Siemens 6AV2124-0GC01-0AX0 HMI Touch Panel

Siemens 6AV2124-0GC01-0AX0 TP700 Comfort: Stop the Clock on Your Downtime

Your line is down. The operator screen is dark. Every minute the TP700 Comfort stays offline, you’re bleeding production output, missing SLA windows, and fielding calls from plant management. The 6AV2124-0GC01-0AX0 is not a commodity panel — it is the visualization backbone of your SIMATIC architecture, and when it fails, nothing downstream runs cleanly. We stock it. We ship it today. That’s the only answer that matters right now.

At siemensplc.com, we maintain physical inventory of the 6AV2124-0GC01-0AX0 specifically because HMI failures don’t schedule themselves. This 7-inch WVGA resistive touch panel runs on Windows CE 6.0, integrates natively into TIA Portal WinCC, and communicates across dual PROFINET ports plus MPI/PROFIBUS — covering virtually every SIMATIC topology in the field. Whether your plant runs S7-1200, S7-1500, or legacy S7-300/400, this panel connects without protocol adapters or gateway overhead.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Before you pull the panel, confirm the fault is hardware — not configuration. The TP700 Comfort throws a black screen on boot for three distinct reasons: corrupted project file on internal flash, failed backlight (panel is alive but dark), or genuine main board failure. Hold a flashlight at an angle to the screen — if you can faintly see the UI, the backlight inverter has failed, not the panel logic. That changes your replacement urgency but not your part number.

Common fault codes and field-proven fixes:

• “Connection to PLC interrupted” on startup: Nine times out of ten this is an IP address conflict after a panel swap. The replacement unit ships with default IP 0.0.0.0 (DHCP). If your network is static, assign the correct IP via Start Center → Settings → Network Interfaces before loading the project. Skipping this step costs 30–90 minutes of unnecessary troubleshooting.
• Project transfer fails via PROFINET: Verify the TIA Portal PC and the panel are on the same subnet. The TP700 Comfort does not auto-negotiate subnet masks from the project — set it manually in the panel OS first, then transfer.
• Touch calibration drift after replacement: Resistive panels require recalibration when installed in a new cutout or after temperature shock. Access Start Center → Settings → Touch Calibration. Run the 5-point calibration with a stylus, not a finger.
• Firmware mismatch warning in TIA Portal: If the replacement panel ships with a different firmware revision, TIA Portal flags a version conflict during project download. Navigate to Online → Update Operating System and push the firmware version matching your WinCC project version. Mismatched firmware causes intermittent communication drops that are extremely difficult to diagnose post-commissioning.
• Panel reboots randomly under load: Check 24 V DC supply quality. The TP700 Comfort is sensitive to dips below 20.4 V. Use a SITOP PSU with buffering capability if your cabinet has heavy inductive loads on the same rail.

Field-tested replacement checklist:

• Export the current project backup from the original panel via SD card before powering down — if the panel still boots intermittently, this saves a full re-engineering cycle.
• Note the exact IP address, subnet mask, and gateway from the original panel’s network settings.
• Power down the cabinet. Disconnect PROFINET cables and label them — the TP700 Comfort has two RJ45 ports and incorrect reconnection breaks ring/line topology.
• Remove the 8 mounting clamps. The panel slides forward out of the cutout.
• Install the replacement unit. Reconnect cables in the same port positions.
• Power on. Enter Start Center. Set IP address to match the original. Set correct time and date.
• Transfer the project from TIA Portal or SD card. Run touch calibration. Verify all PLC connections are online before handing back to operations.

Reliability in Harsh Conditions

The 6AV2124-0GC01-0AX0 was engineered to operate continuously in the conditions that actually exist on production floors. The front bezel achieves IP65 ingress protection — it withstands direct water jets and heavy dust accumulation without seal failure. In food and beverage plants where high-pressure washdowns are routine, this rating is the difference between a panel that survives a shift change and one that fails within six months.

Vibration resistance is validated to IEC 60068-2-6 standards: sinusoidal vibration across 10–58 Hz at 0.075 mm amplitude, and 58–500 Hz at 1g. In practice, the panel holds up on machine tools, compressor skids, and mobile equipment where constant mechanical vibration would destroy consumer-grade displays within weeks.

The operating temperature ceiling of +50 °C covers the vast majority of industrial cabinet environments, including tropical climates without air conditioning. The resistive touch technology responds to gloved hands, stylus input, and knuckle operation — critical where operators wear cut-resistant or chemical-resistant gloves and cannot remove them to interact with a touchscreen.

Long-term field deployment data across automotive, chemical, and energy sectors consistently shows the TP700 Comfort achieving MTBF figures well above 50,000 hours under normal operating conditions. The backlight is the most common wear component — plan for panel swap at the 5–7 year mark in continuous 24/7 operation.

Global Express Logistics

Our warehouse is in Xiamen, Fujian Province — one of China’s primary export hubs with direct access to DHL Express, FedEx International Priority, and UPS Worldwide Express freight lanes. For urgent orders confirmed before 14:00 CST, same-day dispatch is standard.

• Southeast Asia (Singapore, Thailand, Vietnam, Malaysia): 2–3 business days via DHL Express
• Middle East (UAE, Saudi Arabia, Qatar): 3–4 business days via FedEx International Priority
• Europe (Germany, Netherlands, Poland, UK): 3–5 business days via DHL Express
• North America (USA, Canada, Mexico): 4–6 business days via FedEx or UPS
• Australia & New Zealand: 3–5 business days via DHL Express
• South America (Brazil, Chile, Colombia): 5–8 business days depending on customs clearance

All shipments include real-time tracking from dispatch to delivery. AWB number is provided within 2 hours of dispatch confirmation. For plant shutdowns or emergency maintenance windows, contact us directly on WhatsApp for priority processing — we coordinate same-day courier pickup for orders confirmed by noon.

Export documentation prepared in-house: commercial invoice, packing list, certificate of origin, and HS code declaration (HS 8537.10) are standard with every shipment. DDP, DAP, and EXW Incoterms available. Every unit is packed in anti-static foam-lined cartons with moisture barrier film and double-walled corrugated outer carton for air freight drop protection.
