Bently Nevada 330905-00-11-10-02-CN Proximity Probe

330905-00-11-10-02-CN: Stop the Clock on Your Downtime — Ship Today from Xiamen

Every hour a critical rotating machine sits idle costs real money. Gas turbine tripped on high vibration. Compressor train shut down by the protection system. Steam turbine offline pending sensor replacement. You already know the part number — Bently Nevada 330905-00-11-10-02-CN — and you need it on a plane today, not in six weeks. We stock it. We ship it. We’ve done this hundreds of times for plants across Asia, the Middle East, and Europe.

The 330905-00-11-10-02-CN is an 8mm eddy-current proximity probe from Bently Nevada’s 3300 NSv (Non-contacting Vibration) series. It is the front-end sensing element in API 670-compliant machinery protection systems — the component that feeds shaft displacement and vibration data to your 3500 rack monitors. When it fails or goes out of calibration, your protection system is blind. That is not a condition you run with.

We maintain physical stock of this probe at our Xiamen warehouse. Orders confirmed before 14:00 CST ship same day via DHL Express or FedEx International Priority. Transit time to most destinations in Southeast Asia, the Middle East, and Europe runs 2–4 business days. We handle all export documentation — commercial invoice, packing list, certificate of origin — so your customs clearance does not become another delay.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Common failure signatures that point to the 330905-00-11-10-02-CN probe:

• OK LED off on the 3300 XL driver, gap voltage reads –24 VDC or open circuit: The probe coil is open. This is the most common hard failure mode — usually caused by cable damage at the probe body junction or connector corrosion. Replace the probe. Do not attempt to splice the integral cable.
• Gap voltage in range but vibration reading is noisy or erratic: Check the probe tip for surface contamination (oil varnish, metallic debris). Clean with isopropyl alcohol. If noise persists after cleaning, the probe coil may have a partial short — replace it.
• Slow drift in DC gap voltage over weeks: Thermal cycling fatigue in the probe body or cable. Common in high-temperature installations near bearing housings. Verify the probe is not exceeding its +177°C body rating. Replace and reroute cable if necessary.
• 3500 monitor shows “Not OK” with gap voltage in the normal –10 to –18 VDC window: Do not assume the probe is faulty. Check the extension cable connector seating first. A loose or corroded BNC/CN junction between the probe cable and extension cable accounts for roughly 40% of field “probe failures” that are actually connector issues.

Replacement procedure — field checklist:

1. Confirm machine is de-energized and locked out per your site LOTO procedure.
2. Record the existing gap voltage before removal (should be –10 to –18 VDC for a healthy installation). This is your baseline for the new probe setup.
3. Disconnect the probe cable from the extension cable at the CN connector. Inspect the connector pins for corrosion or bent contacts before connecting the new probe.
4. Remove the old probe from the bracket. Note the locknut position — count the exposed thread turns so you can set the new probe to approximately the same gap as a starting point.
5. Install the new 330905-00-11-10-02-CN. Thread it in until the gap voltage reads –10 to –18 VDC (typically 1.0–1.5 mm physical gap for a steel target). Tighten the locknut to the torque specified in the BN installation manual (typically 20–25 N·m for M10 thread).
6. Verify the gap voltage is stable (±0.1 VDC) over 5 minutes with the machine at rest. Any drift indicates a seating or connector issue — do not start the machine until resolved.
7. Confirm the 3500 monitor OK LED is illuminated and the channel is not in alarm before releasing the machine for restart.
8. No driver reconfiguration is required when replacing a like-for-like 330905-00-11-10-02-CN. The 3300 XL driver does not require re-gapping or firmware changes for a same-model probe swap.

Configuration note on the -CN connector suffix: The CN connector is electrically identical to the standard BNC used in Western installations. The only difference is the physical connector body. If your extension cable terminates in a standard BNC, you will need a CN-to-BNC adapter (Bently Nevada part 02820022) or a -00 suffix probe. Confirm your connector type before ordering.

Reliability in Harsh Conditions

The 3300 NSv probe series was not designed for a clean lab environment. It was designed for the inside of a bearing housing on a 50 MW gas turbine running at 3,000 RPM in a 45°C ambient with oil mist, vibration, and electromagnetic interference from adjacent VFDs. The 330905-00-11-10-02-CN reflects that design intent at every level.

The probe body is machined from stainless steel with a PEEK (polyether ether ketone) tip housing — a material that maintains dimensional stability from cryogenic temperatures to well above the probe’s rated +177°C operating limit. PEEK does not absorb moisture, does not outgas under vacuum, and does not degrade in contact with turbine oils, hydraulic fluids, or cleaning solvents. The integral cable uses a fluoropolymer jacket rated for continuous flex and high-temperature exposure, with a braided shield that rejects the common-mode noise generated by large rotating machines.

Vibration resistance is not a marketing claim for this probe — it is a design requirement. The 3300 NSv series is qualified to withstand the vibration environments defined in IEC 60068-2-6 (sinusoidal) and IEC 60068-2-64 (random), which cover the frequency ranges and amplitudes encountered in turbomachinery installations. The probe tip assembly is potted and sealed; there are no internal mechanical joints that can loosen under vibration.

In high-humidity environments — coastal plants, offshore platforms, tropical facilities — the CN connector and cable termination are the most vulnerable points. Bently Nevada addresses this with a sealed connector design and recommends the use of connector boots or heat-shrink sealing in permanently wet environments. Our pre-shipment inspection includes a connector integrity check specifically because this is where field failures originate.

Global Express Logistics

Our dispatch hub is in Xiamen, Fujian Province — one of China’s primary export ports with direct DHL, FedEx, and UPS gateway access. This is not a drop-ship arrangement. The probe is physically in our warehouse, inspected, and ready to pack when your order is confirmed.

Standard export process:

• Order confirmation → same-day dispatch for orders received before 14:00 CST (Monday–Saturday).
• Export documentation prepared in parallel with packing: commercial invoice, packing list, certificate of origin (Form E for ASEAN, standard CO for other regions), and HS code declaration (HS 9031.80 for proximity measurement instruments).
• Shipment booked on DHL Express Worldwide or FedEx International Priority — both services offer door-to-door tracking and customs clearance assistance.
• Tracking number sent to your email within 2 hours of dispatch.

Typical transit times from Xiamen:

• Southeast Asia (Singapore, Malaysia, Thailand, Indonesia): 1–2 business days
• Middle East (UAE, Saudi Arabia, Qatar, Kuwait): 2–3 business days
• Europe (Germany, Netherlands, UK, France): 3–4 business days
• North America (USA, Canada): 3–5 business days
• South America, Africa: 4–7 business days (varies by destination customs)

For plants with urgent shutdowns, we can arrange Saturday dispatch and provide a pre-alert to your local DHL/FedEx customs broker to expedite clearance. Contact us before placing the order so we can coordinate. We have done this for refineries in Jubail, power plants in Jakarta, and compressor stations in Kazakhstan — the process is established and repeatable.
