Mitsubishi FX1S-30MT-001 PLC Module – MELSEC FX1S Series

FX1S-30MT-001: 30-Point Transistor Output PLC for Deterministic Discrete Control

The Mitsubishi Electric FX1S-30MT-001 is a self-contained main unit within the MELSEC FX1S platform, integrating 18 DC sink/source inputs and 12 NPN transistor outputs into a 150 mm wide DIN-rail body. Designed for OEM machine builders operating under strict panel-space budgets, this unit delivers a deterministic scan cycle, battery-free program retention, and dual-axis pulse output — all without requiring an expansion rack or external power supply for the logic section. Its architecture reflects Mitsubishi Electric’s approach to embedding motion-adjacent capability directly into the base CPU, reducing component count in single-axis and dual-axis positioning applications.

In the control loop, the FX1S-30MT-001 occupies the role of the primary execution engine: it samples field signals through its 18 optically isolated DC inputs, resolves the ladder or SFC program stored in EEPROM, and drives output actuators through 12 transistor channels rated at 0.5 A per point. The RS-422 programming port provides a synchronous communication path to GX Works2 for online monitoring, forced I/O, and data register inspection without interrupting the scan cycle. This architecture makes the unit suitable for conveyor sequencing, packaging machinery, HVAC control panels, injection molding sequencing, and compact pick-and-place cells where scan-time predictability directly affects product quality.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

Optical Isolation Architecture on DC Inputs: Each of the 18 input channels passes the field signal through a dedicated photocoupler before it reaches the CPU data bus. The isolation barrier sustains a minimum of 500 VDC between the field wiring and the logic section, suppressing common-mode transients generated by inductive loads — contactors, solenoid valves, and motor starters — that share the same 24 VDC rail. The software-adjustable input filter (0–60 ms per point) allows the engineer to trade noise immunity for response speed on a per-channel basis: high-speed encoder channels can be set to 0 ms while pushbutton inputs retain a 10 ms debounce window.

Transistor Output Stage and Flyback Protection: The 12 NPN transistor outputs use discrete power transistors rather than relay contacts, eliminating mechanical wear and enabling switching frequencies up to 100 kHz on the designated pulse channels (Y0, Y1). Each output channel incorporates an internal flyback diode across the load terminals, clamping inductive kickback from solenoid coils to within the transistor’s safe operating area. The 0.5 A per-point rating with an 0.8 A common limit requires the engineer to verify that the sum of simultaneously active outputs within each common group does not exceed the common rating — a constraint that must be addressed during I/O assignment in GX Works2.

EEPROM Program Storage and Battery-Free Retention: Program data, device comments, and parameter settings are stored in on-board EEPROM with a rated write endurance of 10,000 cycles. Unlike SRAM-backed CPUs that require a lithium backup battery, the FX1S-30MT-001 retains its program indefinitely without battery maintenance. Data registers designated as latched (D512–D7999 in the FX2N address map, subset applicable to FX1S) retain values through power cycles via the same EEPROM mechanism, eliminating the risk of data loss from battery depletion in remote or unattended installations.

High-Speed Counter and Pulse Output Co-Architecture: The six high-speed counter channels (C235–C255) operate on dedicated hardware interrupt logic, decoupled from the main scan cycle. Single-phase counters accept up to 60 kHz input frequency; two-phase (A/B quadrature) counters operate at up to 30 kHz. The two pulse output channels (Y0, Y1) share the same high-speed hardware path, generating PULSE/DIR or CW/CCW signals at up to 100 kHz for direct stepper driver interfacing. The co-location of high-speed counter inputs and pulse outputs within the same CPU eliminates the latency introduced by a separate motion controller communicating over a fieldbus — a measurable advantage in single-axis positioning loops where position error correction must occur within one scan cycle.

