Lenze C30GAC00000F3G0XXX-02S3C300000 Motion Controller – C300 Series

Lenze C30GAC00000F3G0XXX-02S3C300000 — Multi-Axis Motion Controller in the C300 Platform Architecture

The Lenze C30GAC00000F3G0XXX-02S3C300000 is a configurable multi-axis motion controller belonging to the Lenze C300 platform — a modular, scalable control architecture designed for deterministic real-time motion sequencing in industrial drive systems. Within a control loop, this unit occupies the role of the central motion coordinator: it receives setpoint trajectories from the supervisory PLC or HMI layer, executes interpolation and axis synchronization algorithms internally, and transmits torque/velocity references to downstream servo drives via a synchronous fieldbus cycle. The C300 controller’s internal processing pipeline is built around a dual-core ARM Cortex-A architecture with a dedicated real-time co-processor, enabling cycle times as low as 250 µs for position-controlled axes without offloading computation to an external master.

The SKU suffix structure — C30G / AC00000 / F3G0 / XXX / 02S3 / C300000 — encodes the hardware configuration: communication interface selection (EtherCAT master, CANopen, or PROFIBUS DP), safety option level (STO/SS1/SLS up to SIL 2 / PLd), firmware variant, and I/O expansion slot population. The XXX field represents a configurable option block; buyers must confirm the exact variant code against their bill of materials prior to procurement to ensure fieldbus and safety function compatibility.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

Backplane Bus Architecture & Axis Synchronization: The C300 controller communicates with downstream Lenze i550/i650 inverter drives and ECS servo drives via a synchronous EtherCAT master stack embedded directly in the controller firmware. The EtherCAT distributed clock (DC) mechanism locks all slave devices to a common reference time with a jitter of < 1 µs across the network, which is the physical basis for the deterministic multi-axis synchronization the platform advertises. The controller’s real-time co-processor handles the EtherCAT frame scheduling independently of the application CPU, preventing application-layer latency spikes from propagating into the motion cycle.

EMC Design & Galvanic Isolation: The 24 V DC logic supply rail is galvanically isolated from the fieldbus transceivers and the digital I/O interface via DC/DC converters and optocoupler barriers rated at 500 V AC isolation voltage. This isolation topology prevents ground-loop currents — common in large panel installations with multiple drive cabinets — from coupling noise into the controller’s signal processing chain. The PCB layout follows IEC 61800-3 Category C2 guidelines, with separate ground planes for analog reference, digital logic, and chassis earth, joined at a single star point.

Functional Safety Subsystem: The integrated safety processor operates on a separate execution domain from the motion application CPU. Safety function requests (STO, SS1, SLS) are processed through a dual-channel hardware path with cross-comparison logic, conforming to the diagnostic coverage requirements of IEC 62061 SIL 2. The safety subsystem maintains its own watchdog timer and will de-energize the STO output independently of the application CPU state — meaning a software fault in the motion application does not compromise the safety shutdown path.

Memory Architecture: The controller provides non-volatile FLASH storage for the user application program and retain variables, with a battery-backed SRAM region for fast-access retain data that survives power cycles without FLASH write latency. This architecture is significant for applications requiring sub-second restart after power interruption, such as conveyor synchronization systems where axis position data must be preserved across unplanned shutdowns.

System Integration Benefits

• Deterministic EtherCAT Cycle: The embedded EtherCAT master with distributed clock synchronization delivers axis-to-axis jitter below 1 µs, enabling electronic gearing and cam profiling without mechanical coupling hardware.
• Unified Engineering Environment: Lenze EASY Engineer software provides a single workspace for drive parameterization, IEC 61131-3 PLC programming, motion function block configuration, and safety validation — reducing commissioning time compared to multi-tool workflows.
• Scalable Axis Count: The EtherCAT topology supports up to 32 synchronized axes from a single C300 controller, allowing machine builders to scale from 2-axis test rigs to 32-axis production lines without changing the control architecture.
• Integrated Diagnostic Transparency: The controller exposes axis-level diagnostic data — following error, actual torque, thermal load, and fieldbus cycle overrun counters — via the EtherCAT CoE object dictionary, accessible from any standard EtherCAT master diagnostic tool without proprietary software.
• SIL 2 Safety Without External Safety PLC: Integrated STO/SS1/SLS functions eliminate the need for a separate safety relay module or safety PLC for basic machine guarding, reducing panel BOM cost and wiring complexity.
• IEC 61131-3 Portability: Application programs written in Structured Text or Function Block Diagram are portable across Lenze C300 hardware variants and compatible with third-party IEC 61131-3 runtimes, protecting software investment across machine generations.
• Multi-Protocol Flexibility: Support for EtherCAT, CANopen, and PROFIBUS DP within the same hardware platform allows the controller to integrate into existing plant networks without gateway hardware, reducing network latency and single-point-of-failure risk.
• Retain Variable Architecture: Battery-backed SRAM for retain variables enables sub-second warm restart after power interruption, preserving axis position data and production counters without requiring a full home cycle after every power event.
• Thermal Derating Monitoring: The controller continuously monitors its internal thermal state and provides a pre-warning output before reaching the thermal shutdown threshold, allowing the supervisory system to execute a controlled stop rather than an emergency trip.
• Firmware Update via USB/SD: Field firmware updates are performed via USB or SD card without requiring a laptop or engineering software connection, reducing service time in remote installations.

Quality Assurance & Global Logistics

Every Lenze C30GAC00000F3G0XXX-02S3C300000 unit supplied through siemensplc.com is sourced from verified distribution channels with full traceability to Lenze SE’s authorized supply chain. Each unit undergoes a structured incoming inspection covering label authenticity, firmware version verification, connector and housing integrity, and packaging seal condition before being accepted into stock.

Our warehouse is located in Xiamen, China — a major logistics hub with direct access to international freight carriers including DHL Express, FedEx International Priority, UPS Worldwide Express, and TNT. Standard dispatch for in-stock units is within 1–2 business days of order confirmation. International shipments are accompanied by a commercial invoice, packing list, and HS code documentation (HS: 8537.10.91) to facilitate customs clearance in the EU, North America, Southeast Asia, the Middle East, and other major import markets.

A 12-month warranty from the date of shipment covers manufacturing defects and functional failures under normal operating conditions. Units that do not match the advertised part number or exhibit defects upon arrival are eligible for return or replacement. Certificate of conformity and traceability documentation are available upon request for quality-system audit purposes.
