ABB 3HNA021587-001 Robot Battery Module

ABB DSQC508 Battery Backup Unit 3HNA021587-001 — Stop the Clock on Your Downtime

Your IRC5 controller just threw a low-battery alarm. The FlexPendant is flashing. Production is stopped. Every minute costs money — and you already know that a dead DSQC508 means lost SRAM data, corrupted program offsets, and a full re-teach if you wait too long. This page exists for exactly that moment.

We stock the ABB DSQC508 Battery Backup Unit (primary PN: 3HNA021587-001/03, cross-ref: 3HAC025562-001-06 / 3HAC5393-2) in Xiamen, China. Same-day dispatch on confirmed orders. DHL Express to most destinations in 2–4 business days. No waiting on ABB’s standard lead time. No broker markup. Direct from verified OEM stock.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Ten years of field calls on IRC5 lines teach you the same patterns. Here is what actually matters when you are standing in front of the cabinet:

Fault Code 38026 — Battery Voltage Low: This is your first warning. You have a window — typically 48–72 hours before SRAM data is at risk. Do not ignore it and do not power-cycle the controller until the new DSQC508 is installed. A cold boot with a dead battery wipes the calibration data stored in the main computer’s SRAM, and you are looking at a full axis calibration job.

Fault Code 38027 — Battery Voltage Critical / 38028 — Battery Failure: At this stage the controller may refuse to start or will start with a blank program. If you are already here, pull the FlexPendant backup immediately before cutting power. Go to ABB Menu → Backup & Restore → Backup and save to USB. Then replace the DSQC508.

Replacement Procedure (IRC5 Single Cabinet):

1. Confirm the controller is in Manual mode and motors are OFF. Do not power down — keep the cabinet energized during swap if possible; the DSQC508 is hot-swappable on most IRC5 revisions (verify your main computer firmware version first).
2. Open the cabinet door. The DSQC508 is mounted on the main computer board (DSQC639 or DSQC1000 depending on revision), typically in the upper-left quadrant of the electronics bay.
3. Disconnect the two-pin Molex connector. Note the orientation — it is keyed but field-worn connectors can be forced incorrectly.
4. Slide the battery module out of its retention bracket. Do not use metal tools near the board.
5. Insert the new DSQC508. Reconnect the Molex. Verify the LED on the main computer returns to steady green within 30 seconds.
6. Clear fault codes via Event Log → Clear All. Perform a warm restart. Confirm SRAM data integrity by checking program pointer and tool data.

Firmware Matching: The DSQC508 itself carries no firmware — it is a passive power module. However, if you are also replacing the main computer (DSQC639 / DSQC1000), ensure the RobotWare version on the new board matches the existing system. Mismatched RobotWare versions will cause a system failure on boot even with a healthy battery.

Dual Cabinet Note: In IRC5 Dual Cabinet configurations, each cabinet has its own main computer and its own DSQC508. Replace both units simultaneously during a planned maintenance window — staggered replacement leaves one cabinet vulnerable.

Shelf Life Advisory: Lithium batteries self-discharge at approximately 2–3% per month. If your spare has been sitting in the tool crib for more than 18 months, test it before relying on it. We ship fresh stock with manufacture date documentation on request.

Reliability in Harsh Conditions

IRC5 controllers are deployed in environments that would destroy consumer electronics in days. The DSQC508 is engineered to survive alongside them.

In automotive BIW lines, the battery module endures continuous vibration from press operations and spot-welding impulses transmitted through the cabinet frame. ABB’s mounting bracket design isolates the cell from direct mechanical shock, but the connector and PCB traces are the weak points — which is why OEM units with proper solder joint specifications matter. Aftermarket equivalents frequently fail at the connector interface within 6–12 months in high-vibration cells.

Foundry and die-casting environments push ambient temperatures well above 40°C during peak production. The DSQC508’s lithium chemistry is rated for continuous operation up to 55°C. Beyond that threshold, capacity degrades rapidly and replacement intervals should be shortened to 24 months rather than the standard 36–60 months ABB recommends in temperate environments.

In coastal and humid manufacturing zones — common across Southeast Asia and southern China — condensation inside cabinets is a real failure driver. The DSQC508’s conformal-coated PCB provides a baseline moisture barrier, but if your cabinet door seals are compromised, no battery module will survive long. Check door gaskets during every planned maintenance visit.

Each unit we ship has been stored in climate-controlled conditions (18–25°C, RH <60%) and packed in anti-static ESD bags with foam-lined cartons per IEC 61340-5-1. We do not ship from uncontrolled warehouse environments.

Global Express Logistics

Our dispatch hub is in Xiamen, Fujian Province — one of China’s primary export ports with direct DHL Express and FedEx International Priority connections. Here is how a typical urgent order moves:

Day 0 (Order Confirmed Before 14:00 CST): Unit pulled from climate-controlled stock, inspected, packed with commercial invoice, packing list, and Certificate of Origin. MSDS and UN38.3 test report included for air freight lithium battery compliance — no customs delays from missing documentation.

Day 0–1: Handed to DHL Express or FedEx International Priority. Tracking number sent to your email within 2 hours of pickup scan.

Day 2–4 (Most Destinations): Delivery to Europe (Germany, Netherlands, UK, Poland), North America (USA, Canada, Mexico), and major Asian hubs (Singapore, South Korea, Japan, India). Remote destinations may require 5–6 days.

Customs Clearance: We declare accurately. HS Code 8507.60, value as invoiced. We do not under-declare to save you duty — that creates delays and legal exposure. If your plant requires a formal import permit for lithium batteries, notify us at order time and we will prepare the supplementary documentation package.

Emergency Air Freight: For multi-unit urgent orders where standard express is not fast enough, we can arrange charter air freight consolidation from Xiamen Gaoqi International Airport. Contact us directly to discuss.

We have shipped to 47 countries. We know the documentation requirements. We will not let paperwork be the reason your line stays down.