EMC Design and Noise Immunity: The FX1S-30MT-001 meets EN 61131-2 electromagnetic compatibility requirements. The internal power supply uses a switching topology with common-mode chokes on the AC input lines, attenuating conducted emissions below CISPR 11 Class A limits. The PCB layout separates the high-frequency switching section from the analog reference circuits using a split ground plane, and the chassis ground terminal provides a low-impedance path to the DIN rail for capacitively coupled high-frequency noise. These measures allow the unit to operate in environments with variable-frequency drives and welding equipment on the same panel without requiring additional external filtering.

System Integration Benefits

• Deterministic Scan Execution: The FX1S CPU executes a fixed-priority scan — input refresh, program execution, output refresh — with a typical scan time of 0.55 µs per basic instruction. For a 2,000-step program, worst-case scan time remains under 5 ms, providing a predictable control loop period that simplifies PID tuning and motion profile design.
• Zero-Battery Field Maintenance: EEPROM-based program and latch data retention removes the battery replacement interval from the preventive maintenance schedule, reducing lifecycle cost in installations with 5–10 year service expectations.
• Integrated Dual-Axis Pulse Output: Two independent 100 kHz pulse channels allow simultaneous control of two stepper axes without an external motion card, reducing panel wiring complexity and BOM cost by eliminating a dedicated positioning module.
• Software-Configurable Input Filtering: Per-channel filter adjustment from 0 to 60 ms allows a single hardware platform to serve both high-speed encoder counting and low-speed pushbutton inputs without external RC filter networks.
• GX Works2 Online Diagnostics: The RS-422 port supports online program monitoring, device value forcing, and execution trace without halting the CPU. Engineers can inspect data register values, timer/counter current values, and I/O status in real time during commissioning, reducing fault-finding time.
• Right-Side Expansion Compatibility: Up to 8 FX2N-series expansion modules (analog I/O, additional digital I/O, communication adapters) connect via the right-side expansion bus, extending the system to a maximum of 128 I/O points without replacing the CPU or rewiring the power supply.
• Universal AC Power Input: The 100–240 VAC wide-range power supply accepts both 110 VAC (North American) and 220 VAC (European/Asian) mains without hardware modification, simplifying global machine deployment and spare-parts standardization.
• Interrupt-Driven Event Response: Six interrupt inputs (I000–I050) trigger dedicated interrupt service routines with a response latency of 0.2 ms, enabling time-critical event handling — emergency stop processing, registration mark detection — independent of the main scan cycle length.
• Compact Panel Footprint: At 150 mm width and 90 mm height, the FX1S-30MT-001 occupies less than half the panel space of a comparable 30-point relay output unit with separate power supply, freeing space for drives, circuit breakers, and terminal blocks in 300 mm or 400 mm wide enclosures.
• Standardized Programming Environment: Full compatibility with GX Works2 and GX Developer allows engineering teams to reuse existing ladder logic libraries, function block templates, and comment databases across FX1S, FX3U, and iQ-F platform projects, reducing new-project programming time.

Quality Assurance & Global Logistics

Every FX1S-30MT-001 unit supplied by siemensplc.com is sourced as genuine Mitsubishi Electric hardware. Units are inspected upon receipt: label authenticity, production date code, firmware version, and physical condition are recorded before the unit enters stock. A power-on functional test verifies input response, output switching, and RS-422 communication integrity prior to dispatch. Original Mitsubishi Electric packaging and documentation are supplied where available; units without original packaging are repackaged in anti-static foam-lined cartons with desiccant.

Shipments originate from our warehouse in Xiamen, China — a major logistics hub with direct access to DHL Express, FedEx International Priority, and UPS Worldwide Expedited services. Standard transit times are 3–5 business days to Europe, 4–6 business days to North America, and 2–3 business days to Southeast Asia. Export documentation — commercial invoice, packing list, and certificate of origin — is prepared in compliance with destination country import requirements. EXW Xiamen and CIF destination port Incoterms are both available. For orders requiring expedited customs clearance, our logistics team coordinates with the freight forwarder to pre-file entry documentation. All units ship with a 12-month warranty covering manufacturing defects and functional failure under normal operating conditions.
