Bently Nevada 143945-05 Proximity Transducer – 3300 Series

Bently Nevada 143945-05 Eddy-Current Proximitor Sensor — Core Role in Rotating Machinery Protection Loops

The Bently Nevada 143945-05 is an 8 mm eddy-current Proximitor® sensor engineered for non-contact, continuous measurement of shaft radial vibration, axial displacement, and eccentricity in critical rotating machinery. Operating on the principle of electromagnetic induction, the sensor generates a high-frequency oscillating magnetic field (typically 1.0–1.5 MHz) through its probe tip coil. When a conductive target — typically AISI 4140 steel shaft — enters the field, eddy currents are induced on the target surface, loading the oscillator circuit and producing a proportional DC output voltage. This voltage, nominally biased at −24 VDC, shifts linearly with gap distance at a sensitivity of 7.87 V/mm (200 mV/mil), providing the monitor rack with a continuous, high-resolution analog signal that directly represents mechanical displacement in real time.

Within a machinery protection loop, the 143945-05 occupies the first stage of the signal chain: probe → extension cable → Proximitor module → monitor rack. Its output feeds directly into Bently Nevada 3300 Series or 7200 Series monitor modules, where the signal is conditioned, filtered, and compared against alarm and danger setpoints. The deterministic linearity of the eddy-current output — free from mechanical wear, friction, or contact hysteresis — makes this sensor the preferred transducer for API 670-compliant protection systems on steam turbines, gas turbines, centrifugal compressors, and large pumps.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The 143945-05 probe body houses a precision-wound coil embedded in a thermally stable epoxy matrix. The coil forms the inductive element of a Colpitts-type LC oscillator circuit resident in the Proximitor driver module. The oscillator operates at a carrier frequency of approximately 1.0–1.5 MHz — a range selected to maximize eddy-current penetration depth in ferromagnetic steel while maintaining immunity to low-frequency electromagnetic interference from motor drives and switchgear.

EMC Design: The coaxial cable between probe and Proximitor module acts as a shielded transmission line, with the outer braid grounded at the module end only (single-point grounding) to prevent ground-loop currents from injecting noise into the signal path. The Proximitor module’s demodulator circuit employs synchronous detection referenced to the carrier frequency, providing inherent rejection of out-of-band interference. This architecture achieves a signal-to-noise ratio sufficient to resolve shaft displacements below 5 μm in environments with ambient EMI levels typical of large motor control centers.

Thermal Compensation: The probe coil’s inductance exhibits a temperature coefficient that would otherwise introduce a thermal drift in the output voltage. Bently Nevada addresses this through a matched thermal compensation network within the Proximitor module, calibrated specifically for the 143945-05 probe geometry. The result is a thermal sensitivity error of less than ±0.5% of full scale across the rated −35°C to +121°C operating range — a critical requirement for sensors mounted on hot turbine bearing housings.

Cable Length Matching: The total cable system (probe cable + extension cable) must match the Proximitor module’s calibrated cable length. The 143945-05 uses a 5 m probe cable; extension cables of 1 m, 5 m, or 9 m are available to achieve standard total lengths of 5 m, 9 m, or 15 m. Mismatched cable lengths alter the oscillator’s Q-factor and shift the output scale factor, producing a calibration error that cannot be corrected by rack configuration alone. This is a common source of field measurement error and must be verified during commissioning.

Target Material Sensitivity Correction: The nominal 7.87 V/mm scale factor is calibrated against AISI 4140 steel. Shafts machined from austenitic stainless steel (e.g., 316L) or titanium alloys exhibit lower electrical conductivity and magnetic permeability, reducing eddy-current coupling and shifting the effective scale factor. Bently Nevada publishes material correction factors (typically 0.85–1.10×) for common shaft alloys; these must be applied in the monitor rack configuration to maintain measurement accuracy.

System Integration Benefits

• Direct 3300/7200 Series Compatibility: The 143945-05 is factory-calibrated to the Bently Nevada signal standard, eliminating the need for rack sensitivity reconfiguration during installation. Plug-and-play integration with 3300/16, 3300/20, 3300/25, 7200/20, and 7200/25 monitor modules is confirmed without additional signal conditioning.
• API 670 Compliance: The sensor meets the transducer performance requirements of API 670 (5th Edition), the industry standard for machinery protection systems in oil & gas and petrochemical plants. This simplifies documentation for safety integrity level (SIL) assessments and insurance audits.
• Deterministic Real-Time Response: The eddy-current output is a continuous analog signal with no sampling latency. The Proximitor module delivers a conditioned DC output within microseconds of a gap change, enabling the monitor rack to detect sub-millisecond shaft excursions — essential for protecting against rub events and oil-whirl instability in high-speed turbomachinery.
• Diagnostic Transparency via System 1: When integrated with Bently Nevada System 1 software, the 143945-05 signal chain supports full waveform capture (time-domain and frequency-domain), Bode plots, polar plots, and orbit displays. This data density allows machinery diagnostics engineers to distinguish between unbalance, misalignment, bearing defects, and aerodynamic instability without removing the machine from service.
• Non-Contact Measurement Eliminates Wear: Unlike contact-type displacement transducers (LVDTs, potentiometers), the eddy-current sensor has no mechanical interface with the rotating shaft. Mean time between failures (MTBF) for the probe assembly exceeds 100,000 hours in normal operating conditions, reducing maintenance intervals and unplanned downtime.
• Hazardous Area Suitability: ATEX certification allows deployment in Zone 1 and Zone 2 classified areas (gas groups IIA/IIB, temperature class T4) without additional intrinsic safety barriers in most configurations. Verify the specific ATEX certificate number against your site area classification documentation.
• Redundant Monitoring Architecture Support: The 143945-05 is compatible with dual-probe XY configurations for full orbit analysis. Two sensors mounted 90° apart on the same bearing plane provide a two-dimensional shaft position vector, enabling the monitor rack to compute orbit shape and detect directional instability — a capability not achievable with single-axis measurement.
• Eccentricity and Slow-Roll Compensation: At shaft speeds below approximately 600 RPM, the 143945-05 output captures shaft bow and eccentricity (mechanical runout). Bently Nevada monitor racks support slow-roll compensation vectors, subtracting the low-speed runout from the dynamic vibration signal to isolate true forced-response vibration from mechanical imperfections — improving alarm accuracy during startup and coast-down transients.

Quality Assurance & Global Logistics

Every Bently Nevada 143945-05 unit supplied by siemensplc.com is sourced through verified authorized distribution and surplus channels with full traceability documentation. Prior to dispatch, each unit undergoes a structured pre-shipment inspection protocol: visual examination of probe body, coil continuity check, coaxial connector integrity verification, and confirmation of OEM labeling and date codes. Units with evidence of rework, counterfeit markings, or damaged cable jackets are rejected at intake.

Original OEM packaging is preserved where available. Calibration certificates and material traceability records are provided upon request. A 12-month warranty against manufacturing defects is included with every shipment.

Logistics operations are based in Xiamen, China — a major port city with direct air freight connections to Singapore, Dubai, Frankfurt, Los Angeles, and Tokyo. In-stock orders are processed and dispatched within 1–3 business days. International shipments are handled via DHL Express, FedEx International Priority, and UPS Worldwide Expedited, with typical transit times of 3–7 business days to most destinations. DDP (Delivered Duty Paid) and DAP (Delivered At Place) Incoterms are supported. Export documentation including commercial invoice, packing list, and certificate of origin is prepared in compliance with destination country customs requirements. For project orders requiring consolidated shipment of multiple part numbers, contact the sales team for a logistics plan and lead time confirmation.
