Bently Nevada 135613-01 Case Expansion Transducer – 3300/3500 Series

Bently Nevada 135613-01: High-Temperature Case Expansion Transducer in Turbine Machinery Protection Systems

The Bently Nevada 135613-01 is a high-temperature case expansion transducer assembly engineered for continuous differential expansion measurement in steam turbines, gas turbines, and large-frame rotating machinery. Differential expansion — the relative axial displacement between a turbine rotor and its casing — is a critical protection parameter under API 670. When thermal gradients cause the rotor to expand faster or slower than the casing, the resulting gap change can lead to blade-to-seal contact, catastrophic rub events, or forced outage. The 135613-01 provides the continuous, high-resolution position signal that allows the 3300/3500 Series monitor rack to enforce trip and alarm setpoints before mechanical damage occurs.

Unlike standard proximity transducers that operate within ambient or mildly elevated temperature envelopes, the 135613-01 is rated for the elevated thermal environment immediately adjacent to turbine casings, where surface temperatures routinely exceed the limits of conventional LVDT or eddy-current probe assemblies. The armored cable assembly and high-temperature extension cable are integral to the design, maintaining signal integrity across the full thermal gradient from the hot casing surface to the cooler junction box or monitor rack input.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

Eddy-Current Sensing Architecture Under Thermal Stress

The 135613-01 operates on the eddy-current (inductive proximity) principle. The probe tip contains a wound coil driven by a high-frequency oscillator within the Bently Nevada driver/oscillator module. When the conductive turbine casing target surface enters the probe’s electromagnetic field, eddy currents are induced, loading the coil and reducing oscillation amplitude. The driver converts this amplitude change into a DC voltage output — typically in the –24 VDC supply range — with a linear relationship between gap distance and output voltage across the calibrated measurement range.

Thermal Compensation and Cable Integrity

Standard proximity transducer assemblies use RG-58 or equivalent coaxial cable, which degrades rapidly above 120 °C. The 135613-01 replaces this with a high-temperature dielectric cable construction, maintaining stable characteristic impedance and minimizing capacitive variation across the thermal gradient. Capacitive variation in the extension cable directly shifts the oscillator’s operating point, introducing a DC offset error in the gap measurement. By controlling cable capacitance per unit length within tight tolerances at elevated temperatures, the 135613-01 preserves the factory calibration curve without field recalibration.

EMC Design and Shielding

The armored outer jacket provides both mechanical protection and a continuous Faraday shield, attenuating radiated electromagnetic interference from adjacent high-voltage switchgear, variable-frequency drives, and bus bars common in turbine hall environments. The shield is grounded at a single point — typically at the monitor rack chassis — to prevent ground loop currents that would appear as low-frequency noise on the DC output signal. This single-point grounding topology is consistent with Bently Nevada’s system-level EMC architecture across the 3300/3500 platform.

Mechanical Assembly and Mounting Geometry

The probe body is threaded for installation into a mounting bracket welded or bolted to the turbine casing. The bracket positions the probe tip at the nominal gap distance — typically 1.0 mm to 2.5 mm — from the target surface machined into the turbine shaft or thrust collar. The assembly’s rigid probe body minimizes vibration-induced gap variation that would otherwise appear as false differential expansion signal. The armored cable exits the probe body at a defined bend radius to prevent kinking under thermal cycling of the casing.

System Integration Benefits

• Direct API 670 compliance: The 135613-01 is designed to satisfy API 670 requirements for differential expansion measurement, eliminating the need for additional engineering justification when used in new or retrofit machinery protection installations.
• Zero-recalibration drop-in replacement: Factory calibration is performed against the same driver/oscillator used in the 3300/3500 monitor rack. Replacing a failed transducer with a new 135613-01 restores the original calibration curve without field adjustment, reducing maintenance window duration.
• Deterministic alarm and trip response: The DC voltage output is continuously sampled by the 3300/3500 monitor at its internal scan rate. There is no polling latency or protocol overhead — the monitor responds to a trip-level gap change within its hardware response time specification, typically under 20 ms for voted trip logic.
• Diagnostic transparency via System 1: When connected to a 3500 rack interfaced with Bently Nevada System 1 software, the 135613-01’s output is trended, alarmed, and archived at the process historian level. Engineers can review historical differential expansion profiles to identify slow thermal drift, bearing wear, or alignment shifts before they reach trip thresholds.
• Compatibility with redundant voting architectures: The 3500/45 Position Monitor supports 1oo2, 2oo3, and other voting configurations. Multiple 135613-01 assemblies can be installed at the same measurement plane to provide redundant inputs, allowing one transducer to be removed for inspection without forcing a process shutdown.
• Reduced false-trip risk: The high-temperature cable construction eliminates the thermally induced impedance drift that causes false alarm or trip events in standard transducer assemblies installed in hot zones. This directly reduces spurious shutdown events and associated production losses.
• Broad turbine fleet applicability: The 135613-01 is applicable across steam turbine, gas turbine, and combined-cycle unit types. A single spare part number covers multiple machine frames, simplifying spare parts inventory management for plant maintenance teams.
• Long service life under cyclic thermal loading: The armored cable assembly is rated for repeated thermal cycling between ambient and operating temperature without degradation of the cable’s dielectric properties or shield continuity. This is critical in peaking plants and combined-cycle units that undergo frequent start-stop cycles.

Quality Assurance & Global Logistics

Every Bently Nevada 135613-01 unit supplied by siemensplc.com is sourced from verified supply channels and undergoes incoming inspection prior to dispatch. Physical integrity, connector condition, cable continuity, and shield resistance are verified against acceptance criteria before the unit is allocated to an order. Batch traceability records and certificates of conformance are available on request for customers operating under ISO 9001 or equivalent quality management systems.

Our logistics operations are based in Xiamen, China — a major international port city with direct air freight connections to Europe, North America, Southeast Asia, the Middle East, and Oceania. In-stock units are dispatched within 1–3 business days of order confirmation. Standard international delivery via DHL Express or FedEx International Priority reaches most destinations within 3–7 business days. For time-critical plant shutdowns or emergency maintenance windows, same-day dispatch on confirmed orders placed before 14:00 CST is available upon request.

Sea freight consolidation is available for bulk orders where air freight cost is a constraint. All shipments are accompanied by a commercial invoice, packing list, and country-of-origin documentation to support customs clearance in the destination country. Export classification and HS code documentation are provided as standard.

The 12-month warranty covers manufacturing defects and premature failure under normal operating conditions. Warranty claims are processed with a replacement-first policy to minimize plant downtime — a replacement unit is dispatched upon receipt of the failed unit and confirmation of the defect.
