CONVUM CVX-1243-MC2 OZ23 Vacuum Generator

CVX-1243-MC2 OZ23 Down? Every Minute of Vacuum Loss Costs You Money — We Ship Today

A suction failure mid-shift is not a maintenance note for tomorrow. It is a line-stop event. Pick-and-place arms freeze, conveyor buffers overflow, and your OEE number craters in real time. The CONVUM CVX-1243-MC2 OZ23 is a precision multi-stage vacuum generator — not a commodity part you can substitute with whatever is on the shelf. Wrong vacuum flow rate, wrong manifold port pitch, wrong silencer spec: any mismatch and you are back to square one. We stock this exact unit in Xiamen and can have it moving toward your facility within hours of order confirmation.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

After ten years of field work, the failure patterns on CVX-series multi-stage generators are predictable. Here is what to check before you condemn the unit — and what to watch when you install the replacement.

Common Fault Signatures:

• Gradual vacuum decay over weeks: Almost always the internal venturi nozzle fouled by particulate from upstream air supply. Pull the filter element first. If the filter bowl is clean but flow is still low, the nozzle throat is eroded — replace the generator.
• Sudden total vacuum loss: Check the solenoid valve upstream before condemning the CVX unit. A stuck-open exhaust valve on the solenoid will bleed your vacuum circuit continuously. Isolate the generator with a manual shutoff and test vacuum at the generator outlet port directly.
• Excessive exhaust noise after silencer replacement: The OZ23 silencer element is a sintered bronze disc. If a previous technician over-torqued the silencer cap, the disc cracks and loses attenuation. Inspect the disc face — hairline cracks are visible under a flashlight at an angle.
• Vacuum level unstable / hunting: On MC2 manifold configurations, check that both manifold port plugs are fully seated. A loose plug on an unused port is a common installation error that creates a micro-leak path and causes the vacuum level to oscillate.

Replacement Procedure — Key Steps:

• Depressurize the pneumatic circuit fully before disconnecting. CVX units hold residual pressure in the manifold cavity even after the supply valve closes.
• Mark the supply and vacuum port orientations before removal. The MC2 manifold is symmetric — it is easy to reinstall 180° rotated, which reverses the flow path and produces zero vacuum output.
• Inspect the mating face O-rings on the manifold block. These are the most common source of post-replacement leaks. Replace them as a matter of course — do not reuse old O-rings.
• After installation, ramp supply pressure slowly from 0 to operating pressure while monitoring vacuum level. A sharp rise to target vacuum within 2–3 seconds confirms correct installation. A slow, sluggish rise indicates a leak or incorrect port connection.
• Log the replacement date and supply pressure at commissioning. CVX multi-stage units are sensitive to over-pressure — running above the rated supply pressure accelerates nozzle wear and shortens service life significantly.

Reliability in Harsh Conditions

The CVX-1243-MC2 OZ23 is not designed for a climate-controlled lab. It is built for the floor — where coolant mist settles on every surface, where ambient temperature swings 20°C between morning startup and afternoon peak production, and where vibration from nearby presses and conveyors is constant background noise.

The multi-stage ejector body is machined from aluminum alloy with anodized surface treatment, providing corrosion resistance against the mild acids and cutting fluids common in metalworking environments. The internal venturi stages are precision-formed to maintain consistent flow geometry even after thermal cycling — a critical factor in applications where the generator cycles on and off thousands of times per shift.

The OZ23 silencer assembly uses a sintered bronze element rated for continuous duty. Unlike foam-element silencers that degrade and shed particles into the exhaust stream, the sintered bronze construction maintains its attenuation performance and does not introduce contamination risk into the surrounding environment — important in food-grade and pharmaceutical adjacent applications.

Vibration resistance is inherent in the manifold-mount design. The MC2 block provides a rigid, multi-point mounting interface that eliminates the resonance issues seen with inline-body generators mounted on flexible tubing. In high-cycle robotic cells where the generator is mounted directly on the robot arm, this rigidity translates directly into longer service intervals and fewer nuisance faults from vibration-induced connector loosening.
