Allen-Bradley 1715-TASOF8 Redundant Analog Output Module – ControlLogix 1715 Series

Allen-Bradley 1715-TASOF8: Redundant Analog Output Architecture for High-Availability Process Control

The Allen-Bradley 1715-TASOF8 is an 8-channel redundant analog output module engineered for the Rockwell Automation 1715 Redundant I/O platform. It operates as a primary/secondary hardware pair within the 1715 backplane, delivering continuous 4–20 mA or ±10 V output signals to field devices even during a module-level fault. The architecture is purpose-built for process industries where output signal interruption translates directly into unplanned downtime, product loss, or safety incidents.

Unlike standard ControlLogix analog output modules that rely on controller-level redundancy alone, the 1715-TASOF8 implements hardware-level output redundancy at the I/O tier. Both the primary and secondary modules drive their output DACs simultaneously; the field terminal assembly (FTA) arbitrates which module’s signal reaches the field wiring. This design eliminates the single point of failure inherent in simplex analog output architectures and reduces mean time to repair (MTTR) by allowing hot-swap module replacement without process interruption.

The module communicates with the ControlLogix controller via the 1715-AENTR EtherNet/IP redundant adapter, which maintains dual-path network connectivity. Tag data, diagnostic status, and module health are all surfaced natively in Studio 5000 Logix Designer, enabling engineers to monitor output channel health, calibration drift flags, and redundancy state from within the standard programming environment without additional middleware.

In oil and gas wellhead control, the 1715-TASOF8 governs valve positioner signals where a loss of output would require manual intervention in a hazardous area. In power generation, it drives turbine governor actuators where output continuity is a grid-stability requirement. In pharmaceutical bioreactor control, it maintains precise temperature and pH dosing setpoints under FDA 21 CFR Part 11 audit environments. Across all these verticals, the module’s value proposition is identical: deterministic output delivery with transparent diagnostics and zero-interruption maintenance capability.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

DAC Architecture and Output Fidelity: Each of the eight output channels employs an independent 16-bit digital-to-analog converter. At 16-bit resolution, the LSB step size across a 20 mA span is approximately 0.305 µA — sufficient for valve positioner control loops where fine resolution directly affects process stability. The DAC reference voltage is internally regulated and temperature-compensated, limiting gain drift to a specified band across the 0–60 °C operating range. This matters in outdoor enclosures or non-climate-controlled MCC rooms where ambient temperature variation is a real operating condition.

Optical Isolation and EMC Design: The 1715-TASOF8 implements optical isolation between the backplane logic domain and the field output circuitry. This galvanic barrier prevents ground loop currents — common in large industrial plants with distributed earthing — from corrupting the DAC reference or introducing offset errors into the output signal. The isolation barrier also attenuates common-mode transients generated by variable-frequency drives, contactors, and high-current switching equipment operating in the same panel or cable tray. The module’s PCB layout follows IEC 61000-4 series immunity requirements, with filtered power supply inputs and shielded signal traces on the output stage.

Redundancy Arbitration Logic: The FTA (Field Termination Assembly) contains the arbitration circuit that selects between the primary and secondary module outputs. Under normal operation, both modules receive identical setpoint data from the controller and drive their DACs to the same output value. The FTA continuously monitors the health status broadcast by each module over the 1715 backplane. On detection of a primary module fault — whether a DAC failure, power supply dropout, or communication loss — the FTA switches field wiring to the secondary module’s output within the specified failover window. Because both modules were already tracking the same setpoint, the transition is bumpless: the field device sees no step change in the analog signal.

Hot-Swap Capability: The 1715 backplane supports live module insertion and removal. When a faulted primary module is replaced, the new module synchronizes its DAC output to the current setpoint before the FTA re-enables it as the active output. This synchronization sequence prevents the output bump that would otherwise occur if a freshly powered module started from a default or last-stored value. The synchronization handshake is managed by the 1715-AENTR adapter firmware and requires no operator intervention in Studio 5000.

Diagnostic Transparency: Each channel reports open-circuit detection, over-range conditions, and DAC health status as individual bits in the module’s input data table. These bits are accessible as standard Logix tags and can be mapped directly into HMI faceplates or alarm management systems without custom ladder logic. The module also reports its own power supply voltage and internal temperature, enabling predictive maintenance workflows based on actual hardware telemetry rather than fixed time-based replacement schedules.

System Integration Benefits

• Zero-interruption module replacement: Hot-swap capability allows a faulted module to be replaced during live process operation. The secondary module maintains field output continuity throughout the swap, eliminating the need for a process shutdown or manual bypass.
• Native Studio 5000 integration: The 1715-TASOF8 is fully supported by Rockwell Automation’s Add-On Profile (AOP) framework. Module configuration, channel scaling, and diagnostic mapping are performed within the standard Logix Designer project tree — no separate configuration utility or third-party driver required.
• Deterministic EtherNet/IP scan cycle: The 1715-AENTR adapter delivers I/O data to the controller on a configurable Requested Packet Interval (RPI). For tight control loops, RPIs as low as 1 ms are achievable on a properly segmented EtherNet/IP network, ensuring that setpoint updates reach the DAC within a predictable time window.
• Scalable redundancy topology: The 1715 platform supports mixed I/O configurations. A single 1715-AENTR adapter can host multiple 1715-TASOF8 pairs alongside analog input, digital I/O, and HART modules, allowing engineers to apply hardware redundancy selectively to the most critical loops without redesigning the entire I/O architecture.
• ATEX Zone 2 certification: The module carries ATEX II 3 G certification, permitting installation in Zone 2 hazardous areas without an additional intrinsic safety barrier for the module itself. This simplifies panel design in offshore, refinery, and chemical plant environments where Zone 2 classification is common in the instrument room.
• Alarm management integration: Per-channel diagnostic bits map directly to ISA-18.2 alarm management frameworks. Engineers can configure rationalized alarms for open-circuit faults, redundancy loss, and DAC degradation without writing custom diagnostic rungs, reducing alarm engineering time during FAT and SAT phases.
• Reduced spare parts inventory: Because the 1715-TASOF8 operates as a matched pair, a single spare module covers both primary and secondary positions. Maintenance teams do not need to stock separate primary and secondary variants, simplifying spare parts management in remote or offshore facilities.
• Long-term platform support: Rockwell Automation maintains the 1715 platform with firmware updates, PCDC compatibility matrices, and technical support. Specifying the 1715-TASOF8 in a new project provides a documented upgrade path and avoids the obsolescence risk associated with discontinued or grey-market I/O platforms.

Quality Assurance & Global Logistics

Every 1715-TASOF8 unit shipped from our Xiamen, China facility is sourced through verified supply channels and subjected to a multi-stage inspection protocol before dispatch. Visual inspection confirms label integrity, housing condition, and the absence of re-marking or counterfeit indicators. Functional power-on testing verifies that the module enumerates correctly on the 1715 backplane and that all eight output channels respond to DAC commands within specification. Serial number traceability is maintained for each unit, and documentation is available on request for customers operating under IEC 62443 or FDA 21 CFR Part 11 audit requirements.

Shipments are dispatched from Xiamen via DHL Express, FedEx International Priority, or UPS Worldwide Expedited, with typical transit times of 3–5 business days to Europe, North America, and Southeast Asia. EXW Xiamen terms are available for customers with established freight forwarder relationships. All export documentation — including commercial invoice, packing list, and certificate of origin — is prepared in compliance with destination country import requirements. HS code classification is provided for customs clearance. A 12-month replacement warranty covers manufacturing defects and confirmed functional failures from the date of shipment.
