Siemens 6AV2124-0QC02-0AX1 HMI Touch Panel – SIMATIC Comfort Series

Siemens 6AV2124-0QC02-0AX1 — SIMATIC HMI TP1200 Comfort: High-Resolution Operator Interface for Process-Critical Control Loops

The 6AV2124-0QC02-0AX1 is a 12.1-inch widescreen operator panel from Siemens’ SIMATIC HMI Comfort series. Within a distributed control architecture, this unit occupies the visualization and operator-interaction layer — translating PLC process data into structured graphical representations and routing operator commands back to the controller with deterministic latency. Its role is not decorative; it is a functional node in the control loop, responsible for alarm acknowledgment, setpoint entry, recipe management, and real-time trend display across multi-axis and multi-zone process environments.

The TP1200 Comfort is engineered for applications where display fidelity, communication redundancy, and long-term platform stability are non-negotiable. It integrates natively with SIMATIC S7-1200, S7-1500, S7-300, and S7-400 controllers via PROFINET and MPI/PROFIBUS, and supports third-party controller connectivity through OPC UA client and Modbus TCP. The panel runs SIMATIC WinCC Comfort/Advanced under TIA Portal, enabling unified engineering across PLC, HMI, drives, and safety within a single project framework.

Real-time Stock & RFQ: [email protected] | WhatsApp: +86 18359268345

Technical Parameters

Hardware Logical Analysis

The 6AV2124-0QC02-0AX1 is built on a single-board architecture centered on a 1 GHz ARM Cortex-A8 SoC. The processor handles concurrent tasks — PROFINET stack execution, WinCC runtime rendering, touch event processing, and SD card I/O — through a real-time OS scheduler under Windows CE 6.0. Memory bandwidth is managed via a dedicated DDR controller, keeping display refresh and communication polling on separate DMA channels to prevent I/O contention.

Dual PROFINET Port Topology: The two RJ45 ports share a single PROFINET ASIC with an integrated 2-port switch. This enables daisy-chain (line) topology without an external switch, reducing panel wiring complexity and eliminating a potential single point of failure in the network segment. Each port supports PROFINET RT (cycle time ≥ 1 ms) and IRT (cycle time ≥ 250 µs) modes, with the HMI operating as a PROFINET IO controller or device depending on configuration.

EMC Design: The panel housing is a die-cast aluminum alloy frame with continuous EMC gasket sealing at the front bezel interface. Internal PCBs use ground plane stitching and ferrite bead filtering on all I/O lines. The 24 V DC input is protected by a transient voltage suppressor (TVS) rated at ±1 kV (IEC 61000-4-5 Level 3), and the PROFINET ports include transformer-coupled isolation with 1.5 kV common-mode rejection. This architecture meets EN 61000-6-2 (industrial immunity) and EN 61000-6-4 (industrial emissions) without external filtering.

Resistive Touch Mechanism: The analog resistive overlay uses a four-wire matrix with a dedicated touch controller IC that performs 12-bit A/D conversion on X/Y coordinates. Activation force is calibrated to 0.5–1.0 N, allowing gloved-hand operation — a practical requirement in chemical, food processing, and heavy manufacturing environments where capacitive touch is unreliable. The overlay is rated for ≥ 1,000,000 touch cycles at a single point.

Backlight Architecture: The TFT panel uses a cold-cathode fluorescent lamp (CCFL) backlight with an inverter circuit that maintains constant luminance (≈ 400 cd/m²) across the 19.2–28.8 V supply range. MTBF for the backlight assembly exceeds 50,000 hours at 25 °C ambient. The display assembly is a field-replaceable unit (FRU) available through Siemens spare parts channels, supporting long-term serviceability.

System Integration Benefits

• Unified TIA Portal Engineering: HMI project shares the same symbol table and data block references as the S7 PLC project — tag changes propagate automatically, eliminating manual synchronization errors between controller and visualization layers.
• Line Topology Without External Switches: Dual PROFINET ports allow the panel to pass network traffic to the next device in a daisy chain, reducing switch count, cabinet footprint, and BOM cost in distributed machine architectures.
• OPC UA Client for Heterogeneous Networks: Built-in OPC UA client (UA 1.02 compliant) enables direct data exchange with non-Siemens controllers, SCADA servers, and MES systems without gateway hardware, supporting IIoT data aggregation architectures.
• Alarm Server with 32,768 Alarm Classes: The integrated alarm server supports discrete, analog, and system alarms with configurable priorities, acknowledgment groups, and time-stamped logging to SD card or network share — enabling root-cause analysis and 21 CFR Part 11 compliant audit trails in regulated industries.
• Recipe Management: Up to 500 recipes with 100 data records each can be stored locally and transferred to PLC data blocks via operator selection or automated triggers, supporting flexible batch production without PLC program changes.
• Trend and Data Logging: Configurable trend objects log up to 32 process values at user-defined intervals (100 ms minimum) to SD card or USB storage, providing long-term process data for quality analysis and predictive maintenance workflows.
• Multi-Language Runtime Switching: Supports up to 32 project languages with runtime switching via operator input or PLC tag — essential for multinational production facilities and OEM machine exports to multiple markets.
• Scalable Security Model: Five-level user administration with password protection and configurable screen saver lockout. Supports integration with SIMATIC Logon for centralized Windows-domain-based user management in enterprise environments.

Quality Assurance & Global Logistics

Every 6AV2124-0QC02-0AX1 unit supplied by siemensplc.com is sourced from verified Siemens distribution channels. Each unit undergoes a structured incoming inspection protocol: firmware version verification against Siemens release notes, display integrity check (zero dead pixels, uniform backlight), connector and port physical inspection, and a full power-on self-test (POST) confirming boot sequence completion and PROFINET port link establishment.

Original Siemens packaging, CE declaration of conformity, and product documentation are supplied where available. Serial number traceability is maintained for every unit, and authenticity verification documentation can be provided upon request for procurement compliance purposes.

Warranty coverage is 12 months from the shipment date. Dead-on-arrival (DOA) units are replaced within 30 days of confirmed fault report. Technical support for commissioning, TIA Portal configuration, and firmware queries is available via email and WhatsApp throughout the warranty period.

Logistics are managed from Xiamen, China, with daily dispatch via DHL Express, FedEx International Priority, and UPS Worldwide Expedited. Standard transit times: 3–5 business days to Europe and North America; 2–4 business days to Southeast Asia and the Middle East. Incoterms available: EXW, FOB Xiamen, CIF destination port. Export documentation including commercial invoice, packing list, and certificate of origin is prepared for all international shipments. HS Code 8537.10 applies for customs classification in most jurisdictions.
