Siemens 6EP1337-3BA00 Power Supply Module

Siemens 6EP1337-3BA00 SITOP PSU100S — Stop the Clock on Your Downtime

Your line is down. The SITOP rail is dark. Every minute the 6EP1337-3BA00 stays offline, you’re burning money — lost throughput, idle labor, delayed shipments, and a plant manager breathing down your neck. We’ve been in that control cabinet with you. That’s exactly why we stock the Siemens 6EP1337-3BA00 ready to pull and ship today, not in six weeks.

The 6EP1337-3BA00 is the 24 VDC / 10 A variant in Siemens’ SITOP PSU100S series — the workhorse power supply found in tens of thousands of S7-300, S7-1200, and ET 200 installations worldwide. When it fails, nothing downstream works: PLCs lose their 24 V logic rail, solenoids drop, HMIs go dark, and safety circuits may trip the entire cell. There is no workaround. You need the exact part, fast.

We ship from Xiamen via DHL Express and FedEx International Priority. Most orders clear customs and land on your dock within 3–5 business days, anywhere in the world. That’s the difference between a half-day incident and a week-long production crisis.

URGENT REQUIREMENT? Contact: [email protected] | WhatsApp: +86 18359268345

Quick Technical Datasheet

Troubleshooting & Replacement Tips

Fault symptom: Green LED off, no 24 V output. Before condemning the PSU, check your AC input fuse and the upstream MCB — a nuisance trip is the most common false alarm. Confirm AC input with a multimeter at L and N terminals. If AC is present and the LED stays dark, the internal PFC stage or primary switching transistor has likely failed. The 6EP1337-3BA00 is not field-repairable; swap the unit.

Fault symptom: Output voltage low (below 22 V) under load. This usually points to a degraded output capacitor bank — common after 5–7 years in high-ambient environments. The output voltage trim pot on the front panel can compensate slightly, but if you’re already at maximum trim and still reading low, replace the unit. Do not attempt to run downstream PLCs on a sagging rail; S7-300 CPUs will generate spurious STOP events and corrupt retentive data.

Fault symptom: Intermittent DC OK relay chatter. The signal contact is bouncing, triggering nuisance alarms in your SCADA. Root cause is almost always marginal output voltage — the internal comparator is toggling around the threshold. Check for loose output wiring first (a 0.5 Ω resistance in a 10 A circuit drops 5 V). If wiring is solid, the PSU is failing.

Replacement procedure — step by step:

1. Isolate the AC supply to the panel. Lock out / tag out per your site procedure. Verify zero energy with a CAT III meter.
2. Note the output voltage trim setting on the old unit before removal — photograph the front panel.
3. Disconnect the DC OK signal wires first (low voltage, but label them — polarity matters for your PLC input).
4. Disconnect the 24 V DC output terminals. If the downstream bus is live from a parallel PSU, be aware of back-feed current.
5. Disconnect AC input terminals (L, N, PE). The PE lug is safety-critical — do not omit it on the replacement.
6. Slide the old unit off the DIN rail. The 6EP1337-3BA00 uses a standard snap-fit foot — press down on the rail release lever at the bottom.
7. Snap the new unit onto the rail. Reconnect in reverse order: PE → AC input → DC output → DC OK signal.
8. Set the output voltage trim to match your previous setting. If unknown, start at 24.0 V and verify downstream device specs before adjusting.
9. Restore AC power. Confirm green LED illuminates within 2 seconds. Measure output voltage under load before releasing the line.
10. Verify DC OK relay closes (check your SCADA alarm clears). Log the replacement in your maintenance record with date and serial number.

Configuration note — parallel operation: If you’re adding a second 6EP1337-3BA00 for redundancy, set both units to identical output voltage (within 0.1 V) before paralleling. A mismatch will cause one unit to carry disproportionate load and fail prematurely. No diodes or load-sharing modules are required for two units; beyond two, use the SITOP redundancy module.

Firmware / hardware revision note: The 6EP1337-3BA00 has no firmware — it is a pure analog/switched-mode supply. Hardware revisions (e.g., -3BA00 vs earlier -2BA00) differ in PFC topology and efficiency rating. The -3BA00 is a drop-in mechanical and electrical replacement for all prior PSU100S 10 A variants. No reconfiguration of the downstream PLC or I/O is required.

Reliability in Harsh Conditions

The SITOP PSU100S was engineered for environments that destroy consumer-grade power supplies in weeks. The 6EP1337-3BA00 carries an IP20 rating for the module itself, but the real story is what’s inside the enclosure.

Vibration: Qualified to IEC 60068-2-6 (sinusoidal, 10–150 Hz, 1 g) and IEC 60068-2-27 (shock, 15 g / 11 ms). In practice, this means it survives on the same DIN rail as a running compressor or a press brake without loosening internal solder joints — a failure mode that kills cheaper supplies within months.

Thermal cycling: The operating range of 0–60 °C covers the vast majority of industrial cabinet environments, including summer conditions in non-air-conditioned outdoor enclosures in Southeast Asia and the Middle East. The internal thermal management uses a combination of convection and a low-noise fan (activated above 50 °C ambient) to maintain junction temperatures within safe limits. Electrolytic capacitors — the life-limiting component in any PSU — are rated for 105 °C, giving substantial derating margin at typical operating temperatures.

Humidity and condensation: Conformal coating on the PCB provides protection against humidity up to 95% RH (non-condensing). In coastal or high-humidity plant environments, this coating is the difference between a 7-year service life and a corrosion failure in year two.

EMC: Compliant with EN 61000-6-2 (industrial immunity) and EN 61000-6-4 (industrial emissions). Active PFC reduces harmonic injection into the plant power distribution, protecting sensitive instrumentation on the same bus.

ATEX Zone 2: The 6EP1337-3BA00 holds ATEX certification for use in Zone 2 potentially explosive atmospheres when installed in an appropriate Ex e or Ex d enclosure. This makes it suitable for chemical plant control panels, offshore platform junction boxes, and paint booth automation — environments where most competitors’ supplies simply cannot go.

Global Express Logistics

We operate from Xiamen, China — one of the country’s primary export hubs with direct access to international freight lanes via Xiamen Gaoqi International Airport and Xiamen Port. This geography is not accidental: it puts us within 24 hours of DHL and FedEx international sort facilities, which translates directly into faster delivery for you.

Standard export process: Orders confirmed before 14:00 CST are packed and handed to the carrier the same business day. Each shipment includes a commercial invoice, packing list, and certificate of conformity. For destinations requiring import permits or specific customs documentation (e.g., EU CE declaration, UKCA, or country-specific certificates), we prepare these in advance to prevent customs holds.

DHL Express Worldwide: Typical transit times — Europe: 3–4 business days; North America: 3–5 business days; Southeast Asia: 1–2 business days; Middle East: 3–4 business days; Australia/NZ: 3–5 business days. All shipments are fully tracked with proactive exception management — if a customs hold or routing delay occurs, we contact you immediately and work with the carrier to resolve it.

FedEx International Priority: Available as an alternative for destinations where FedEx has stronger local delivery networks (e.g., remote US locations, Canada, Mexico). Transit times are comparable to DHL Express.

Freight insurance: All shipments are insured at declared value. In the event of loss or damage in transit, we file the claim and ship a replacement unit — you are not left chasing the carrier yourself.

Emergency same-day dispatch: For critical downtime situations, contact us via WhatsApp before 12:00 CST. We will prioritize packing and can arrange airport pickup by the carrier for the earliest available flight. This option has recovered production lines in Europe within 48 hours of the initial call.
