for shaft radial vibration and position measurement on turbines, compressors, and pumps governed by API 670. When this part fails, there is no workaround. You need the exact replacement, and you need it moving toward your site today.

We hold the 991-06-50-02-01 in stock at our Xiamen warehouse. Confirmed orders placed before 15:00 CST ship same day via DHL Express or FedEx International Priority — no broker, no cross-dock, no delay. Transit to Singapore, Rotterdam, Houston, or Abu Dhabi runs 2–4 business days. That is the difference between a controlled restart and an extended forced outage.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Step 1 — Isolate the fault before you pull anything. Connect a calibrated gap simulator directly to the proximitor input. If the output tracks correctly, the fault is in the probe or extension cable. If the proximitor still reads Not OK with a known-good simulator, swap the 330180-series proximitor first — you may not need the 991-06-50-02-01 at all. Misdiagnosis on a machinery protection system is expensive.

Common field fault signatures for a failed 991-06-50-02-01:

• Gap voltage railed to −24 VDC: Open circuit. Check the probe-to-extension cable junction first — connector corrosion and cable jacket crush at conduit entry points are the leading causes in high-vibration installations.
• Gap voltage at 0 VDC: Short circuit. Inspect the armored cable for mechanical damage. Steam-washed environments frequently drive moisture into the probe tip, producing this exact symptom.
• Noisy output, correct average gap: Partial coil damage or intermittent cable fault from thermal cycling fatigue. Replace the complete probe-cable assembly — field splicing is not an option on a safety-critical measurement loop.
• Correct gap voltage, elevated 1× vibration amplitude: Probe is functional. Investigate shaft runout, target surface condition, or probe holder looseness before ordering a replacement.

Replacement Field Checklist:

• ☐ Machine de-energized and locked out per site LOTO procedure.
• ☐ Record existing gap voltage and physical gap (feeler gauge or depth micrometer) — this is your reinstallation reference.
• ☐ Remove probe using correct spanner on 3/8-24 UNF thread. Never grip the cable jacket.
• ☐ Inspect probe holder bore for corrosion, thread damage, and debris. Clean with lint-free cloth.
• ☐ Install 991-06-50-02-01 hand-tight first, then torque to 1.1–1.4 N·m (verify against current Bently Nevada installation manual for your revision).
• ☐ Set physical gap to mid-range: 1.0 mm ± 0.05 mm → target gap voltage approximately −10.0 VDC ± 0.5 VDC.
• ☐ Confirm the complete system — probe, extension cable, and proximitor — are all 3300 XL matched. Mixing 3300 XL and legacy 3300 components without recalibration introduces scale factor errors. The rack will accept the signal; your vibration amplitude readings will be wrong.
• ☐ After energizing, verify gap voltage is within the linear range: −2 VDC to −18 VDC. Values outside this window indicate incorrect gap or a system mismatch.
• ☐ Perform static calibration check if your machinery protection system requires a post-maintenance functional test per API 670 Section 9.

Rack Configuration After Replacement: The 991-06-50-02-01 is a passive sensing element — no DIP switches, no firmware, no addressing. All configuration lives at the proximitor and the 3500 monitoring rack. After installation, confirm: transducer type set to 3300 XL 8mm; scale factor confirmed at 200 mV/mil (not the legacy 3300 series 100 mV/mil value); alert and danger setpoints reviewed against the new probe’s actual gap voltage to prevent nuisance trips on first startup.

Reliability in Harsh Conditions

The 991-06-50-02-01 is not a controlled-environment instrument. It is designed to run continuously in the worst locations on your plant — bolted to a steam turbine casing, submerged in lube oil mist, exposed to daily washdowns, and subjected to the broadband vibration spectrum of the machine it is protecting.

The armored extension cable resists degradation from turbine lube oil, seal gas condensate, and steam without jacket breakdown over multi-year service intervals. The probe body handles the full −35 °C to +177 °C operating envelope — from cryogenic LNG booster compressors to high-pressure steam turbine casings where the probe tip sees sustained elevated casing temperatures. The sealed probe tip construction blocks moisture-induced coil resistance drift that causes false Not OK alarms and nuisance trips in tropical, coastal, and offshore installations.

The integral armored cable design eliminates the field-assembled connector junction that is the single most common failure point in aftermarket proximity probe assemblies. Plants in Southeast Asia, West Africa, and the Gulf of Mexico consistently report multi-year service intervals on properly installed 3300 XL assemblies without recalibration — a direct result of the sealed, factory-terminated construction of the 991-06-50-02-01.

Vibration immunity is built into the mechanical design, not added as an afterthought. The probe body and cable assembly withstand the high-frequency structural resonances that fatigue-crack poorly designed sensor mounts within a single operating cycle. When you install a 991-06-50-02-01, you are not scheduling the next replacement — you are restoring the protection margin your machine was designed to operate with.

Global Express Logistics

Our Xiamen export operation is built around a single objective: your critical spare on a plane the same day you confirm the order.

• Order cutoff: 15:00 CST for same-day dispatch on in-stock items.
• Carriers: DHL Express Worldwide and FedEx International Priority — direct Xiamen pickup, no domestic relay leg.
• Typical transit: Southeast Asia 1–2 days | Middle East 2–3 days | Europe 2–4 days | North America 3–5 days | Australia 2–3 days.
• Documentation: Commercial invoice, packing list, certificate of origin, and MSDS (where applicable) included with every shipment. EAR99 classification — no export license required for most destinations.
• Customs: HS Code 9031.80 (precision measuring instruments). Accurate declared values and complete documentation prepared to prevent customs holds. DDP terms available on request for select destinations.
• Tracking: Waybill number sent via email and WhatsApp within 2 hours of dispatch.
• Emergency freight: For AOG-equivalent industrial emergencies, contact us directly on WhatsApp for hand-carry or charter freight options.
