Allen-Bradley 1746-P3 PLC Power Supply – SLC 500 Series

Allen-Bradley 1746-P3 — Regulated Backplane Power Supply for SLC 500 Modular Control Systems

The Allen-Bradley 1746-P3 is a dedicated switching-mode power supply engineered for the SLC 500 modular chassis family (1746-A4, A7, A10, A13). Its primary function within a control loop is to deliver stable, regulated DC power to the chassis backplane and the field-device user power bus simultaneously, ensuring that processor scan cycles and I/O module response times remain deterministic regardless of AC mains fluctuation. Unlike general-purpose DIN-rail PSUs, the 1746-P3 integrates directly into the chassis backplane connector, eliminating external wiring between the power source and the logic bus — a design choice that reduces impedance on the +5 VDC rail and minimizes conducted noise injection into the processor’s memory subsystem.

In a typical SLC 500 control loop, the 1746-P3 occupies the leftmost dedicated slot of the chassis. The processor (5/01 through 5/05) and all I/O modules draw +5 VDC logic power from the backplane bus. Field sensors, solenoid valves, and discrete input circuits draw +24 VDC from the user power bus, which the 1746-P3 supplies at up to 0.96 A continuous — nearly double the capacity of the predecessor 1746-P2 (0.46 A). This headroom is critical in dense I/O configurations where multiple 2-wire proximity sensors or 4–20 mA transmitters share the same user power rail.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The 1746-P3 employs a flyback switching topology operating at a fixed high-frequency switching rate, which allows the transformer core to be significantly smaller than an equivalent linear supply while maintaining tighter output regulation across the full 85–265 VAC input window. The universal input range is achieved through a power-factor-corrected front-end rectifier stage that maintains a near-unity power factor at rated load, reducing reactive current demand on the plant distribution panel — a measurable benefit in facilities with undersized branch circuits.

EMC Design: The module incorporates a multi-stage common-mode and differential-mode filter on the AC input line. A toroidal common-mode choke attenuates high-frequency noise conducted from the switching stage back onto the mains, while X- and Y-class capacitors suppress differential-mode transients. On the DC output side, low-ESR bulk capacitors and ferrite bead filters on each output rail suppress switching ripple to levels below the SLC 500 processor’s noise immunity threshold, which Rockwell specifies at ±5% of nominal rail voltage.

Backplane Bus Architecture: The +5 VDC backplane rail is the sole logic power source for the SLC 500 processor and all installed I/O modules. The 1746-P3 connects to the backplane via a dedicated edge connector that carries both power and the chassis ground reference. The supply’s internal regulation loop monitors the +5 VDC rail at the backplane connector point — not at the output terminals — ensuring that voltage drop across the backplane traces is compensated in real time. This remote-sense architecture maintains ±2% regulation at the point of load regardless of backplane current distribution.

Fault Isolation Logic: An internal comparator circuit continuously monitors all three output rails. If any rail deviates beyond its regulation window (typically ±5% for +5 VDC, ±10% for +24 VDC), the supply asserts a Power Fail signal on the backplane bus. The SLC 500 processor samples this signal at the beginning of each scan cycle; upon detection, it executes a controlled program halt and sets the major fault bit in the status file (S:1/13), preserving the last-known output state and enabling deterministic fault recovery without data corruption in the processor’s data table.

Thermal Management: The 1746-P3 uses a passive convection-cooled heatsink integrated into the module housing. The switching regulator’s efficiency at full load (typically 78–82%) limits internal heat generation to approximately 22–28 W, which the heatsink dissipates within the 0–60 °C ambient envelope without forced airflow. This eliminates fan-related failure modes in environments with particulate contamination — a common concern in woodworking, cement, and grain-handling facilities.

System Integration Benefits

• Direct Backplane Integration: The 1746-P3 connects to the SLC 500 chassis backplane via a dedicated edge connector, eliminating external DC wiring between the power supply and logic bus. This reduces installation labor and removes a potential point of connection failure in high-vibration environments.
• Deterministic Scan-Cycle Power Stability: The regulated +5 VDC rail maintains ±2% at the backplane point of load, ensuring that processor scan time jitter attributable to supply voltage variation remains below 0.1 ms — a requirement for motion control and high-speed counting applications using the SLC 5/04 or 5/05.
• Expanded Field Device Budget: The 0.96 A user power bus supports up to 19 standard 50 mA 3-wire PNP proximity sensors simultaneously, compared to 9 sensors on the 1746-P2. This eliminates the need for an external 24 VDC auxiliary supply in moderate-density I/O panels.
• Universal AC Input for Global Deployment: The 85–265 VAC wide-range input allows a single hardware configuration to operate on 100 VAC (Japan), 120 VAC (North America), 220 VAC (Europe/China), and 240 VAC (Australia/UK) mains without transformer or jumper changes, simplifying global machine variants.
• Integrated Power-Fail Signaling: The Power Fail output on the backplane bus gives the SLC 500 processor approximately 1–3 ms of advance warning before the +5 VDC rail collapses below the processor’s minimum operating voltage. This window is sufficient for the processor to execute a controlled shutdown routine and set output states to a defined safe condition.
• Over-Current Protection on All Rails: Independent current-limiting circuits on the +5 VDC, +24 VDC, and −5 VDC rails prevent a fault on one rail from propagating to others. A shorted field device on the user power bus does not affect backplane logic power, maintaining processor operation and enabling fault diagnostics while the field fault is isolated.
• Passive Cooling for Harsh Environments: The absence of internal cooling fans eliminates a common failure mode in dusty or humid industrial environments. The convection-cooled design is rated for continuous operation at 60 °C ambient, covering the majority of industrial panel enclosure temperature profiles without derating.
• Drop-in Replacement Compatibility: The 1746-P3 shares the identical mechanical form factor, backplane connector pinout, and terminal block layout with all 1746-P series power supplies. Replacement requires only AC mains reconnection — no chassis modification, no program change, and no I/O module removal.
• Diagnostic Transparency via Status LED: The front-panel Power Good LED provides immediate visual confirmation of supply health during commissioning and maintenance. Loss of the LED under load indicates an overload or internal fault condition, directing maintenance personnel to the correct subsystem without requiring a laptop or programming software.

Quality Assurance & Global Logistics

Every 1746-P3 unit dispatched from our Xiamen, China facility is sourced directly from authorized distribution channels and undergoes a structured pre-shipment verification protocol. Visual inspection confirms housing integrity, label legibility (catalog number, series letter, date code), connector pin condition, and the absence of burn marks, corrosion, or evidence of prior repair. Each unit is then subjected to a functional power-on test: AC mains are applied at both 120 VAC and 220 VAC, and all three DC output rails are measured under a representative resistive load to verify regulation within published tolerances. The series letter and date code are recorded in the shipment documentation and disclosed to the buyer.

Packaging follows IEC 61340-5-1 ESD protection guidelines: each module is sealed in a conductive anti-static bag, cushioned with closed-cell foam inserts, and placed in a double-wall corrugated carton rated for international air freight. For orders of five or more units, individual cartons are consolidated into a master carton with desiccant packs to control humidity during ocean or air transit.

Logistics from Xiamen to major global destinations: DHL Express typically delivers to Western Europe in 3–5 business days, to North America in 4–6 business days, and to Southeast Asia in 2–3 business days. FedEx International Priority and UPS Worldwide Express are available as alternatives. All shipments include a commercial invoice, packing list, and certificate of origin. Import HS code documentation is provided on request to facilitate customs clearance. A 12-month warranty covers manufacturing defects and verified functional failures under normal operating conditions.
