EPRO PR6423/010-040-CN Proximity Probe

PR6423/010-040-CN In Stock Xiamen — Machine Down? We Cut Your Restart Time, Not Corners

The vibration monitor tripped. The NOT OK relay is open. Your PR6424 driver is reading a dead probe — coil resistance gone, gap voltage collapsed, machine locked out. Every hour that turbine or compressor sits idle is a number someone in finance is already calculating. You do not need a catalogue. You need a unit on a plane today.

We hold verified EPRO PR6423/010-040-CN stock in Xiamen. Not a broker promise, not a warehouse allocation that evaporates when you call to confirm. Physical units, bench-checked, packed and ready. Orders confirmed before 14:00 CST leave the same business day via DHL Express or FedEx International Priority. Transit to Europe, the Middle East, Southeast Asia, and North America runs 2–5 business days depending on routing. That is the only timeline that matters right now.

The PR6423/010-040-CN is an 8 mm eddy current proximity probe designed for continuous non-contact measurement of shaft radial vibration and axial position on rotating machinery. It is the sensing element in the EPRO PR6424 proximitor system and is dimensionally and electrically interchangeable with Bently Nevada 3300 XL 8 mm installations when the driver is configured to match. API 670 compliant. CE marked. ATEX/IECEx documentation available on request for Zone 1 and Zone 2 hazardous area installations.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

What follows is not a manual excerpt. These are the failure patterns that show up repeatedly in the field — the ones that waste time when you do not recognize them fast enough.

Fault 1 — Gap Voltage Out of Window, Coil Resistance Abnormal
At a nominal 1.0 mm air gap, the PR6423/010-040-CN should produce –10.5 V to –11.5 V DC at the PR6424 output. Full linear stroke spans –10 V to –18 V. If the gap is mechanically correct and the voltage sits outside that band, measure coil resistance at the MIL-C-5015 connector. Nominal is 8–12 Ω. Open circuit indicates a fractured winding — mechanical strike or severe cable pull event. A dead short points to insulation breakdown from sustained overtemperature. Neither condition is recoverable in the field. Condemn the probe, log the failure mode, and initiate the replacement order.

Fault 2 — Intermittent NOT OK That Clears When the Cable Moves
This is fretting corrosion on the MIL connector pins, not a probe failure. It is the dominant fault mode in offshore, coastal, and tropical installations where humidity cycles are severe. Clean the pins with isopropyl alcohol and electrical contact cleaner, re-seat the connector with positive engagement, and observe for 30 minutes under normal operating vibration. If the fault returns, move to the probe body. Do not disturb the air gap before ruling out the connector — re-gapping adds 20–40 minutes to your restart and is unnecessary if the probe is healthy.

Fault 3 — Single Shorted Probe Triggering Multi-Channel NOT OK
A shorted coil places a low-impedance load on the shared –24 V supply rail. When multiple channels draw from that rail, one failed probe can pull the supply voltage below the driver threshold and trigger NOT OK on adjacent healthy channels. The symptom looks like a driver or power supply fault. Isolate by disconnecting the suspect probe at the driver terminal block. If the rail recovers, the coil is shorted. Before energizing with the replacement, inspect the driver’s input protection circuit — a sustained short can damage the input clamp components and create a second failure on the new probe.

Fault 4 — Elevated Noise Floor or Erratic Vibration Amplitude After Cable Extension
Total cable length — integral 1.0 m plus extension cable — must match the PR6424 driver’s calibration jumper setting. Standard PR6424 variants have a cable-length jumper: J1 for 5 m total, J2 for 9 m total. A mismatch detunes the oscillator and degrades scale factor accuracy by up to 15%, producing false vibration amplitude readings and potentially incorrect trip setpoints. Verify extension cable length and confirm the jumper position before condemning the probe for noise.

Replacement Sequence — Step by Step

• De-energize the PR6424 driver before disconnecting the probe. Hot-swapping under live –24 V can spike the monitor input card and trigger nuisance trips on adjacent channels.
• Record the pre-removal gap voltage from the driver output. Your target after installation is within ±0.2 V of that baseline — faster than re-gapping from scratch with a feeler gauge.
• Thread the replacement probe into the API 670 boss and torque to 2.5 N·m. Over-torquing fractures the ceramic tip housing. Under-torquing allows probe walk under sustained vibration.
• No DIP switch, channel address, or firmware parameter is required on this probe — all calibration data resides in the PR6424 driver. If you are simultaneously replacing the driver, set the cable-length jumper before energizing.
• After power-up, allow 30 seconds for the oscillator to stabilize. Confirm the OK relay energizes and gap voltage is within specification before releasing the machine to operations.

Reliability in Harsh Conditions

The PR6423/010-040-CN is not a controlled-environment instrument. It is specified and built for the conditions that exist inside turbine halls, compressor skid enclosures, and offshore platform machinery spaces — where temperature, vibration, moisture, and electromagnetic interference are not edge cases but the baseline operating environment every shift.

The IP67-rated probe body handles pressurized water jets, steam condensate, and the oil mist that saturates bearing housings on continuous-duty rotating equipment. The stainless steel armored integral cable resists abrasion from cable tray edges and the broadband electromagnetic interference generated by variable frequency drives and motor control centers operating at full load within meters of the probe installation point.

Probe tip temperature tolerance reaches +120 °C continuous — covering the majority of bearing housing installations on industrial steam turbines and gas compressors without thermal standoff brackets or derating calculations. Coil geometry is engineered for low thermal drift: scale factor variation stays within ±1% across the full –50 °C to +120 °C operating range. Trip setpoints remain valid through seasonal temperature swings without scheduled recalibration intervals.

Vibration endurance is qualified to 20 g broadband per IEC 60068-2-64. Units pulled from continuous service after five or more years in petrochemical and power generation plants routinely pass bench verification against original factory calibration data. The PR6423 platform carries genuine design margin — a probe that earns its place in API 670-compliant machinery protection systems and holds it through the full service interval.

Global Express Logistics

Xiamen is a tier-1 international air freight hub with daily DHL Express and FedEx International Priority departures to every major industrial region. From confirmed purchase order to your plant gate, every step is tracked and documented.

• Order cut-off: 14:00 CST. Confirmed orders before that time are picked, packed in ESD-safe anti-static bags inside foam-lined export cartons, and handed to the carrier the same business day.
• DHL Express Worldwide: Europe, Middle East, Southeast Asia, and Australia in 2–4 business days. Live tracking active within 4 hours of dispatch.
• FedEx International Priority: Preferred routing for North America — 3–5 business days with streamlined US Customs clearance and proactive exception management.
• Shipment documentation: Commercial invoice, packing list, HS code 8543.70 pre-declared, Certificate of Conformance, and original EPRO datasheet included in the shipment envelope. No post-delivery paperwork chase.
• Critical shutdown situations: Contact us directly on WhatsApp for courier-on-demand options when standard express transit is not fast enough. Same-day courier handoffs for plant shutdown emergencies are a routine part of what we do.

Tracking numbers are sent within 2 hours of dispatch. If customs requires additional documentation, we handle the response directly so your engineering team stays focused on the plant restart, not on freight administration.
