SST SST-PFB-CLX PROFIBUS Scanner Module – ControlLogix Series

SST-PFB-CLX: PROFIBUS DP Master/Slave Scanner for Allen-Bradley ControlLogix Backplane

The SST-PFB-CLX is a single-slot PROFIBUS DP scanner module engineered for direct installation into Allen-Bradley ControlLogix 1756-series chassis. It operates as a Class 1 DP Master or DP Slave, bridging the ControlLogix backplane to a PROFIBUS DP field network at baud rates from 9.6 kbps up to 12 Mbps. The module handles all cyclic data exchange autonomously — polling up to 125 slave nodes per scan cycle — while exposing structured I/O data tables to the ControlLogix controller via the 1756 backplane interface. This architecture decouples fieldbus timing from the PLC scan cycle, preserving deterministic ladder execution regardless of PROFIBUS network load.

In a typical process or discrete manufacturing control loop, the SST-PFB-CLX sits between the ControlLogix CPU and the PROFIBUS DP field layer. The CPU writes output data to a mapped memory region; the scanner autonomously transmits that data to the addressed slave nodes within the configured PROFIBUS cycle time. Incoming slave diagnostic and process data are written back to the input data table before the next PLC scan reads them. This producer/consumer model eliminates polling overhead from the CPU scan and allows the PROFIBUS network to sustain its own deterministic cycle independent of PLC task scheduling.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The SST-PFB-CLX implements a dedicated PROFIBUS DP protocol stack on an embedded microcontroller that is physically isolated from the ControlLogix backplane logic. This dual-processor architecture is the foundation of its deterministic behavior: the onboard PROFIBUS controller manages token-ring arbitration, GSD-file-defined slave parameterization, and cyclic data exchange entirely within its own execution context. The ControlLogix CPU interacts with the module only through a shared dual-port RAM (DPRAM) interface on the backplane, reading and writing structured data blocks without any awareness of the underlying PROFIBUS timing.

The RS-485 physical layer driver incorporates galvanic isolation between the PROFIBUS cable segment and the module’s internal logic. This isolation barrier — typically rated at 500 V DC — prevents ground loop currents from propagating into the ControlLogix chassis, a critical design requirement in industrial environments where field devices and control cabinets share different ground potentials. The differential RS-485 transceiver provides common-mode rejection of up to ±7 V, maintaining signal integrity on cable runs up to 1,200 m at 93.75 kbps or 200 m at 1.5 Mbps.

EMC hardening is achieved through a combination of hardware filtering on the RS-485 input stage and the module’s metal faceplate, which bonds directly to the 1756 chassis ground rail. This shielding path provides a low-impedance return for high-frequency interference coupled onto the PROFIBUS cable shield, attenuating conducted emissions before they reach the backplane. The module meets EN 61000-4-2 (ESD), EN 61000-4-4 (EFT/Burst), and EN 61000-4-6 (conducted RF immunity) without requiring external suppression components.

Slave parameterization is stored in non-volatile flash memory on the module. On power-up, the SST-PFB-CLX autonomously re-parameterizes all configured slaves using the stored GSD data before the ControlLogix CPU completes its own initialization sequence. This means the PROFIBUS network reaches a fully operational state before the PLC program begins executing, eliminating the startup race condition that can occur when parameterization is handled by ladder logic.

System Integration Benefits

• Backplane-native installation: Occupies a standard 1756 slot with no external power supply, gateway hardware, or additional wiring — reducing panel footprint and eliminating an external failure point.
• Autonomous cyclic exchange: The onboard PROFIBUS controller maintains its own scan cycle independent of the ControlLogix task scheduler, ensuring field device data is refreshed at a consistent rate regardless of PLC program complexity or task overrun conditions.
• Dual master/slave mode: A single module can be configured as either a DP Master Class 1 or a DP Slave, enabling flexible topologies such as inter-PLC PROFIBUS links or integration into a higher-level DCS as a slave node.
• GSD-file-based parameterization: Full compatibility with standard GSD files from any PROFIBUS DP slave vendor eliminates proprietary configuration dependencies and simplifies multi-vendor field device integration.
• Structured diagnostic transparency: Slave diagnostic data — including station status bytes, module status, and channel-level fault codes — is mapped directly into the ControlLogix input data table, making fault localization available to the PLC program without additional polling logic.
• Baud rate auto-detection: The module automatically negotiates the network baud rate on startup, reducing commissioning time and eliminating manual baud rate configuration errors on mixed-speed networks.
• Non-volatile configuration storage: Network configuration and slave parameterization are retained in onboard flash memory, allowing the module to restart and re-establish the PROFIBUS network without host CPU intervention after a power cycle.
• Broad chassis compatibility: Operates in all 1756 chassis variants — 1756-A4 through 1756-A17 — including ControlLogix-XT extended-temperature chassis, covering both standard and harsh-environment deployments.
• AOI and ladder library support: SST provides Add-On Instructions (AOIs) and structured text function blocks for RSLogix 5000 / Studio 5000, accelerating application development and standardizing the programming interface across projects.
• Firmware field-upgradeable: Module firmware can be updated via the backplane without physical removal, reducing maintenance downtime and enabling compatibility updates as ControlLogix chassis firmware evolves.

Quality Assurance & Global Logistics

Every SST-PFB-CLX unit supplied by siemensplc.com is sourced through verified distribution channels and subjected to a structured incoming inspection process before dispatch. Physical inspection covers connector integrity, faceplate condition, label authenticity, and board-level visual examination for counterfeit indicators including non-standard component markings and irregular solder profiles. Firmware revision is verified against the official SST/Molex release matrix to confirm the unit carries a production-release build rather than a pre-production or field-modified image.

Functional verification includes a powered backplane insertion test in a reference 1756 chassis, confirming that the module enumerates correctly, passes its internal self-test sequence, and establishes a valid PROFIBUS DP master state with a loopback slave configuration. Units that pass all inspection stages are packaged in anti-static bags with humidity indicator cards, placed in rigid foam-lined cartons rated for international air freight handling.

Dispatch is from Xiamen, China, with DHL Express, FedEx International Priority, and UPS Worldwide Express available as standard shipping options. Transit times to major industrial hubs — Frankfurt, Chicago, Singapore, Dubai — are typically 3 to 5 business days under normal customs clearance conditions. Commercial invoice, packing list, and certificate of conformance are included with every shipment. For volume orders, sea freight consolidation and bonded warehouse staging are available on request. All units carry a 12-month warranty covering manufacturing defects and functional failure under normal operating conditions.
